Installing and Wiring the Thermostat
Table 3
Only one sensor can be connected to each port.
Note
Table 3 Remote Sensor Switch Settings
Remote Sensor
Remote Sensor 1
A1
B1
Remote Sensor 2
A2
B2
Connecting CAT5/CAT5E/CAT6 Wiring for Ethernet Networks to
IMT350c Thermostats
The label located on the inside of the base plate (see
color-coded wiring schemes for Ethernet CAT5/CAT5E/CAT6 connections.
To wire the Ethernet network, refer to
Proliphix base plate number for CAT5/CAT5E/CAT6 color coding.
If the other end of the CAT5/CAT5E/CAT6 cable is connected to a Proliphix
EPA-20/60 Ethernet Power Adapter, follow the wiring scheme for T568A.
Note
All wiring must conform to local codes and ordinances. The distance between
CAT5/CAT5E/CAT6 cables and HVAC cables should be a minimum of one inch.
Caution
10 Proliphix Internet Managed Thermostat (IMT) 350c/350w Installation Guide, Release 1.0
Beta Draft Confidential
lists the remote sensor switch settings.
Thermistor and Contact
ON
OFF
ON
OFF
Figure 4) shows several
Figure 4 and match the label number to the
