- Page 1 INSTRUCTION MANUAL IDM17 PEN-TYPE MULTIMETER IDM 17...
- Page 2 ISO-TECH IDM 17 PEN-TYPE MULTIMETER INSTRUCTION MANUAL...
- Page 4 INTRODUCTION 1-1 Unpacking and Inspection Upon removing your new Digital Multimeter from its packing, you should have the following items: 1. Digital Multimeter. 2. Test lead (one black). 3. Test probe (Red). 4. Operations manual. 5. Carrying case. 1-2 Meter Safety Terms marked on Equipment ATTENTION - Refer to Manual.
- Page 5 Symbols in this Manual This symbol indicates where cautionary or other information is found in the manual. Battery 1-3 Front Panel Refer to Figure 1 and to the following numbered steps to familiarise yourself with the meter's front panel controls and connectors.
- Page 6 , Ω 6. V Selection Switch — Press the blue switch alternately to measure AC Voltage or DC Voltage in the voltage mode or to measure resistor or continuity or diode in Ω mode. 7. Hold Switch — This switch is used to hold measured value for all functions. Press the Hold switch until the " "...
- Page 7 Figure 1...
-
Page 8: Specifications
SPECIFICATIONS 2-1 General Specifications This instrument has been designed in accordance with UL 3111-1 and IEC publication 1010 Pt 1, Class II, Safety Requirements for Electrical Equipment for measurement, control and laboratory use. This level of safety can only be guaranteed while the limits of 2.2 are observed. - Page 9 2-3 Environmental Conditions Maximum Altitude : 2000m Installation Category : IEC 1010 600V CAT II 300V CAT III Pollution Degree : 2 Operating Temperature : 0°C to 50°C, 0 to 80% R.H. Storage Temperature : -20°C to 60°C, 0 to 80% R.H with battery removed from the meter. Temperature Coefficient : 0.15 x (Specified accuracy) / °C, <...
- Page 10 2-3 Electrical Specifications Accuracy is ± (% reading + number of digits) at 23°C ± 5°C, less than 75% R.H. (1) DC Volts Range Resolution Accuracy Over voltage protection 300mV 100µV ±(0.7% reading+ 2 digits) 10mV 600V DC or 600Vrms 300V 100mV 600V...
- Page 11 (2) AC Volts Range Resolution Accuracy Over voltage protection ±(1.7% reading+ 5digits) 10mV 600V DC or 600Vrms ±(1.7% reading+ 5digits) 300V 100mV 40Hz ~ 500Hz 600V * Frequency Response : 40Hz 300Hz for 3V range. Input Impedance: 10MΩ // less than 100pF. The reading will fluctuate approximately 2 ~ 5 counts over 200V.
- Page 12 (3) Resistance Range Resolution Accuracy Over load protection ±(1.2%reading + 4digits) 300Ω 0.1Ω 3KΩ 1Ω ±(1.0%reading + 2digits) 30KΩ 10Ω 600V DC or 600Vrms 300KΩ 100Ω ±(1.5%reading + 3digits) 3MΩ 1KΩ 30MΩ 10KΩ ±(3%reading + 5digits) Open Circuit Voltage: 1.3V approx.
- Page 13 (4) Diode Check and Continuity Max. Test Max.Open Range Resolution Accuracy Current Circuit Voltage ±(1.5%reading + 5digits)* 1.5mA 3.3V *For 0.4V ~ 0.8V Overload Protection: 600V DC/AC rms max. Continuity: Internal sounder operates when resistance is less than approximately 20Ω. (5) Auto Power Off The meter will automatically shut itself off approximately 10 minutes after power on.
- Page 14 OPERATION This instrument has been designed and tested in accordance with IEC Publication 1010, Safety Requirements for Electronic Measuring Apparatus, and has been supplied in a safe condition. This instruction manual contains some information and warnings which must be followed by the user to ensure safe operation and to retain the instrument in safe condition.
- Page 15 3-1 Preparation and Caution before Measurement 1. Allow at least 60 seconds after switching on before taking measurements. 2. When the function switch selector is changed during measurement, be sure to do so only after removing the test leads from the equipment. 3.
- Page 16 WARNING TO AVOID ELECTRICAL SHOCK, HAZARD OR DAMAGE TO THE METER, DO NOT ATTEMPT TO MEASURE VOLTAGE THAT MIGHT EXCEED 600V (INSTALLATION CATEGORY II) AND 300V (INSTALLATION CATEGORY III). DO NOT APPLY MORE THAN 600V D.C OR A.C. RMS BETWEEN THE COMMON INPUT TERMINAL AND EARTH GROUND.
- Page 17 4. Connect the test leads across the resistor to be measured. To ensure the best accuracy in measurement of low resistance, short the test leads before measurement and note the test lead resistance. It is necessary to subtract the resistance of the test leads from the displayed reading. 3-4 Continuity Check by Sounder 1.
-
Page 18: Maintenance
MAINTENANCE To keep the instrument clean, wipe the case with a damp cloth and detergent. Do not use abrasives or solvents. Any adjustment, maintenance and repair of opened instruments with voltage applied shall be avoided as far as possible and, if inevitable, shall be carried out by a skilled person who is aware of the hazard involved. Whenever it is likely that the protection has been impaired, the instrument shall be made inoperative and be secured against any unintended operation. -
Page 19: Battery Replacement
BATTERY REPLACEMENT The meter is powered by two 1.5V batteries. Refer to Figure 2 and use the following procedure to replace the batteries. 1. Disconnect the test leads and turn the meter off. Remove the test probe and lead from the input terminals. 2. - Page 20 Screw Battery 1.5V x 2 Figure 2...
- Page 21 Asia Iso-Tech 7410 Pebble Drive 460 Alexandra Road, #15-01A Fort Worth PSA Building Texas 76118-6961 Singapore 119963 Europe Canada Iso-Tech 1701 Woodward Drive PO Box 99 Ste 108 Ottawa Corby Ontario K2C 0R4, Canada Northamptonshire NN17 9RS United Kingdom Japan...
