dropbear voiptel-ntp ssmtp voiptel-cron
Then it will connect to owetel and VoIPtel website for the latest packages. Please make sure that
your IP04 has the internet connection to download the packages. Don't worry if it seems to get
stuck on downloading / installing the voiptel-sounds package, as it just needs some time due to it's
size.
root:~>/etc/init.d/zaptel enable
root:~>/etc/init.d/asterisk enable
root:~>reboot
after reboot, you can check the ip address on the console port and check its ip address via
root:~>ifconfig
put this ip address on your firefox browser and configure the IP04.
7/ After the new kernel and new software packages are installed in the ip04 successfully. You may
need to remove the console port and close the cover, remember to short the pin2 and pin4 on J8
connector with jumper as below.
// load zaptel driver on every booting
// load the asterisk on evert booting.
Short pin2 and pin4
