AOpen MODT Flex i945GTt-VFA Easy Installation Manual page 7

1
BIOS Setup when 1st Power On
After finish the setting of jumpers and connect
Del
correct cables. Power on and enter the BIOS
Setup,
<Del> during POST
(Power On Self Test).
Choose
Optimized Defaults" for
recommended optimal
performance.
2 Drive Installation
After you install window XP, please insert AOpen
Bonus CD to start on Driver installation
After you insert AOpen Bonus CD, it will automatically
show below "Ezinstall' screen.
Click to install
Install
online manual
driver
Install
utility
Browse CD
Contents
Readme
Exit CD
Use "mouse pointer" to Tab "Install
Driver", then click left button of mouse
on it. Ezinstall will have "Install Driver"
page come out as below
Please check the items of
then press
driver which it shows. In
default, it will select all
necessary driver in the
"Load
list. After check, please
use "mouse pointer" to
click button "GO".
The "Ezinstall" will take you minutes on install driver
for you. Do not click other functions during the
process of driver
installation. While
complete driver
installation. It will
automatically
show "Reboot".
Please choose button "YES". System will reboot and
enter window O.S. Below is "window device Manager",
you can check driver are installed properly.
AOpen
branches
information
EX. i945GTt-VFA device manager picture
Model Name and BIOS Version
Model name and BIOS version can be found on upper
left corner of first boot screen (POST screen). For
example:
Phoenix - AwardBIOS v6.00PG, An Energy Star Ally
Copyright (C) 2004, Phoenix Technologies, LTD.
i945GTt-VFA R1.01 Feb. 09. 2006 AOpen Inc.
i945GTt-VFA is model name of motherboard;
R1.01 is BIOS version
Register Your Motherboard
Thanks for choosing AOpen product, please take time
to register the product
http://club.aopen.com.tw/productreg/
ensure that you can receive the most updated
information from AOpen in the future. Please prepare
the following information before you start: Model
Name, Part Number (P/N), Serial Number (S/N)
and Purchase Date. The Part Number and Serial
Number are printed on the bar code label. You can
find this bar code label on the outside packing or on
component side of PCB. For example:
Part No. Serial No.
P/N: 91.88110.201 is part number,
S/N: 91949378KN73 is serial number.
Phoenix-Award BIOS Error Message
Beep Sound Message
1 short (Beep) System booting is normally.
1 long - 1 short (Beep) DRAM error
Display Card connected error
1 long - 2 short (Beep)
Monitor Connected error
1 long - 3 short (Beep) Keyboard error
Long (Beep) continuous DRAM hasn't insert correctly.
registration,
This will
