PROFESSIONAL
SERIES
Automatic / Manual Transmission
Remote Start with Keyless Entry

Installation Guide

for models:
ca5554
2014 Voxx Electronics Corporation. All rights reserved.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ca5554 PROFESSIONAL SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for Code Alarm ca5554 PROFESSIONAL SERIES

Summary of Contents for Code Alarm ca5554 PROFESSIONAL SERIES

  • Page 1: Installation Guide

    PROFESSIONAL SERIES Automatic / Manual Transmission Remote Start with Keyless Entry Installation Guide for models: ca5554 2014 Voxx Electronics Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Table of Contents Before You Begin ..................3 Wire Connection Guide ................4 11 Pin Main Harness ................. 5 3 Pin Parking Light Harness ..............8 6 Pin Start Harness ................... 9 4 Pin Alternate Harness ................10 2 Pin Door Lock Harness ................ 11 Additional Ports ..................

  • Page 3: Before You Begin

    BEFORE YOU BEGIN PROFESSIONAL INSTALLATION STRONGLY RECOMMENDED Installation Precautions: Roll down window to avoid locking keys in vehicle during installation Avoid mounting components or routing wires near hot surfaces Avoid mounting components or routing wires near moving parts Tape or loom wires under hood for protection and appearance Use grommets when routing wires through metal surfaces...

  • Page 4: Pin Main Harness

    11 Pin Main Harness GRAY/RED PARKING BRAKE INPUT ( - ) PURPLE DOOR INPUT ( + ) GREEN DOOR INPUT ( - ) BLACK/WHITE ILLUMINATED ENTRY OUTPUT ( - ) BROWN/BLACK HORN OUTPUT ( - ) RED/WHITE TRUNK RELEASE OUTPUT ( - ) BLUE/BLACK START STATUS / ACTIVE OUTPUT ( - ) PURPLE/WHITE...

  • Page 5: Pin Alternate Harness

    4 Pin Alternate Harness BLACK/YELLOW PULSE DURING CRANK ( - ) GREEN/WHITE PULSE AFTER SHUTDOWN ( - ) LT BLUE FACTORY ARM / PULSE AFTER START ( - ) LT GREEN/BLACK FACTORY DISARM / PULSE BEFORE START ( - ) 2 Pin Door Lock Harness 11 Pin Main Harness GRAY/RED...
  • Page 6 GREEN DOOR TRIGGER INPUT ( - ) Locate the vehicle’s dome light or door pin switch wire. Verification: This wire will register ground (NEG) when the door is opened and the interior light is on. This wire will register positive voltage when the door is closed and the interior light is off.
  • Page 7 BLUE/BLACK START STATUS / ACTIVE OUTPUT ( - ) This wire provides a ground output when the remote start function is activated and remains until 4 seconds after the remote start is shutdown. If this wire will be used for multiple application’s a 1 amp diode is required in-line with the stripe facing the control module.
  • Page 8 VIOLET/BLACK AUX 1 This wire provides a ( - ) 200mA output capable of driving relays. For Control of optional accessories (i.e. Power Window/Sunroof, etc.). To activate refer to the transmitter button configuration chart. Please refer to the selectable options for timing. 3 Pin Parking Light Harness BLACK GROUND Connect the BLACK wire to a solid chassis ground point using a ring terminal and self tapping screw (not supplied).
  • Page 9 6 Pin Start Harness PURPLE STARTER OUTPUT ( + ) Locate the vehicle starter wire. Verification: This wire registers voltage only when the key is turned to the START position. Verification: The starter wire registers voltage when the key is turned to the START position.
  • Page 10 RED/WHITE BATTERY 12V ( + ) Locate 1 of the vehicle’s constant 12 Volt battery wires at the ignition switch. Verification: This wire will register ( + ) voltage in all positions of the ignition switch. Connect the RED/WHITE wire to the constant 12 Volt battery wire. NOTE: Remove all fuses until all connections are made.

  • Page 11: Pin Door Lock Harness

    LT BLUE FACTORY ARM / PULSE AFTER START ( - ) This wire will supply a ( - ) 200mA pulse both upon arming the system and upon successful completion of the remote start activation sequence and is typically used to re-lock the vehicle’s doors upon remote start if necessary.
  • Page 12 Negative Switching Locks All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock switch. Verification: These wires will register ground when the Lock and Unlock switches are activated. Connect the GREEN and BLUE wires shown in the diagram below. Negative Locks: GREEN ( - ) Lock Output Lock...
  • Page 13 Reverse Polarity Locks (5-Wire Door locks) All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock switch. Verification: These wires will rest at ground and register positive voltage when the Lock and Unlock switches are activated. Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below using (2) SPDT relays (not supplied).
  • Page 14 Positive Multiplexed Locks All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock / unlock switch. Verification: This wire will show variable positive voltage when the switch is activated. Please consult the wire and location chart for specific resistor values for your vehicle. Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below using (2) SPDT relays (not supplied).

  • Page 15: Additional Ports

    Additional Ports Antenna / LED / Programming Port Mount the supplied antenna/receiver to a clear spot on the vehicle’s windshield that will not block the driver’s vision. A good location is usually high on the windshield near the rear view mirror. Be careful not to mount the antenna/receiver on any metallic window film, as this will effect system range. Route the antenna/receiver cable to the control module and plug into the antenna port.

