WaterLogic WL4 Firewall Technical Manual page 15

WL4 WL4 WL4
Description
HCS HC CS
Machine Size 417mm(W) x 439mm(H) x 470mm(D)
Base Cabinet Size 418mm(W) x 803.4mm(H) x 467.3mm(D)
Mini & BC Size 418mm(W) x 1238mm(H) x 470mm(D)
Machine Weight 35kg 27kg 34kg 26kg
Base Cabinet
Weight
Power Supply
Heater 500W 500W N/A
Fan 16W 16W 16W
Compressor 114W 114W 114W
Pump 12W N/A 12W
UV Lamp 11W 11W 11W
Control Units 15W 15W 15W
Unit Total 668W 656W 168W 156W
Refrigeration Gas
75g 75g 75g
R134a
4.5 4.5 4.5
Cold Tank Capacity
Litre Litre Litre
1.2 1.2
Hot Tank Capacity N/A
Litre Litre
CO 2 Bottle (Max) 10kg N/A 10kg
1/4" 1/4" 1/4"
Water Connection
Hose Hose Hose
Minimum Water
0.15 0.15 0.15
Pressure
(1.5) (1.5) (1.5)
Megapascal (Bar)
Maximum Water
0.35 0.35 0.35
Pressure
(3.5) (3.5) (3.5)
Megapascal (Bar)
Recommended Water
0.30 0.30 0.30
Pressure
(3.0) (3.0) (3.0)
Megapascal (Bar)
Hot Water
87°C 87°C N/A
Temperature
Cold Water
6°C 6°C 6°C
Temperature
Sparkling Water
6°C N/A 6°C
Temperature
28
WL4
WL4 WL4 WL4 WL4 WL4
CA CAS HC CA C
C
26kg 34kg 25kg 24kg 24kg
18kg
220-240 Volt / 50Hz
N/A N/A N/A 500W N/A N/A
16W 16W 16W 16W 16W 16W
114W 114W 114W 114W 114W 114W
N/A N/A 12W N/A N/A N/A
11W 11W 11W 11W 11W 11W
15W 15W 15W 15W 15W 15W
156W 168W 656W 156W 156W
75g 75g 75g 45g 45g 45g
4.5 4.5 4.5 2 2 2
Litre Litre Litre Litre Litre Litre
1.2
N/A N/A N/A N/A N/A
Litre
N/A N/A 10Kg N/A N/A N/A
1/4" 1/4" 1/4" 1/4" 1/4" 1/4"
Hose Hose Hose Hose Hose Hose
0.15 0.15 0.15 0.15 0.15 0.15
(1.5) (1.5) (1.5) (1.5) (1.5) (1.5)
0.35 0.35 0.35 0.35 0.35 0.35
(3.5) (3.5) (3.5) (3.5) (3.5) (3.5)
0.30 0.30 0.30 0.30 0.30 0.30
(3.0) (3.0) (3.0) (3.0) (3.0) (3.0)
N/A N/A N/A 87°C N/A N/A
6°C 6°C 6°C 6°C 6°C 6°C
N/A N/A 6°C N/A N/A N/A
End of Life
Non Eu Countries
At the end of this products life, please ensure that it is disposed of in an
environmentally friendly manner which is in line with your Country requirements/
guidelines.
WEEE (Eu ONLY)
Please be aware that our products are covered by the Waste Electrical and Electronic
(WEEE) directive (2002/96/EC). The symbol shown above denotes that the product
should not be disposed of with general/household waste. Please contact your sup-
plier/service agent who will arrange for the collection and disposal of this product.
ROHS
All Waterlogic machines comply with EC Directive (2002/95/EC) on the Restriction
of the Use of Certain Hazardous Substances in Electrical and Electrical Equipment
(RoHS).
BIOCOTE® (ANTI-MICROBIAL SOLuTION)
For your added protection this product incorporates BioCote® antimicrobial tech-
nology. Silver, in the form of silver ions, is the active ingredient utilised in BioCote®.
This silver technology is manufactured into the surface of our products, giving them
built-in sustainable antimicrobial protection.
BioCote's silver technology has been tested by an independent laboratory to show
its ability to inhibit the growth of bacteria, mould and fungi by up to 99.9% over a 24
hour period and for the duration of the machine life.
FREQuENTLY ASKED QuESTIONS ABOuT BIOCOTE®:
Why use BioCote®? BioCote® will help reduce the risk of cross-contamination. You
may not want to think about it, but every surface in the working environment is a
potential breeding ground for Bacteria.
How is it applied? BioCote® is applied via an additive into the manufacturing proc-
ess and will, therefore, be present throughout the moulded or painted parts.
How long will BioCote® last? BioCote® will last for the usual life expectancy of
your water dispenser. It will not wear or wash out with use or cleaning.
What bacteria is BioCote® effective against? BioCote® is effective against most
common bacteria, moulds and fungi.
PLEASE NOTE:
BioCote® is an additional line of defence to protect between cleaning routines,
it is not a replacement for your normal cleaning and sanitisation processes.
Waterlogic 4 Firewall Technical Manual - Issue A, October 2010
