[MENU] + [MENU] + "INPUT/OUTPUT" + [ENTER] + "VIDEO INPUT" +
[ENTER]
Select Video Input
E
Activate Video Input E
Switching Timeout
E
Restore Defaults E
4.8

C-WEATHER SERVICE

C-Weather Service
ability to visualize the weather forecast, overlaying it on cartography. The weather
data is held on Jeppesen Marine's weather server, which can be accessed via a
C-COM modem connected to the chart plotter or by using the PC Planner (or the
DPS - Dealer Programming System) saving the weather data on a User C-CARD.
The weather format data available are:
Weather Service
To select the menu:
[MENU] + [MENU] + "WEATHER SERVICE" + [ENTER]
It opens a sub-menu with the following options.
User Manual
: Available options are the following: Full Video 1: Shows the image from the video camera
1 at full screen. Full Video 1 + Video 2 Small: Shows the image from the video camera 1
at full screen, with the image from the video camera 2 on a window which can be moved up/
down and/or right/left using the cursor key. Full Video 2: Shows the image from the video
camera 2 at full screen. Full Video 2 + Video 1 Small: Shows the image from the video
camera 2 at full screen, with the image from the video camera 1 on a window which can be
moved up/down and/or right/left using the cursor key. PiP (Picture In Picture) Video 1:
Shows the cartographic image at full screen, with the image from the video camera 1 on a
window which can be moved up/down and/or right/left using the cursor key. PiP (Picture In
Picture) Video 2: Shows the cartographic image at full screen, with the image from the video
camera 2 on a window which can be moved up/down and/or right/left using the cursor key.
Auto Switch Video 1 / Video 2: Shows the image from the video camera 1 and from the video
camera 2 at full screen alternately, after time selected in the "Switching Timeout" item (see
below). None.
: Activates Video Input from menu. At the activation of the Video Mode the following messages
are shown on a dedicated window: "Connnected Video Input Signal is XXXX. The Video
Mode will be activated". XXXX can be PAL or NTSC: the software automatically detects the
type of Video Input source connected. Once the Video Mode is active use the following keys
to adjust video settings: press [POWER] and move the cursor to adjust the contrast and
backlight, press [ZOOM IN]/[ZOMM OUT] to adjust hue phase. Pressing any other key exits
from Video Mode.
: Select the timeout for the Auto Switch option among 5, 10, 30 seconds, 1, 5, 10 minutes.
: Restores default values of Contrast, Brightness, Backlight, color saturation and Hue phase
is an innovative meteorological forecasting system with the
E
Data Type
WIND (Speed & Dir)
WAVE (Height & Dir)
TEMPERATURE (C°)
HUMIDITY (%)
VISIBILITY (m)
WEATHER TYPE: Sun
WEATHER TYPE: Rain
WEATHER TYPE: Fog
WEATHER TYPE: Snow
WEATHER TYPE: Clouds
WEATHER TYPE: Partly Cloudy
WEATHER TYPE: Thunderstorm
Fig. 4.8 - Weather data package
Menu
E
E
Display
0
1
18°
30
20
57
