Main Parts Layout
Hot, Cold and Sparkling
CHECK VALVE
IN (Water)
HOT WATER OUT
AIR VENT
SOLENOID
VALVE 2
SOLENOID
VALVE 1
SOLENOID
VALVE 3
CONDENSER
HOT
TANK
FILTER
DRYER
COMPRESSOR
FAN MOTOR
DRAIN
VALVE
CO In
2
HOT WATER OUT
SOLENOID
VALVE 6
SPARKLING WATER OUT
SOLENOID
COLD
VALVE 5
WATER
OUT
COLD SAFETY
SENSOR VALVE
COLD &
SPARKLING
TANK
SOLENOID
VALVE 4
DRAIN DRAIN
VALVE VALVE
CHECK
VALVE
PUMP
8
Main Parts Layout
Hot and Cold
IN (Water)
AIR VENT
SOLENOID
VALVE 2
SOLENOID
VALVE 1
SOLENOID
VALVE 3
CONDENSER
HOT
TANK
FILTER
DRYER
COMPRESSOR
FAN MOTOR
DRAIN
VALVE
HOT WATER OUT
SOLENOID
VALVE 5
COLD WATER OUT
COLD
SENSOR
COLD
TANK
DRAIN DRAIN
VALVE VALVE
