- Page 1 BEETLE /X plus Modular POS System User Manual...
- Page 2 Please send us a copy of this page if you have any constructive criticism. We would like to thank you in advance for your comments. With kind regards, Your opinion: Wincor Nixdorf International GmbH Technical Documentation RD HWD01 Wohlrabedamm 31 D-13629 Berlin E-Mail: retail.documentation@wincor-nixdorf.com...
- Page 3 BEETLE /X plus Modulare POS System User Manual Edition September 2012...
- Page 4 All brand and product names mentioned in this document are trademarks of their respective owners. Copyright © Wincor Nixdorf International GmbH, 2012 The reproduction, transmission or use of this document or its contents is not permitted without express authority. Offenders will be liable for damages.
-
Page 5: Table Of Contents
Power Supply ....................15 Power Connector ..................16 System Unit ....................17 BEETLE /X plus with a J1- Motherboard ..........17 RJ10/RMT Jack (optional) ............... 18 D- Sub Plug (COM1) ................18 D- Sub- Jack Power Supplied (COM2*-COM4*) ........18 DisplayPort (DP) .................. - Page 6 USB (Universal Serial Bus)- A ..............19 RJ45 (LAN) ....................19 Jack Plug 3.5 mm (IN/OUT/MIC) ............. 20 RJ12 (CASHDR) ..................20 Disconnecting Cables ................21 Storage Media ..................23 Change Of the Hard Disk Drive ..............23 RAM Modul .................... 28 USB- Hub (optional) ................
-
Page 7: Manufacturer's Certification
Therefore, you will find the CE mark on the device or packaging. Tested Safety The POS system BEETLE /X plus has been provided with the symbol for “Tested Safety”. In addition, the BEETLE /X plus has received the UL symbol and cUL symbol. -
Page 8: Safety Notes
Expansion cards with electrostatically sensitive devices (ESD) can be marked with this sticker. Important Notes The modular POS system BEETLE /X plus conforms to the current safety standards for data processing equipment. If this device is taken from a cold environment into the operating ... - Page 9 In case of an improper change of the lithium battery it exist an explosion risk. Your BEETLE system is the result of modern technical innovation. So please see for according structural and technical surroundings to guar- antee a faultless and efficient work of your BEETLE.
-
Page 10: Introduction
Powerful processors ensure a quick processing of all operations. You can connect a variety of different peripheral devices to your BEETLE /X plus and even the choice of the software is not limited to a cer- tain product. This provides you with a considerable degree of flexibility when arranging the configuration of your POS system. -
Page 11: Care Of Beetle /X Plus
Recycling Center, which is certified pursuant to ISO 9001 and ISO 14001. So don’t discard your BEETLE /X plus system on the garbage when it has served its time, but take advantage of the environmentally smart, up-to-... -
Page 12: Warranty
All parts of the product which are subject to wear and tear are not includ- ed in the warranty engagement. For detailed warranty arrangements please consult your contract documents. Please order spare parts at the Wincor Nixdorf customer service. BEETLE /X plus User Manual... -
Page 13: Before Switching On The System
Transport the device only in its original packaging (to protect it against impact and shock). Setting Up the Device Set up the BEETLE /X plus system where it will not be exposed to extreme environmental conditions. Protect the device from vibrations, dust, moisture, heat and strong magnetic fields. -
Page 14: Horizontal Installation
40 °C (104 °F). 70 mm 60 mm 20 mm 50 mm 50 mm Mind the following minimum distances for the power supply: 60 mm 60 mm 60 mm 60 mm approx. 60 mm BEETLE /X plus User Manual... -
Page 15: Vertical Installation Of The Equipment
Type Label 4 Rubber Feet If the BEETLE /X plus is to be installed with a HDD in vertical position the right hand side of the system must be on top. For specification see page 37. The BEETLE /X plus is designed for horizontal and vertical installation. -
Page 16: Cabling Of The Beetle /X Plus
Make sure that all data cables at the system unit and the peripherals are correctly plugged. Plug one end of the DC cable into the socket of the BEETLE /X plus and the other end to the socket of the external power supply. - Page 17 Power Out to the POS System The power supply can be connected to all conventional power supply net- works. It automatically adjusts itself to the particular voltage. For the speci- fied ratings see page 35, »Technical Data«. BEETLE /X plus User Manual...
