Wincor Nixdorf BEETLE Operating Manual
Hide thumbs
Also See for BEETLE:
- User manual (82 pages) ,
- Installation manual (60 pages) ,
- Operating manual (40 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Wincor Nixdorf BEETLE
Summary of Contents for Wincor Nixdorf BEETLE
- Page 1 BEETLE /i8 V System Operating Manual...
- Page 2 MS-DOS™, Windows 95™, Windows 98™, Windows NT™, Windows 2000™, Windows XP™ and Windows CE™ are registered trademarks of the Microsoft Corporation ™ is a registered trademark of Wincor Nixdorf GmbH & Co. KG EETLE Copyright© Wincor Nixdorf GmbH & Co. KG, 2006 The reproduction, transmission or use of this document or its contents is not permitted without express authority.
- Page 3 BEETLE /i8 V System Operating Manual Edition Oct 2006...
-
Page 4: Table Of Contents
Connecting to the Main Power Supply ........10 Switching on the system ..............10 BEETLE /I8 V – The Components.............11 Functions & Indicators on the BEETLE /I8 V ........11 Drives on the BEETLE /I8 V............12 Rear Panel Connectors on the BEETLE /I8 V........13 12V Power Output ..............14... -
Page 6: Manufacturers Certification
Modifications not authorized by the manufacturer may void users authority to operate this device. This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NBM-003 du Canada. BEETLE /i8 V System – Operating Manual 01750119177 A... -
Page 7: Important Notes
Notes Important notes The BEETLE /I8 V system conforms to the current safety standards for data processing equipment. If this device is taken from a cold environment into the operating room, moisture condensation may form. The device must be absolutely dry before being put into service;... -
Page 8: Power Cord Selection
Safety Regulation of the country. Countries Safety Approvals Japan Taiwan BSMI China For other countries not mentioned in the above list, please check with the local authority. BEETLE /i8 V System – Operating Manual 01750119177 A... -
Page 9: Replacing The Lithium Battery
Push the Latch and remove the Lithium Battery from its Socket Insert and press a new Lithium Battery of same type in the Socket BEETLE /i8 V System – Operating Manual 01750119177 A... -
Page 10: Introduction
Introduction About this manual This manual describes the BEETLE /I8 V system. This documentation is intended to help you to work with the POS system and to serve as a reference work. The detailed table of contents helps you find the desired information quickly and easily. -
Page 11: Care Of The Beetle /I8 V
Recycling Center, which is certified pursuant to ISO 9001. So don’t simply throw your BEETLE /I8 V system on the scrap heap when it has served its time, but take advantage of the environmentally smart, up-to-date recycling methods! Please contact your competent branch office for information on how to return and re-use devices and disposable materials. -
Page 12: Warranty
Introduction Warranty Wincor Nixdorf guarantees a limited warranty engagement for 12 months beginning with the date of delivery. This warranty engagement covers all those damages which occur despite a normal use of the product. Damages because of improper or insufficient maintenance, ... -
Page 13: Device Overview
Device Overview Device Overview BEETLE /I8 V is a compact POS system that features the Open Architecture design concept with high level of retail peripheral integration. It has the flexibility as a modular system as well as its ability to be connected to a variety of external peripherals, such as cash drawer, printer, customer display and even to a network. -
Page 14: Basic Operation
Protect the device from vibrations, dust, moisture, heat and strong magnetic fields. ! CAUTION Make sure that the side ventilation slots on the BEETLE /I8 V system are not obstructed in order to ensure that the device has sufficient ventilation. BEETLE /i8 V System – Operating Manual... -
Page 15: Cabling Of The Beetle /I8 V
