- Page 1 ™ AquaPro Instructions for use and parts list Advance MODEL 56102802 ™ 06/03 revised 8/08 Form Number 56041559 FORM NO.56041559 / AquaPro XP - 1...
-
Page 2: Parts And Service
INTRODUCTION This manual will help you get the most from your Advance AquaPro XP. Read thoroughly before operating the machine. NOTE: Bold numbers in parenthesis indicate an item illustrated on page 7. This product is intended for commercial use only. PARTS AND SERVICE Repairs, when required, should be performed by your authorized Advance Service Center, who employs factory-trained service personnel, and maintains an inventory of Advance original... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using an electrical appliance, basic precautions should always be followed, including the following: Read all instructions before using this appliance WARNING! -
Page 4: Consignes De Securite Importantes
CONSIGNES DE SECURITE IMPORTANTES Cette machine ne convient qu´à un usage industriel, par exemple dans des hôtels, écoles, hôpitaux, usines, boutiques et bureaux et autres à l´exclusion de tout usage de maintenance résidentielle normale. L’utilisation d’un appareil électrique demande certaines précautions: LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CET APPAREIL) AVERTISSEMENT! Pour réduire les risques d’incendie, de choc électrique ou de blessure:... -
Page 5: 120Vac Grounding Instructions
120VAC GROUNDING INSTRUCTIONS This appliance must be grounded. If it should electrically malfunction, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 6: Instructions Visant La Mise À La Terre (120Vac)
INSTRUCTIONS VISANT LA MISE À LA TERRE (120VAC) Cet appareil doit être mis à la terre. En cas de défaillance ou de panne éventuelles, la mise a la terre fournit au courant un chemin de moindre résistance qui réduit le risque de choc électrique. Cet appareil est pourvu d’un cordon muni d’un conducteur de terre et d’une fiche avec broche de terre. -
Page 7: Know Your Machine Descriptions
KNOW YOUR MACHINE KNOW YOUR MACHINE DESCRIPTIONS Operator Handle (1) - Operator holds this to move the machine from one location to another. Lift Handle (2) - Operator grasps this handle when lifting the machine. Solution Tank Lid (3) - Fill Solution Tank here with warm water and chemicals. Recovery Tank Lid (4) - The Recovery Tank can be flushed out by running clean water into this opening with the Recovery Tank Drain Hose open. - Page 8 SWITCH PLATE DESCRIPTIONS Locator Light (1) - This green light will turn on when the two power cords are plugged into separate circuits. Separate circuits are defined as outlets fed by circuit breakers on opposite sides of the circuit breaker panel. This feature helps to prevent blown breakers. When the locator light (1) turns on, the heat exchanger will automatically turn on.
-
Page 9: Wiring Diagram
WIRING DIAGRAM White Power Cord #1 Line 1 15V VAC 1 PUMP SOLENOID Black Dual Cord Power Sensor Board Black Cord #2 Black White P2 P5 1 15V White Thermal Fuse Black Black • Thermostat “LOCATOR” LIGHT “MODE” LIGHT Black FORM NO.56041559 / AquaPro ™... -
Page 10: Operation
OPERATION Inspect the machine, hoses, and cleaning tools for cleanliness and completeness. Fill the solution tank with water. Using warm water may be a benefit in cleaning effectiveness, but do not use hot water (above 140 F / 60 C) in the tank. °... -
Page 11: Maintenance Schedule
USE AND MAINTENANCE Use only liquid chemicals with a pH between 6 and 9 at the recommended mix ratios. Improper chemicals, or improperly mixed chemcials, can cause possible damage to the pump, seals, and other components. Turn the pump “off” when the solution tank is low on fluid. Do not let the pump run dry. Regularly clean any mineral or chemical deposits in the heat exchanger, lines and pump with a mild acid descaler. - Page 12 12 - FORM NO. 56041559 / AquaPro ™...
- Page 13 PART LIST AquaPro Item Ref. No. Qty Description 56102809 Solution Tank, Light Gray 56108024 Priming Hose, 3/8” x 54” 56102808 Recovery Tank, Light Gray 56108061 Vac Inlet Hose Barb 56102823 Gasket (Hardware Kit) 56108055 Lid, 6”, Clear Center, W/Ring 56108054 Chain, 8”...
- Page 14 14 - FORM NO. 56041559 / AquaPro ™...
-
Page 15: Part List
PART LIST AquaPro XP (continued) Item Ref. No. Qty Description 56102823 Screw, #4 x .38 (Hardware Kit) (Hardware Kit) (Hardware Kit) (Hardware Kit) (Hardware Kit) 56102863 Light, Green, 120V 56102827 Switch, SPST, W/Cover 56102828 Switch, DPDT, W/Cover 56102843 Handle, Chrome 56102823 Screw, 1/4-20 x .75, Flat Head (Hardware Kit) (Hardware Kit) - Page 16 16 - FORM NO. 56041559 / AquaPro ™ revised 8/08...
- Page 20 14600 21st Avenue North Plymouth, MN 55447-3408 www.advance-us.com Phone: 800-989-2235 Fax: 800-989-6566 ©2010 Nilfi sk-Advance, Inc. A Nilfi sk-Advance Brand...