-
Page 18: Pos System Beetle /X Plus
POS System BEETLE /X plus Front Side View 2 USB Interfaces Power Button HDD/SSD Power- LED Ventilation Slots (do not cover) USB (Universal Serial Bus)- A, USB 2.0 You can connect several USB peripheral devices to the USB or powered USB interface (12V or 24V). -
Page 19: Power Button
LED flashes orange HDD/SSD HDD/SSD lower LED lights orange hibernation, shut down POWER lower LED lights green the device is switched on lower LED flashes green stand by mode BEETLE /X plus User Manual... -
Page 20: Interior View
Cooling element for the processor Carrier for Riser Card (for example PCI) Carrier for 2.5” Hard Disk or Solid State Disk Power Button (Standard) Power Button (optional in place of Standard) BEETLE /X plus User Manual... -
Page 21: Connector Panels
DC Power Out, Current Supply to BEETLE /X plus Status LED At the front side of the BEETLE you will find the Power button which will only turn on the system, when the external power supply is connected to the main power and the DC cable is plugged at the POS system. -
Page 22: Power Connector
The power cord receptacle and the power socket for the printer are located on the back of the BEETLE system. The power pack must be removed or replaced by authorized quali- fied personnel only. Only replace power packs released by Wincor Nixdorf. -
Page 23: System Unit
System Unit Always make sure that the system is switched off when you do cabling works. Connecting peripherals with the system switched on is not allowed. BEETLE /X plus with a J1- Motherboard Example for a connector panel: ... -
Page 24: Rj10/Rmt Jack (Optional)
COM1 is designed as a 9-pin D-sub plug. If scales which are not supplied by Wincor Nixdorf International GmbH are connected to the BEETLE /X plus, you must obtain a Wincor Nixdorf licence for the driver software Make sure that the connector is plugged securely into the socket to prevent possible malfunctioning. -
Page 25: Dvi-I
1920 × 1200 pixels/60 Hz. DVI-I transfers digital and analogue image data. Mini- DIN (KYBD) The BEETLE /X plus has a 6-pin mini-DIN jack for connecting a keyboard. Make sure that the connector is plugged firmly into the socket to prevent mal functioning. -
Page 26: Jack Plug 3.5 Mm (In/Out/Mic)
RJ12 plugs lock in when you insert them. Power is supplied to the cash drawer via this socket, P24V +5% / -15%. Connecting daisy chained cash drawers and 12V OEM-drawers is prohibited! Connect cash drawers only (no telephone). BEETLE /X plus User Manual... -
Page 27: Disconnecting Cables
networks. Unplug all cables from the devices. With MINI-DIN plugs (Wincor Nixdorf), the plug remains inserted until released. Pull the plastic covering from the connecting socket with your thumb. The lock is re- leased. The metal of the plug is visible. - Page 28 Manually loosen the knurled screws of the DC connector at the power supply. RJ45 plugs lock in when you insert them. To release them push the latch (see arrow). BEETLE /X plus User Manual...
-
Page 29: Storage Media
Change Of the Hard Disk Drive First ensure that the device is switched off and that the power connector is disconnected. Open your BEETLE /X plus. Loosen the two screws at the back side (see arrows). BEETLE /X plus User Manual... - Page 30 Lift the top cover at the back side (1) and pull it out of the front guide (2). Loosen the power cable (3) and the data cable (4). BEETLE /X plus User Manual...
- Page 31 Push the unlocking plate with a screw driver downward. Move the hard disk with the holder out of the carrier. BEETLE /X plus User Manual...