Always make sure that the system is switched off when you do cabling works. Connecting to the Main Power Supply All devices connecting to the BEETLE /I8 V system that have a separate power cable must be connected to the same electric circuit. -
Page 16: Beetle /I8 V - The Components
BEETLE /I8 V Components BEETLE /I8 V – The Components Functions & Indicators on the BEETLE /I8 V The illustration below shows the components of the BEETLE /I8 V system. – ON/OFF Button In an Micro ATX based system, the new soft touch power button replaces the main power switch that turns your system on and off. -
Page 17: Drives On The Beetle /I8 V
Drives on the BEETLE /I8 V The BEETLE /I8 V is equipped with a 3 ½” E-IDE Hard-Disk drive. The storage capacity is changed in line with market demand, but is currently at least 40 GB. -
Page 18: Rear Panel Connectors On The Beetle /I8 V
BEETLE /I8 V Components Rear Panel Connectors on the BEETLE /I8 V The illustration shows part of the rear panel of the BEETLE /I8 V, with the position of the connecting sockets and connectors. 24V Output COM3 COM2 COM4 Mouse... -
Page 19: 12V Power Output
There are two PCI Bus Master slots (rev. 2.2) on-board. Power Supply Unit The power supply unit automatically adjusts itself to the particular voltage. The power output of the power supply unit is maximum 220W. BEETLE /i8 V System – Operating Manual 01750119177 A... -
Page 20: Vga Connector For Monitor Or Lcd-Display
BEETLE /I8 V Components VGA Connector for Monitor or LCD-Display You can connect a Monitor or LCD-Display to the BEETLE /I8 V via the Blue 15-Pin D-Sub Jack on the VGA Connector. Keyboard Connector (PS/2) The BEETLE /I8 V has a Purple 6-pin Mini-DIN Jack for connecting a keyboard. -
Page 21: Lan (Rj45) Socket For Network
The BEETLE /I8 V system can be connected to a network (LAN) from the POS terminal rear panel. USB (Universal Serial Bus) Port 1 and 2 Two USB ports are available at the rear panel of BEETLE /I8 V system for connecting USB Devices. Audio Port Sockets... -
Page 22: 7Dl6-C7 (V4) Via Motherboard
BEETLE /I8 V Motherboard 7DL6-C7 (V4) VIA Motherboard BEETLE /I8 V is using VIA motherboard with VIA CN700 + VT8237R PLUS chipset and C7/V4 CPU. CAUTION Static electricity can harm delicate components of the Main-Board. To prevent damage caused by static electricity, discharge the static electricity from your body before you touch any of the computers electronic components. -
Page 23: Motherboard Block Diagram
SM Bus Audio Codec AC'97 LINK H/W Monitor Floppy Parallel Serial 1/2 ROM BIOS SATA X2 W83L786 SATA Interface (Option) (Option) Serial 3/4 VIA PHY LAN MII Fast Ethernet Interface 10/100BaseT BEETLE /i8 V System – Operating Manual 01750119177 A... -
Page 24: Motherboard Details
3 audio jacks for line-out, line-in and mic-in. 12V Power connector BIOS Award BIOS 4Mbit flash memory System Monitoring & CPU temperature monitoring Management System voltage monitoring Keyboard-Power-on. 8.662” x 8.80” Dimension Accessories Driver CD BEETLE /i8 V System – Operating Manual 01750119177 A... -
Page 25: System Bios
Set User Password PnP/PCI Configurations Save & Exit Setup PC Health Status Exit Without Saving : Select Item Quit Save & Exit Setup Time, Date, Hard Disk Type…. BEETLE /i8 V System – Operating Manual 01750119177 A... -
Page 26: Setup Items
Use this menu to set User and Supervisor Passwords. Password Save & Exit Setup Save CMOS value changes to CMOS and exit setup. Exit Without Save Abandon all CMOS value changes and exit setup. BEETLE /i8 V System – Operating Manual 01750119177 A... -
Page 27: Appendix
Appendix Appendix Technical Data for the BEETLE /I8 V Dimension (without cable cover) Width 288 mm Depth 353 mm Height 103 mm Weight approx. 5.4 kg Climatic category IEC 721-3-3 Class 3K3 +5°C to +40°C Operating IEC 721-3-3 Class 3K3 -25°C to +40°C... - Page 28 Published by Wincor Nixdorf Pte Ltd 2, Kallang Sector Singapore 349277 Part No.: 01750119177 A Printed in Singapore...
