How to Enable and Configure PPP via Serial Port
The DV-IP Server supports PPP via serial connectivity and also over the network
connection. The following identifies the parameters that require configuration to allow a
PPP connection to be made via the serial interface.
To enable PPP and allocate a modem:
1. Select System -> Serial Ports & Telemetry
2. Using the drop down list on the associated Communication port (COM 2) select PPP
Note: PPP Link 1 is allocated to COM2 for dial out on alarm and PPP Link 2 is allocated to
COM1 for dial in.
3. Select the relevant modem from the Modem/TA drop down list, if your modem is not supported
select generic
Note: Auto detect will only auto detect the modems the Server recognises.
4. The serial standard settings for the selected modem will automatically be allocated, however if this
is incorrect you can change these for:
- Baud rate, Parity, Data bits, Stop bits, Flow control
115200, 0, 8, 1, HARDWARE
5. Remember to save the configuration by selecting Save Settings!
6. Reset the DV-IP Server for the unit to initialise the modem.
Note: For Connect on Alarm to function the Remote Alarm Monitoring function of the DV-IP
Viewer must be unlocked, contact Dedicated Micros Customers Services for more
information.
