Motorola C601I User Manual

Digital cordless phone.
Hide thumbs

Advertisement

Motorola C6I
Digital Cordless Phone
For C601I, C602I, C603I and C604I
Warning
Charge the handset for 24 hours before use.

Advertisement

   Related Manuals for Motorola C601I

   Summary of Contents for Motorola C601I

  • Page 1

    Motorola C6I Digital Cordless Phone For C601I, C602I, C603I and C604I Warning Charge the handset for 24 hours before use.

  • Page 2

    Welcome... to your new Motorola C6I Digital Cordless Phone! • All handsets are fully cordless for locating anywhere within range. • 50 Name and Number phonebook. • Speakerphone for hands-free conversation. • Caller ID shows you who’s calling and see details of the last 40 callers in a Calls list.* •...

  • Page 3

    This User Guide provides you with all the information you need to get the most from your phone. Before you make your first call, you need to set up your phone. Follow the simple instructions in ‘Getting Started’, on the next few pages.

  • Page 4: Table Of Contents

    1. Getting started ..........6 3.9.3 Delete an entry ........16 3.9.4 Delete the entire Redial list ....16 2. Getting to know your phone ......9 3.10Paging/Find handset ..........16 3. Using the phone..........13 4. Phonebook setting ........17 3.1 Switch the handset on / off ........ 13 4.1 Store a name and number........17 3.2 Calls..............

  • Page 5

    6.7 Emergency default ..........23 6.8 Area code setting ..........23 6.9 Default settings ..........23 7. Clock & alarm ..........24 7.1 Set the date............24 7.2 Set the time ............24 7.3 Set alarm............24 7.4 Switch off alarm ring........... 24 8.

  • Page 6: Getting Started

    1. Getting started The line will hang up if the handset moves out of range of the base. Move closer to the base. The handset will automatically reconnect to the base. WARNING Do not place your C6I in the bathroom or other humid areas. Setting up Location IMPORTANT...

  • Page 7: Connecting The Handset And Charger

    2. Plug the power adaptor with RED connecter into the socket marked on the underside of the base and plug the other end into the mains power wall socket. Switch on the mains power. Installing and charging the handset 1. Remove the battery cover from the back of the handset and insert the 2 x AAA NiMH rechargeble batteries supplied.

  • Page 8

    Set the date manually BATTERY LOW WARNING icon flashes on the display and you hear a warning DATE-TIME 1. Press , scroll and press beep every minute during a call, you will need to recharge DATE SET The display shows the handset before you can use it again.

  • Page 9: Getting To Know Your Phone

    2. Getting to know your phone Earpiece Display See page 10 for an overview of the display icons. Overview of your handset Secrecy / Clear / Back During a call, press to switch Secrecy on/off, page 14. In menu mode, press to return to previous menu or press and hold to return to standby.

  • Page 10: Display Icons

    Display icons Hands-free During a call, press to switch hands-free on and off, page 13. Flashes to indicate an incoming external call Talk / End call Press to make, receive and end calls, page 13. External call in progress # / Keypad lock Press and hold to lock the keypad, page 21.

  • Page 11: Navigating The Menus

    Keypad is locked Paging In standby mode, press to ring the handset(s). Displayed number is longer than 12 digits Press and hold to enter registration mode when registering handsets. The approximate power levels of your battery are indicated as follows: Navigating the menus Your phone has an easy to use menu system.

  • Page 12: Menu Map

    Menu map PHONEBOOK SETUP HANDSET DATE - TIME REGISTER ADD ENTRY BASE VOLUME BEEP DATE SET SELECT BASE MODIFY ENTRY BASE MELODY INT RING VOL CLOCK SET REG BASE DELETE ENTRY DEL HANDSET EXT RING VOL ALARM SET PIN CODE INT MELODY DIAL MODE EXT MELODY...

  • Page 13: Using The Phone

    < 3. Using the phone 2. When finished the conversation, , press the to hang Note NOTE Your handset will automatically time the duration of all < If you prefer to press when you lift up the handset to external calls. The call timer will display after the first 15 answer a call, you will need to switch Auto answer off.

  • Page 14: Answer A Call Hands-free

    Secrecy mode 3.3.2 Answer a call hands-free When the phone rings, press to answer the call. You can mute your handset so that you can talk to someone nearby without your caller hearing. 3.3.3 Switch to hands-free during a call MUTED 1.

  • Page 15: Receive An Internal Call

    3.7.2 Receive an internal call During a call with an external caller: 1. When you receive an internal call, icon flashes and 1. Press followed by the handset number (1-4) that the handset number that is calling you is displayed. you want to establish a conference call.

  • Page 16: Copy A Redial List Number To The Phonebook

    3.10 Paging/Find handset 3.9.2 Copy a Redial list number to the phonebook 1. Press to open the Redial list. You can alert a handset user that they are wanted or locate a missing handset. Paging calls cannot be answered by a 2.

  • Page 17: Phonebook Setting

    4. Phonebook setting 7. Enter the next name and number entry that you wish to store in your phonebook or press to return to You can store up to 50 names and numbers in the standby. phonebook. Names can be up to 16 characters long and ENTERING NAMES number up to 24 digits.

