2-2 Environmental Conditions
Indoor use only.
Maximum Altitude : 2000 meters.
Installation Category : IEC 1010 Cat. II 600V, Cat. III 300V.
Pollution Degree : 2
Operating Ambient : 0°C ~ 50°C, < 75% R.H.
Storage Temperature : -20°C ~ 60°C, < 80% R.H.
Temperature Coefficient : 0.2 x (Specified accuracy) / °C, < 18°C or > 28°C.
Power Requirement : Alkaline 9V battery.
Battery Life : 40 hours typical (Alkaline).
Max/Conductor Size : 34mm diameter or 20 x 40mm busbar.
Size : 600mm (W) x 203mm (L) x 29mm (H).
Weight : 310 grams.
Supplied Accessories : Battery (installed), manual and carrying case.
7
