Specifi cations OpenRound:
InCeiling Mini OpenRound
Cabinet Dimensions:
Inside Ring Diameter: 6-7/16" (16.3cm)
Mounting Depth: 3" (10.4cm)
Hole Cut Out | NCB: 6-1/2 (16.5cm) | RM
Grill: 7-3/8 (18.7cm)
Product Weight:
3.4 lbs. each (1.5kg)
Shipping Weight:
(2 per box)
9 lbs. (4.2kg)
Drive Units:
(1) 1" (25mm) Fabric dome tweeter.
(1) 4" (11cm) Carbon fi ber woofer.
Sensitivity:
86 dB/1W/1m
Installed Frequency Response:
85 Hz - 20 kHz (+/-3dB)
Power Handling:
Rec. amp. power 25 - 75 watts
Impedance:
Nominal impedance 8 ohms
InCeiling Silver OpenRound
Cabinet Dimensions:
Inside Ring Diameter 9-3/8" (23.8cm)
Mounting Depth 4-1/16" (10.4cm)
Hole Cut Out | NCB: 9-1/2 (24.1cm) | RS
Grill: 10-1/4 (26.1cm)
Product Weight:
5 lbs. each (2.2kg)
Shipping Weight:
(2 per box)
12.4 lbs. (5.6kg)
Drive Units:
(1) 1" (25mm) Fabric dome tweeter.
(1) 6-1/2" (17cm) Carbon fi ber woofer.
Sensitivity:
87 dB/1W/1m
Installed Frequency Response:
70 Hz - 20 kHz (+/-3dB)
Power Handling:
Rec. amp. power 25 - 125 watts
Impedance:
Nominal impedance 8 ohms
InCeiling Bronze OpenRound
Cabinet Dimensions:
Inside Ring Diameter: 7-3/4" (19.6cm)
Mounting Depth: 4-1/8" (10.4cm)
Hole Cut Out | NCB: 7-7/8 (20cm) | RB
Grill: 8-5/8 (21.9cm)
Product Weight:
4.2 lbs. each (1.9kg)
Shipping Weight:
11 lbs. (5kg)
Drive Units:
(1) 1" (25mm) Fabric dome tweeter.
(1) 5-1/4" (14cm) Carbon fi ber woofer.
Sensitivity:
85 dB/1W/1m
Installed Frequency Response:
65 Hz - 20 kHz (+/-3dB)
Power Handling:
Rec. amp. power 25 - 75 watts
Impedance:
Nominal impedance 8 ohms
InCeiling Silver DT OpenRound
Cabinet Dimensions:
Inside Ring Diameter 9-3/8" (23.8cm)
Mounting Depth 4-1/16" (10.4cm)
Hole Cut Out | NCB: 9-1/2 (24.1cm) | RS
Grill: 10-1/4 (26.1cm)
Product Weight:
5.3 lbs. each (2.4kg)
Shipping Weight:
7.4 lbs. each (3.4kg)
Drive Units:
(2) 1" (25mm) Fabric dome tweeter.
(1) 6-1/2" (17cm) Carbon fi ber woofer.
Sensitivity: (each channel)
87 dB/1W/1m
Installed Frequency Response:
60 Hz - 20 kHz (+/-3dB)
Power Handling:
Rec. amp. power 25 - 125 watts
Impedance:
Nominal impedance 8 ohms
