- Page 1 Instruction Manual B&W Smoke-Detector Hidden Camera VK-1322/SMD...
-
Page 2: Safety Instructions
Contents Safety Instructions ..................2 Description ....................3 Installation ..................... 3 Specifications ....................5 Dimensional Drawings ................... 6 1. Safety Instructions • Read these safety instructions and the operation manual first before you install and commission the camera. • Keep the manual in a safe place for later reference. •... - Page 3 • Use only a mild detergent to clean the housing. Never use dilution or gasoline for this can cause permanent damage to the surface. The cameras should never: • be operated beyond the technical specifications. This can lead to destruction. •...
- Page 4 3. Installation Select a location in the ceiling where you want to install the camera unit. Connect the cables as follows: 12VDC to A , Video Out to B. (Ref. Figure below) With your hand, position the camera unit so the camera is aimed toward the area to be observed.
- Page 5 To secure the unit in the location selected in STEP 1, tighten the screws E in the holes as shown in Figure below. Step 6...
-
Page 6: Specifications
4. Specifications Model VK-1322/SMD EDP No. 91988 Imager 1/3” Sony Super HAD Interline Transfer CCD Picture elements Approx. 440,000 (H) 752 x (V) 582 System CCIR Synchronization Internal Sensitivity 0.65Lux at F2.0 / 0.23Lux at F1.2 (VT measured result) Horizontal resolution... -
Page 7: Dimensional Drawings
Accessories EDP No. Description 70447 Plug-in Power Supply Unit 100-240VAC 77772 PSU 12VDC/0.5A, Regulated, Desktop 77779 Plug-in Power Supply Unit 230VAC/12VDC 5. Dimensional Drawings ∅ 120 ∅ 50 Dimensions: mm... - Page 8 ® is a registered trademark of Videor Technical E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR TECHNICAL E. Hartig GmbH Carl-Zeiss-Straße 8 · 63322 Rödermark/Germany Technical changes reserved Tel. +49 (0) 60 74 / 888-0 · Fax +49 (0) 60 74 / 888-100 www.videortechnical.com...