  • Page 16: Set Up & Programming

    Set Up & Programming Transmitter Programming - Feature Bank 1 Turn the ignition ON. Press and hold the valet/override button. Within 10 seconds the system will chirp (3) three times. Press 1 button of each transmitter you wish to program. The system will respond with 1 chirp for each accepted transmitter.

  • Page 17: Transmitter Programming

    Feature Bank 1 - 3 Chirps Transmitter Programming Refer to transmitter programming. Feature Bank 2 - 4 Chirps 1 LED Flash 2 LED Flash 3 LED Flash 4 LED Flash 5 LED Flash 6 LED Flash Security Control Silent Choice Passive Locks Active Passive...
  • Page 18 Feature Bank 4 - 6 Chirps 1 LED Flash 2 LED Flash 3 LED Flash 4 LED Flash 5 LED Flash 6 LED Flash Remote Start Control RF Start Chirp Run Time 15 Minutes 5 Minutes 10 Minutes 20 Minutes 45 Minutes 60 Minutes Running Lights...
  • Page 19 Feature Bank 5 - 7 Chirps 1 LED Flash 2 LED Flash 3 LED Flash 4 LED Flash 5 LED Flash 6 LED Flash 4 Pin Alternate Output Control Pulse Before Ground While Pulse During Lt Green / Black Output Start / During Ignition Accessory...

  • Page 20: Tach Programming

    Tach Programming The unit will not operate unless a tach signal is programmed or the tachless option is turned ON. If an attempt is made to start the vehicle via the remote start without first programming tach, the unit will flash the parking lights 7 times indicating tach has not been learned and stored. If the tach rate is not properly programmed to the specific vehicle, the unit may not realize that the vehicle is running in certain instances and reengage the starter motor.

  • Page 21: Feature Descriptions

    Feature Descriptions Feature Bank 2 - Security 1 - Silent Choice: Controls the normal arm/disarm chirps of the security system. ON - Silent arming/disarming upon first press of lock/unlock, pressing lock/ unlock a second time will activate the arm/disarm chirps respectively. The system will only sound the arm/disarm chirps upon a second press of the lock/unlock buttons.
  • Page 22 Feature Bank 3 - Output Control 1 - Extended Lock Pulse: Controls the timing of the BLUE and GREEN lock output wires. 1 Second - Single 1 second lock pulse, single 1 second unlock pulse. 3.5 Seconds - Single 3.5 second lock pulse, single 3.5 second unlock pulse. 1 Second Lock, Double Pulse Unlock - Single 1 second lock pulse, double 1 second unlock pulse.
  • Page 23 4 - Trunk Output Timing - Red/White Output: Controls the output timing/type of the RED/WHITE output. 1 Second Pulse - 1 second pulse output. 10 Second - Continuous output for 10 seconds. 20 Seconds - Continuous output for 20 seconds. Latched until IGN ON - Continuous output until the vehicle’s ignition is turned Latched ON until Button Press - Continuous output until the activation button is pressed again.
  • Page 24 3 - Running Lights: Controls the WHITE parking light output wire during remote start. Steady - Parking lights constant during the remote start cycle. Flashing - Parking lights flash at a slow pace during the remote start cycle. 4 - Tach Mode: Determines how the system monitors the engine running during remote start. Tach - Hard wired directly to the tach wire of the vehicle to monitor AC voltage.
  • Page 25 8 - Gas / Diesel: Selects engine type and delay time for the starter output wire during remote start activation. Gas - Gasoline engine, no delay for the starter output wire. 10 Second Delay - Diesel engine, delays the starter output wire for 10 seconds after the ignition has been powered up by the remote start.
  • Page 26 15 - Accessory Output: Programmable high current output. Accessory - Output becomes active with the same timing as the accessory output, drops out during crank. Ignition - Output becomes active with the same timing as the ignition output and does not drop out during crank. Start / Crank - Output becomes active with the same timing as the starter output wire, during crank only.
  • Page 27 Feature Bank 5 - 4 Pin Alternate Output Control 1 - Lt Green/Black Output : Controls the LT GREEN/BLACK output activation type and timing. Pulse before Start / During Unlock - 1 second pulse when remote start is activated. Also a 1 second pulse when unlock is pressed. Ground While Running - Continuous output for the entire remote start sequence until after the vehicle shuts down.
  • Page 28 4 - Black/Yellow Output : Controls the BLACK/YELLOW output activation type and timing. Pulse During Crank - Output becomes active with the same timing as the starter output wire, during crank only. Ground While Running - Continuous output for the entire remote start sequence until after the vehicle shuts down.

  • Page 29: Transmitter Button Functions

    Transmitter Button Functions 1 Way Car Find / Lock Unlock Start Operation Method Transmitter Panic Lock Press and Release Unlock Press and Release Trunk Push and Hold (3 Sec) Car Finder Press and Release Panic Push and Hold (3 Sec) Press and Release (1 or 2 times depending Remote Start on selectable option)

  • Page 30: Remote Start Shutdown Diagnostics

    Remote Start Shutdown Diagnostics If the remote start shuts down or fails to start, the parking lights will flash one of the patterns below indicating the shutdown input. To manually enter diagnostics and view the last shutdown, turn the ignition ON and press and release the button. LED FLASHES SHUTDOWN ZONE 3 Flashes Hood Input Brake Input 4 Flashes Remote Start Valet Mode 5 Flashes...
  • Page 31 2014 Voxx Electronics Corporation. All rights reserved.
  • Page 32 Voxx Electronics Corporation. Customer Service 1-800-421-3209 WWW.CODE-ALARM.COM FCC COMPLIANCE This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2.
