Note that when this option is used, in order to read Syslog messages with Wireshark, a
special plug-in (i.e., acsyslog.dll) must be used. Once the plug-in is installed, the Syslog
messages are decoded as "AC SYSLOG" and are dispalyed using the „acsyslog‟
filter instead of the regular „syslog‟ filter.
Notes:
This parameter is typically set to 5 if debug traces are required.
However, in cases of heavy traffic, option 7 is recommended.
Options 2, 3, 4, and 6 are not recommended.
When working with the Gateway Debug Level, be sure to return the setting to
DISABLED. The volume of syslog messaging in Debug Mode can affect call processing
at high levels of traffic.
GwDebugLevel = 0
Syslog fields at a Glance
Local PC time
Gateway IP
Source of log on gateway.
Figure 14 - Syslog fields at a glance (Debug Mode 5)
3.3

Debug Recording Overview

AudioCodes TP Board Debug Recording traces are a powerful debugging tool that
provides ability to capture traffic being handled by a specific Media Gateway board.
Verizon T.38 FAX Configuration Guide for AudioCodes MP-11x
Version 1.0
Source
Address
Page 21
Log counter increments by '1' with each
syslog that is generated. Resets when
gateway is reset
Object identifier
Type of log: NOTICE, ERROR,
INFORMATION, or WARNING
