J&D MAnufacturing MEGA STORM Manual

MEGA STORM
72" Fiberglass Exhaust Fan 72 Fiberglass Exhaust Fan
NOTE: Read ALL instructions over carefully before attempting NOTE: Read ALL instructions over
to install the Mega Storm. to install the Mega Storm.
If you have any questions please call your local dealer or
J&D Manufacturing at: 1-800-998-2398.
Or visit our website at: www.jdmfg.com
WARRANTY
J&D Mfg. warrants all products are free from defects in materials and workmanship under
normal use for the period of one year from date of purchase and our warranty does not
cover normal or regular wear and tear. J&D Mfg can repair or replace at our option, any
product or part of the product that is found to be defective. Our warranty applies to
materials only and does not include return freight, delivery, loss or damage to personal
property, cost of removal or installation, any incidental or consequential damages or labor.
This warranty does not apply to products which are misused, abused, altered, improperly
installed or subject to negligence. All warranties must be approved through our warranty
department. The original purchaser must present a copy of the invoice for the defective
product. One year is our standard warranty unless specified on our literature or in the
installation instructions/user manuals.
RECOMMENDED TOOLS FOR INSTALLATION AND ASSEMBLY
(NOT PROVIDED)
Safety Glasses Rivet Gun
Socket Wrench
1/2" Socket 1/2" Socket
IS183-09H
carefully before attemp
Phillips Head
Screwdriver
Drill
and Drill Bits
Measuring
3/16"
Tape
3/8"
INCLUDED ASSEMBLY HARDWARE - TO SCALE
(8) Phillips Truss Bolt
5/16"-18 x 1"
(8) Nylock Flange Nut
5/16"-18
INSTALLATION HARDWARE IS NOT PROVIDED
PARTS LEGEND
Guard Housing
(10) Shutter Clips
Construct structurally sound 76½" square finished opening.
FINISHED
OPENING
76 ½"
(Inside Dimensions)
Correct orientation of fan. From the inlet side the motor will be located in
the bottom right corner.
View from inlet
side of fan
(10) 3/16" x 1/4"
Aluminium Rivet
(10) 3/16"ID x 1/2"OD
Washer
Shutter
76 ½"
Motor