- Page 32 BIOS (see the manual for the mother- board). Please pay regard to the correct fitting position. Make sure that the metal bolts are corresponding to the stampings in the base plate (see side view). BEETLE /X plus User Manual...
- Page 33 Lift hard disk and green holders. Press those together and move the hard disk with the holders into the carrier until it locks into place. Plug the connectors and close the system with the cover. BEETLE /X plus User Manual...
-
Page 34: Ram Modul
RAM Module Shut down the system. Unplug the power cord at the rear side of the device. Remove the housing cover. BEETLE /X plus User Manual... - Page 35 RAM Module Click Click A coding on the module (notch) avoids a wrong insertion. Close the housing cover and plug the power cord at the rear side of the device. BEETLE /X plus User Manual...
-
Page 36: Usb- Hub (Optional)
A mechanical code avoids the plugging of a USB 12V connector into a USB 24V jack. Always use this onboard P-USB 12V (*) to connect a BA82 or BA83 screen with additional options or any other multifunctional screens. BEETLE /X plus User Manual... -
Page 37: Com5*-Com8* Interfaces (Optional)
The interface connection is a 9-pin D-sub jack. Power (5V or 12V) is supplied via this jack. Make sure that the connector for the customer display is screwed firmly to the socket to prevent possible malfunctioning. BEETLE /X plus User Manual... -
Page 38: Plink- Adapter (Optional)
Pull out the power plug before inserting or pulling out boards contain- ing ESDs. Always hold boards with ESDs by their edges. Never touch pins or conductors on boards fitted with ESDs. BEETLE /X plus User Manual... -
Page 39: Starting Up The System
Starting Up the System After installing the BEETLE /X plus, switch on the system by using the Pow- er button on the front panel and the power switch on the power supply. The system first performs an automatic self-test to test its basic functions. - Page 40 If the operating system has started up without error, the application soft- ware is automatically booted if necessary. A message is displayed as soon as the BEETLE /X plus is ready for opera- tion. For more detailed information, see the description of your application program.
-
Page 41: Appendix
- 25°C up to + 60°C Storage (1K2) + 5°C up to + 40°C Input Voltage 100- 120 V, 200- 240 V Max. power consumption 6A/ 3A Frequency of the system voltage 50/ 60 Hz BEETLE /X plus User Manual... -
Page 42: Interfaces (J1)
1 (keyboard and mouse via Y cable) RJ12 Cash drawer RJ45/ LAN 10/100 and 1000 Mbit/s PCI-Bus/ 1 x PCIe or 1 x PCI 2.1, 32 Bit PCIe Serial ATA 2 x SATA II/ 3.0 Gbit/s RJ10 RMT socket BEETLE /X plus User Manual... -
Page 43: Wall Mounting System
Wall Mounting System Dimensions in mm 27,7 Ø 10 210,2 29,4 16,1 BEETLE /X plus User Manual... -
Page 44: Wall Mounting Power Supply
Wall Mounting Power Supply Dimensions in mm Ø 8,5 10 10 A horizontal mounting of the external power supply is recommended (see above). BEETLE /X plus User Manual... -
Page 45: Total Current Consumption Of Interfaces
The 24V PoweredUSB interface is provided for the operation of Retail thermo printers. The peak load is accordingly designed. Power loss of additionally implemented PCI- and PCIe- Controllers is – for thermic reasons - limited to 10W for each slot and all together to 20W. BEETLE /X plus User Manual... -
Page 46: Abbreviations
Random Access Memory Solid State Disk (flash medium) Thin Film Transistor TN-S Terre Neutre- Separé Underwriters Laboratory (standards) Universal Serial Bus Video Graphics Adapter Wide Area Network WLAN Wireless Local Area Network Wincor Nixdorf International GmbH BEETLE /X plus User Manual... - Page 47 Wincor Nixdorf International GmbH D-33094 Paderborn Order No.: 01750235902A...
