Intellian i2 Operation Manual page 20

Intellian Satellite TV Antenna Systems
Multiple-IRDs Connection
In order to connect multi-IRD to the antenna, you will need to purchase
a suitable multiswitch. The multiswitch has to be installed between the
antenna unit and the IRDs as shown on the right.
Note: The system can receive either "High Band" or "Low Band"
channels by using a multi-switch to connect more than two receivers.
20
RF1 RF2
RF Cable
Antenna
ACU
NMEA GPS PC Cable
DC Power Cable
IRD 1
Figure 17 : Multi-IRDs Configuration
ACU IRD Cable
Receiver
Multi switch
(Not Supplied)
IRD 2 IRD 3 IRD 4
* IRD 1~4 : Not supplied
