8 - Ground While Armed / Orange Output: Controls the output of the orange wire.
This wire will either supply a ( - ) output when armed OR disarmed.
9 - DBI Port Protocol: Determines the protocol type in which the DBI port uses to
interface with external modules.
DBI Protocol
ADS Protocol
10 - Arm/Disarm Chirp / Parking Light Pattern: Determines the number of chirps
and parking light flashes when the system is armed/disarmed.
Standard - 2 chirps/light flashes with arm, 1 chirp/light flash with disarm.
Inverted - 1 chirp/light flash with arm, 2 chirps/light flashes with disarm.
Feature Bank 3 - Output Control
1 - Extended Lock Pulse: Controls the timing of the BLUE and GREEN lock output
wires.
1 Second - Single 1 second lock pulse, single 1 second unlock pulse.
3.5 Seconds - Single 3.5 second lock pulse, single 3.5 second unlock pulse.
1 Second Lock, Double Pulse Unlock - Single 1 second lock pulse, double 1
second unlock pulse.
30 Second Lock, Double Pulse Unlock - Single 30 second lock pulse, double
1 second unlock pulse.
Double Pulse Lock, 1 Second Unlock - Double 1 second lock pulse, single 1
second unlock pulse.
2 - Factory Disarm: Controls the timing of the LT. GREEN/BLACK factory disarm
wire on the 6 pin output harness only and does not change the output of the factory
disarm wire on the 4 pin alternate output harness.
Factory Disarm - Single 1 second pulse with unlock and remote start activation.
2nd Unlock - Same output as unlock with 2nd press of unlock.
Factory Disarm / Start Status - Single 1 second pulse with unlock and
continuous ( - ) output during the remote start cycle.
Factory Disarm - Single 350mS second pulse with unlock and remote start
activation.
Factory Disarm - Single 500mS second pulse with unlock and remote start
activation.
