Code Alarm ca6554 Installation Manual page 11

5 LT GREEN/BLACK
This wire will supply a ( - ) 200mA pulse both upon disarming the system and when
the remote start feature is activated. Locate the factory perimeter alarm disarm wire
from the key cylinder inside the drivers door.
Verification: This wire registers ground if the key is turned to the unlock
position in the driver's door cylinder.
Connect the LIGHT GREEN/BLACK wire to the factory alarm disarm wire.
6 ORANGE
This wire will have a continuous ( - ) 500mA output when the system is Armed.
This wire is typically used for controlling the starter interrupt relay as well as window
modules or additional sensors.
This output can be configured in option programming.
8 Pin Input Harness
1 BLUE/WHITE
This wire is a GROUND input for an external sensor or secondary pin switch.
Verification: This wire when connected will trigger the security system.
2 GREEN
Locate the vehicle's dome light or door pin switch wire.
Verification: This wire will register ground (NEG) when the door is opened
and the interior light is on. This wire will register positive voltage when the
door is closed and the interior light is off.
Connect the GREEN wire to the vehicle's negative door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide.
2014 Voxx Electronics Corporation. All rights reserved.
FACTORY DISARM /
PULSE BEFORE START ( - )
GROUND WHEN ARMED OUTPUT ( - )
INSTANT TRIGGER INPUT ( - )
DOOR TRIGGER INPUT ( - )
11
