3. Route the cable from
the lowest point of
the rear window into
the trunk. Take
advantage of any
existing cable
10
channels or wiring
conduits.
For SUVs, Minivans & 5-door Vehicles: Bring the
cable into the vehicle under the rubber molding for
the tailgate, and continue under the interior trim.
4. From the trunk, route the cable around the
passenger compartment and to the back of
the cradle.
• Do not pull the cable across sharp edges
that could damage it.
• Keep the cable away from areas where
it could become tangled in driver's or
passengers' feet.
5. Plug the antenna into the
back of the cradle (right).
DC 12V
AUDIO OUT
Note: KENWOOD RECOMMENDS UNPLUGGING THE
CIGARETTE LIGHTER ADAPTER AFTER YOU TURN OFF
THE VEHICLE'S IGNITION. (In some vehicles, the
cigarette lighter remains active after the ignition
has been turned off, and leaving Here
cigarette lighter adapter plugged into the cigarette
lighter could drain the vehicle's battery.)
6. Confirm that the antenna is mounted in a
good location.
• Make sure the vehicle is not in a garage
or somewhere the satellite signal could
be blocked.
• Slide Here
Everywhere all the way into the cradle
2
so that the connector at the bottom of the unit
makes proper contact in the cradle. Press the
power ( ) button to turn Here
2
• If your Here
Everywhere has been properly
2
connected and the antenna is receiving the
SIRIUS signal (Preview Channel #184), you
will hear audio. If you do not hear audio, the
display will read "Acquiring Signal. " Re-orient
the antenna until you hear audio. (See Antenna
ANT
FM OUT
Aiming, on page 27 to use the ANTENNA
SIGNAL screen to aim the antenna.)

Installation in a Home

Note: Do not put the Here
Home Docking Station until you have completed
Everywhere's
the installation.
2
1. Plug the audio cable's mini connector into the
back of the cradle, as shown.
AUDIO OUT
DC 12V
3. Plug the AC cord into the power supply, then plug
the power supply into the back of the cradle, as
shown. Don't plug the AC cord into a wall outlet
Everywhere on.
until the installation is completed.
4. Plug the antenna into the back of the cradle
until it is firmly seated, as shown.
AUDIO OUT
DC 12V
Finding a Location
for the Antenna
Everywhere in the
2
Due to the paths of the SIRIUS satellites over the
U.S., the best location for the antenna will depend
on what part of the country you live in, the orientation
of your home, and the locations of any obstructions
2. Plug the audio
that could prevent the satellite signal from reaching
cable's white (L ch.)
the antenna. The best antenna location is on the
ANT
and red (R ch.)
roof, facing straight up (see below).
connectors into your
• The location of the "X" on the map on pg. 13
audio system's avail-
must be visible to the antenna.
able audio input.
ANT
ANT
AUDIO OUT
DC 12V
11
