Summary of Contents for Precor Experience Strength
- Page 1 General Safety & Maintenance Manual Precor Experience Strength Precor Icarian Strength...
-
Page 3: Important Safety Guidelines
• Make sure that the equipment is installed with enough free space for safe operation. With most equipment, the general • Precor designs all commercial strength equipment for use in rule is to allow about a 4-foot (1.2 meters) circle of space from fitness facilities where regular maintenance is performed by the user’s center. -
Page 4: Safety Approval
EN957 –1/2 standards. See an authorized use the equipment until it is working properly. Precor dealer for a complete and current listing of certified • When working with the weight stacks, do not attempt to free machines. -
Page 5: Safety Information For Users
Safety Information for Users • Keep head, limbs, fingers, and hair clear of all moving parts while the equipment is in use. Keep hands clear of racking Before beginning any fitness program, you should obtain a pegs. complete physical examination from your physician. •... -
Page 6: Table Of Contents
Table of Contents Important Safety Guidelines ..........1 Monthly Inspection ............18 Safety Approval ..............2 Inspect Frames and Movement Arms ......18 Safety Information for Users ..........3 Lubricate Pop Pins ............19 Check and Lubricate Ratcheting Seat Lever ....19 Before You Begin .............. -
Page 7: Before You Begin
For information on how to use a piece of maintenance technicians as outlined in this manual. equipment, refer to the instructional label found on the equipment. This manual explains how to maintain the Precor Icarian line of commercial strength equipment. It provides information about Recommended Tools... -
Page 8: Shroud Removal
Perform the necessary maintenance. When you are finished, replace the shroud. The Experience Strength product line includes a shroud that must 4. Attach the Upper Back Shroud first, aligning the tabs at the be removed to perform the maintenance described in this manual. -
Page 9: Obtaining Service
Precor Customer Model #: _______ Serial #: _______________________ Support. Precor uses the serial number in order to establish the model and year of the product. You can generally find the serial Date purchased: _________________________ number underneath the seat support. -
Page 10: Daily Inspection
Daily Inspection Inspect Pads for Wear You will need to do the following tasks each day to maintain the equipment and keep it operating smoothly. Each of these tasks is Inspect pads for cracks in the upholstery, loose staples, and loose covered in this section. -
Page 11: Inspect Cables And End Connections
CAUTION: Carefully inspect the cables, pulleys, fasteners, and related hardware regularly. Replace any cable at the first sign of wear using only Precor-supplied replacement parts. With regular use, a cable can become worn and might fail. Sudden failure of a Obtaining worn cable can cause severe injury to a user. -
Page 12: Check Warning And Instructional Labels
Inspect warning and instructional labels daily to make sure that all the information can be clearly read. If any portion is not visible or part of the label is not adhered properly, replace that label Figure 4: Sample user instructional label for the Experience Strength Obtaining Service immediately (refer to for purchase information). - Page 13 Precor products come equipped with a number of standard warning labels. Figures 6 and 7 show sample warning labels you may see on the equipment depending on the model and product line: Warning PULLDOWN 304 Select appropriate lifting weight. Adjust thigh pad to rest securely on top of legs.
- Page 14 Warning Improper use of this equipment can result in serious injury. Even with proper use, you assume a risk of injury when using this type of equipment. • Before beginning a fitness program, see your physician for a thorough physical examination.
-
Page 15: Weekly Inspection
Weekly Inspection Clean and Lubricate Cable Rod Ends This section covers the tasks you should do each week to maintain the equipment. Choose the appropriate tasks for your equipment, Check cable rod ends to make sure the shoulder bolt is secure. If depending on what you are maintaining: cable rod ends are noisy, you can lubricate them with a silicone •... -
Page 16: Clean And Lubricate Guide Rods
Clean and Lubricate Guide Rods Inspect Cables, Connections, and Tension Inspect the exposed areas of the guide rods for cleanliness. Using a Each week give the cables and connections a thorough inspection dry cloth, wipe any buildup of dirt or grease from the rods. and check cable tensions. -
Page 17: Inspect Cable Handle Attachments
Inspect Cable Handle Attachments Inspect Pulleys Check the cable-to-handle attachment area very closely. (Refer to Precor uses precision ball bearing idler pulleys to smoothly guide Figure 9.) Look for frayed cable ends, broken thimbles, bent cables, the cable. worn spring clips, worn handles, and any other unusual wear. -
Page 18: Inspect And Lubricate Bearings And Bushings
Wipe down linear rails using a light application of a silicon spray • Bronze bushings: Precor recommends using a small amount of lubricant to remove dust, hair, and dirt. Polish the shaft using fine silicone spray lubricant to lubricate the bushings. -
Page 19: Check Seat Adjustment And Test Pop Pins
Check Seat Adjustment and Test Pop Pins Precor strength equipment has three types of adjustments: • 2x4-inch or 2x2-inch telescoping sleeve adjustment for most seat assemblies with and without ratcheting mechanism • ½-inch slotted plate adjustments used on most free-weight bench adjustments •... -
Page 20: Monthly Inspection
To remove surface rust from the frame, rub lightly with a fine wet/ the equipment. Choose the appropriate tasks based on what you dry sand paper or fine steel wool. Finish with Precor’s touch-up are maintaining. paint if needed. Maintain paint luster with an application of a mild automotive wax product. -
Page 21: Lubricate Pop Pins
Pull out the pop pin as far as it goes and apply a small amount of silicone spray lubricant. Wipe off any excess lubricant with a rag. Precor designed the ratcheting seat so users can easily move the (Refer to Figure 12.) seat to a comfortable position. -
Page 22: Inspect All Fasteners
Inspect All Fasteners Precor products are assembled with Grade 5 fasteners or better. With normal use, these fasteners can loosen. Inspect all nuts, bolts, hex key bolts, screws, and other fasteners to make sure they are tight and installed correctly. -
Page 23: Annual Maintenance
To avoid injury, keep your hands and head away from moving parts. Once a year, Precor recommends disassembling the weight stack to thoroughly clean and inspect it. Inspect the plunger and spring for excessive wear and damage, and replace as required. -
Page 24: Limited Warranty
PRECOR at the address set forth on the back cover of such defect, admit exclusions may not apply to all Customers. This warranty gives Customers specific PRECOR authorized service representatives during normal business hours to legal rights;... - Page 25 Notes: General Safety and Maintenance Manual: Notes...
- Page 26 Notes: General Safety and Maintenance Manual: Notes...
- Page 28 U.S. and foreign patents for both the mechanical construction and the visual aspects P.O. Box 7202 of its product design. Any party contemplating the use of Precor product designs is hereby forewarned General Safety & Maintenance Manual CW31972-106, en Woodinville, WA USA 98072-4002 that Precor considers the unauthorized appropriation of its proprietary rights to be a very serious matter.
