  • Page 1 BiPAC 7700N R2 Wireless-N ADSL2+ Firewall Router Quick Start Guide...
  • Page 3 Billion BiPAC 7700N R2 Wireless-N ADSL2+ Firewall Router PLEASE READ THE QUICK START GUIDE AND FOLLOW THE STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE. IF YOU NEED MORE INFORMATION ON THIS SOFTWARE CONFIGURATION, PLEASE REFER TO THE USER MANUAL ON CD-ROM.
  • Page 4 Quick Start Guide The Front LEDs When the system is Flash green when ready, it will be lit WPS configuration green. Lit red when the is in progress. device fails to boot. Lit green when a Lit red when WAN port fails to Lit green when successfully Lit green when the wireless connection...
  • Page 5 Billion BiPAC 7700N R2 Wireless-N ADSL2+ Firewall Router The Rear Ports Connect the supplied Push WPS button Power Connect it with the RJ-11 cable to this port to trigger Wi-Fi ON/OFF supplied power when connecting to the Protected Setup switch adapter.
  • Page 6 Quick Start Guide 1. Power Connection Plug the supplied power adapter in to the wall jack and the other side to the router. Please note that the plug type may differ according to country. 2. Ethernet Connection Connect the supplied RJ-45 Ethernet cable to one of the Fast Ethernet (LAN) ports, and the other side to the PC’s Ethernet interface.
  • Page 7 Billion BiPAC 7700N R2 Wireless-N ADSL2+ Firewall Router 4. Splitter/ Micro-filter Connection The Splitter / Micro-filter are important for ADSL installation, they help direct high-frequency signals to the ADSL modem & low frequency signals to the telephone or other analogue device to prevent inter-modulation distortion & get good speed/stable ADSL sync rate.
  • Page 8 Basic Support Hotline - (02) 8999 0728 (Basic Support) Helpdesk – http://au.billion.com/helpdesk/ (Lodge a support ticket) Billion Support Forums – http://au.billion.com/forums (Get help & suggestions from Billion & other users) Download site - http://au.billion.com/product/fd.php (Download latest firmware, drivers & User Guides) BiPAC 7700N R2: V1.00AU...
