Press the action button (2) onto which you wish to apply the combo that you have just

programmed.

*You cannot program any actions while the LED is flashing.

**If you do not enter an action within 5 seconds the red LED will flash and the entire procedure will be cancelled.

You can program up to 8 different combos (1 per analog action button (2)).

Programmable controls:

•

Single control (short press on a button): press the button corresponding to the action you require

and then press the COMBO button.

•

Combined control (pressing two buttons at once): press the first button, then press the second

button and finally press the COMBO button.

•

Control equivalent to a long press on a direction: push the stick in the required direction and wait

for 5 seconds. The LED turns yellow and flashes for 2 seconds to indicate that a "long press"

action has been registered. Then press the COMBO button to confirm.

•

Pause: when programming your sequence, press the COMBO button at the point at which you

wish to insert a pause, without programming an action.

•

Stick movement: to program a stick movement, break down the movement and program each

individual movement separately, pressing the COMBO button after each movement.

For example: to enter the

Using a combo:

Press and hold the COMBO button and press the action button onto which you have applied the

combo that you wish to use.

Refer to the example on the following page.

CLEAR FUNCTION

The CLEAR button (10) allows you to return to the default configuration and delete all activated

functions (Turbo, Program, Combo).

4/6

movement:

stick

, COMBO button
