6
DSC OPERATION
DSC Set mode (Continued)
D NMEA Output
Select an NMEA Output function. When receiving a position
acknowledgment, the transceiver outputs it to external equip-
ment through the NMEA connector.
q Enter "NMEA Output" in the DSC Set up menu.
DSC Menu
(Push [MENU])
w Rotate [DIAL] to select the NMEA Output function from
List Station, All Station or OFF.
listed on the DSC individual ID screen.
Outputs no position data to the external equipment.
--DSC Menu--

NMEA Output

˘List Station
All Station
OFF
<CLR˘Exit / ENT ˘ OK>
e Push
menu.
[CLR] to cancel and return to the DSC Set up menu.
r Push [CLR], or rotate [DIAL] to select "Exit" then push
, to return to the DSC menu.
r again to return to the normal operating mode
46
Set up NMEA Output
(Rotate [DIAL], then push
(Default: List Station)
to set and return to the DSC Set up
D Auto Switch function
By regulation, after receiving a Distress call, the transceiver
switches the operating channel to Channel 16. However,
when this setting is set to "OFF," the function enables the
transceiver to remain on the operating channel, even after
receiving a Distress call.
.) q Enter "Auto SW" in the DSC Set up menu.
DSC Menu
(Push [MENU])
w Rotate [DIAL] to turn the Auto switch "ON" or "OFF."
ON : After receiving a Distress call, the transceiver automati-
cally switches the operating channel to Channel 16.
OFF : Even after receiving a Distress call, the transceiver
remains on the operating channel.
--DSC Menu--
Auto SW
ON
˘OFF
<CLR˘Exit / ENT ˘ OK>
e Push
[CLR] to cancel and return to the DSC Set up menu.
r Push [CLR], or rotate [DIAL] to select "Exit" then push
, to return to the DSC menu.
r again to return to the normal operating mode
Set up Auto SW
(Rotate [DIAL], then push
(Default: OFF)
to set and return to the DSC Set up menu.
.)