  • Page 18: Edit A Name And Number

    < Delete an entry 2. Scroll to the entry you want. Press to dial or to return to standby. PHONEBOOK 1. Press . The display shows Note 2. Press to select. When the name is displayed, you can switch between the DELETE ENTRY 3.

  • Page 19: Handset Settings

    5. Handset settings 3. Press to select the ringer melody (1 - 10). 4. Press to confirm to return to the previous Handset ringer volume menu. You can adjust the ring volume and set different volume Note levels for your internal and external calls. Choose from 5 Calls from the numbers that you have stored in the volume levels or Off.

  • Page 20: Language

    Battery low warning beep 3. Enter the new handset name and press to confirm. Note When the battery is almost fully discharged, you will hear a The handset name will only be displayed for approximately warning beep every minute during a call. You can switch these beeps on or off.

  • Page 21: Keypad Lock/unlock

    6. Base settings Keypad lock/unlock You can use the menu to lock the keypad. Base ringer volume HANDSET 1. Press , scroll and press Choose from 5 volume levels or Off. KEYLOCK ? 2. Scroll and press to confirm. SETUP 1.

  • Page 22: Change Base Pin Code

    Change base PIN code Flash setting Some functions are protected by a 4 digit PIN code which Depending on your country and network operator, your must be entered if you want to change the settings. The phone has the flash time set as 600 ms (FLASH 2). It is default PIN is 0000.

  • Page 23: Emergency Default

    3. Enter the 4 digit PIN code (default = 0000) and press The handset will filter the local area code (set by user) while receiving or calling back the local number. CONFIRM? . The display shows 4. Press to confirm or to return to the previous Default settings menu.

  • Page 24: Clock & Alarm

    7. Clock & alarm 3. Press to select and press confirm. If you have subscribed to Caller Display service, the date 4. If you select , enter the time in 24 hour format (e.g. and time will be set on all your handsets whenever a call is 07--30 for 7:30am) and press to confirm.

  • Page 25: Caller Display And The Calls List

    8. Caller Display and the Calls list Caller Display If you have subscribed to a Caller Display Service, you will IMPORTANT be able to see your caller’s number on your handset To use Caller Display, you must first subscribe to the service (provided it is not withheld) prior to answering the call.

  • Page 26: View The Calls List

    8.2.1 View the Calls list 8.2.3 Add "0" during call back 1. Press to open the Calls list. If there are no calls in the 1. Make sure the phone is off (Not in talk mode). EMPTY list, the display shows 2.

  • Page 27: Delete An Entry

    9. Using additional handsets 7. Press to select the ringer melody you want and press . The number is stored. You can register up to four handsets to your base to extend NOTE your phone system without having to install extension See “ENTERING NAMES”...

  • Page 28: Select A Base

    REGISTER 3. Enter the base number (1 - 4). The base numbers that 1. Press , scroll and press . The SELECT BASE are already in use flashes. The display shows display shows SEARCHING... 2. Press . All the bases that your handset has been BASE 1 2 3 4 4.

  • Page 29: Help

    10. Help icon is not scrolling during charge • Adjust the handset slightly on the base. No dial tone • Clean the charging contacts with a cloth moistened with • Use only the telephone line cord supplied. alcohol. • Check that the telephone line cord is connected properly. •...

  • Page 30: General Information

    11. General information Handset does not ring • The handset ringer volume may be set to Off. IMPORTANT Base unit does not ring This equipment is not designed to make emergency telephone • The base ringer volume may be set to Off. calls when the power fails.

  • Page 31: Installation Guidelines

    Installation Guidelines 6. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a 1. Read and understand all instructions and save them for damp cloth for cleaning. future reference. 7. Do not disassemble this product. If service or repair 2.

  • Page 32: Battery Safety Instructions

    10. To avoid interference to nearby appliances, do not place • Never use household polish as this will damage the the base of the phone on or near a TV, microwave oven, product. Never use a dry cloth as this may cause static or VCR.

  • Page 33

    LIMITATION THE IMPLIED WARRANTIES OF Warranty MERCHANTABILITY AND FITNESS FOR A PARTICULAR Thank you for purchasing this Motorola branded product PURPOSE, SHALL BE LIMITED TO THE DURATION OF manufactured under license by Suncorp Technologies THIS LIMITED WARRANTY, OTHERWISE THE REPAIR OR...

  • Page 34

    Unauthorized Service or Modification. Defects or damages resulting from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than Motorola, SUNCORP or its authorized service centers, are excluded from coverage. General information...

  • Page 35: Technical Information

    All items of telephone equipment have a Ringer Equivalence tampering; (c) mismatched board serial numbers; or (d) Number (REN), which is used to calculate the number of nonconforming or non-Motorola branded housings, or parts, items which may be connected to any one telephone line. are excluded from coverage.

  • Page 36

    Manufactured, distributed or sold by Suncorp Technologies Ltd. , official licensee for this product. MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their respective owners. © 2011 Motorola Mobility, Inc.
