Do not use hard cloths or paint thinner, alcohol, or
other volatile solvents to clean the unit. These may
cause damage or remove indicator characters.
Warning
!
Do not operate the unit in a way that might divert
6
your attention from driving safely. As a driver, you
alone are responsible for safely operating your
vehicle in accordance with traffic safety laws at
all times.

Installation in a Vehicle

Note: Do not put Here
Everywhere in the Car
2
Docking Cradle until you have completed the
cradle installation.
Step 1: Placing the Base
and Cradle
First, determine where you want to mount
Here
Everywhere.
2
There are two options for installing the
Here
Everywhere. Select the option and location
2
that provides good visibility of and access to
Here
Everywhere's front panel while maintaining
2
a safe driving experience.
Suction cup base
Button
Lever
Base nut
Pivot (where the
Cradle attaches)
Pivot
ANT
DC 12V
AUDIO OUT
FM OUT
Power
Audio Output
FM Out (optional) Antenna Input
Option 1: Windshield Mount
• Do not install Here
Everywhere on the windshield
2
if it may obstruct your view while driving.
• Attach the Car Docking Cradle to the Car
Windshield Docking Base using the four
enclosed screws.
• Loosen the base nut on the Car Windshield Docking
Base so that the suction cup portion rotates easily.
Do not remove the base nut entirely.
• Make sure the suction cup lever is in the up
position.
• Position the suction cup base
on the desired windshield
location. The word "PRESS"
should be upright.
• Press the button marked
"PRESS" while the suction
cup is on the windshield.
Then rotate the lever
down, keeping the button
pressed down at the
same time.
• The suction cup base
should be firmly
attached to the
windshield.
Note: To remove the Car Windshield Docking Base,
return the lever to the up position before attempting
to remove the Base.
Option 2: Console
(Professional) Mount
Ask the dealer where you purchased your
Here
Everywhere about professional installation
2
options. One option is to have the dealer mount
the Pivot of the Car Windshield Docking Base to
the console or other available location in the vehicle.
There are four screws to remove. The Pivot screw
holes match the AMPS standard for mounting
systems, so any AMPS-compatible bracket for your
vehicle will accept the Pivot of the Docking Base.
Many car audio dealers carry these brackets.
If you choose to do the console mount yourself,
please observe the following guidelines:
7
