be used to "jump" back to the previous channel.
Cat. (<, >) Buttons: Enters Category List Mode
and moves from category to category.
Preset Number Buttons, 1-6: Sets and selects
preset channels.
14
Control Knob: Turn to change channels or move
around in menus.
• Press to make selections in menus and lists
• Press and Hold for about 2 seconds to go back
to a previous channel.

Remote Control Functions

Power ( ) Key: Turns Here
Everywhere off and on.
2
Select Key: Used to select items in a list after
navigating the list with CH Up and Down Keys.
CAT (<, >) Keys: Enters Category List Mode and
moves from category to category.
CH Up and Down Keys: Moves up and down one
channel (in Channel Seek mode), or one preset
(in Preset Seek mode).
Mute Key: Turns off the audio of Here
Everywhere.
2
Display Key: Switches the display between different
modes, with artist and song title information displayed
in various sizes.
Jump Key: "Jumps" over to a special stored channel,
such as a local traffic channel; then can be used
Power
Cat.<
Select
Ch
Cat.>
Mute
Jump
Number Keys
Display
Direct
Preset
Band
P. Tune
Back
Memo
List
to "jump" back to the previous channel.
Number Keys: Numbers 1-6 select preset channels
in the currently selected band. Numbers 0-9 are
used with the Direct button to tune directly to a
specific channel number.
Direct Key: Enters Direct Tuning Mode.
Preset Key: When followed by Number Key 1-6,
stores the current channel as preset 1-6 in the
current bank.
Band Key: Cycles through the 5 banks of presets.
List Key: Enters and cycles between several list
Modes: Channel, Artist, and Song Title.
Ch
P. Tune Key: Switches back and forth between
Preset Tune Mode and Channel Tune Mode.
Back Key: Return to the most recently tuned
channel (previous channel).
Memo Key: Saves song and artist information.
Installing Batteries
in the Remote
Note: Do not expose the remote control to high
temperatures or direct sunlight. This could damage
or deform the case and result in battery leakage
or other harm.
1. Remove the battery cover as shown on the left.
2. Install two AAA batteries as shown on the right.
3. Replace the battery cover.
Activating Your SIRIUS
Subscription
Before you can listen to Here
Everywhere, you must
2
subscribe to SIRIUS Satellite Radio's service.
Note: You can activate your SIRIUS subscription
from either the car docking cradle or from the
home docking cradle. Once it is activated in one, it
will work in the other, provided the antenna has a
clear view to the sky.
Follow these steps to activate your service:
1. Make sure that Here
Everywhere is properly
2
connected and that its antenna is oriented to
receive the SIRIUS satellite signal (see Installation
sections for details).
2. Place Here
Everywhere in the docking station by
2
sliding the unit all the way into the cradle so that
the connector at the bottom of the unit makes
proper contact in the cradle.
3. Press the power button to turn Here
Everywhere
2
on. After displaying the SIRIUS logo, the display
will read "Acquiring Signal. " Once the SIRIUS
satellite signal is received, the display will
change to "Call 888-539-SIRIUS to Subscribe. "
15
