S/M No. : DWDFD14001

Service Manual

Auto Washer
: DWD-FD1022
Model
• Caution:
In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-FD1022 and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo DWD-FD1022

Summary of Contents for Daewoo DWD-FD1022

  • Page 1: Service Manual

    S/M No. : DWDFD14001 Service Manual Auto Washer : DWD-FD1022 Model • Caution: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts...

  • Page 2: Table Of Contents

    AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER...

  • Page 3: Specifications

    1. SPECIFICATIONS DWD-F1X1X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER MODEL DWD-FD1411 / 1412 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 58 kg WATER CONSUMPTION 56.1 POWER CONSUMPTION 2200W...

  • Page 4: Installation

    2. INSTALLATION Transit bolts Transit bolts The appliance is fitted with transit bolts to prevent internal damage during transport. The appliance is fitted with transit bolts to prevent internal damage during transport. Removing transit bolts Removing transit bolts 1. To prevent internal damage during trnasport, the 2.

  • Page 5: Installation Place Requirement

    Installation place requirement Level floor : Allowable slope under entire washer is 1° Power outlet : Must be with 1,5 meters of entire side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required.

  • Page 6: Connecting Inlet Hose

    Connecting inlet hose In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. FOR ORDINARY TAP 1 Pull down the collar 2 Loosen the four...

  • Page 7: Installation Of Drain Hose

    Installation of drain hose Installation of drain hose • When installing the drain hose in sink, secure it tightly with a string. • Proper securing of the drain hose will protect the floor from damage due to water leakage. • The drain hose should not be placed higher than 100cm above the floor.

  • Page 8: Level Adjustment

    Level adjustment 1. The level adjustment of the washing machine pre- vents excessive noise and vibration. Install the washing machine on a solid and even floor surface, if possible, in a corner of the room. Note: the wooden floor may cause excessive vibration.

  • Page 9: Maintenance

    3. MAINTENANCE Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive houshold detergent. Immediately wipe off any spills.

  • Page 10: Cleaning The Water Inlet Filter

    Cleaning the water inlet filter Cleaning the water inlet filter • "IE" error message will blink on the control panel when water does not enter the detergent drawer. • "IE" error message will blink on the control panel when water does not enter the detergent drawer. •...

  • Page 11: Cleaning The Detergent Case

    Cleaning the detergent case Cleaning the detergent case After a while detergents and fabric softeners leave a deposit in the detergent case. After a while detergents and fabric softeners leave a deposit in the detergent case. • It should be cleaned from time to time with a jet of running water. •...

  • Page 12: Direction For Disassembly

    4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1) Open the door and remove the gaske clamp. 2) Remove the gasket from the front cabinet. 3) Remove two screws, and remove the door lock switch. HEATER AND THERMISTOR 1) Remove five screws on the COVER B and separate 2) Remove the connectors of the HEATER.
  • Page 13 3) Remove the nut using the 10mm hex wrench and 4) Loose the nut of the HEATER and pull out the remove the earth terminal from the HEATER. HEATER. BLDC MOTOR 1) Remove the nut using the 17mm hex wrench. 2) Pull out the ROTOR.

  • Page 14: Drain Pump

    DRAIN PUMP 1) Lay the right side of the washer on the floor, and 2) Remove connectors. remove the lower panel by pressing six sanp fits. 3) Remove the screw, and remove the drain pump from 4) Remove the drain hose. the lower frame.

  • Page 15: Explode View And Parts List

    5. EXPLODE VIEW AND PARTS LIST BOX INLET AS PART NAME PART CODE SPECIFICATION Q'TY REMARK HANDLE CASE 3612608900 ABS,F1221N CASE DETERGENT 3611140300 CAP SOFTENER 3610916600 BOX INLET 3610526500 3618103510 COLD NOZZLE AS NOZZLE TOP + NOZZLE UNDER 3618103500 COLD+HOT SCREW TAPPING 7122402011 T2S TRS 4X20 MFZN...
  • Page 16 PANEL FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PANEL F 3614284500 3616603600 DWD-FD1411 BUTTON POWER 3616603620 ABS + AL COATING DWD-FD1412 WINDOW DIAL 3615503100 ABS-TR 3616603500 DWD-FD1411 BUTTON SELECT 3616605320 ABS + AL COATING DWD-FD1412 WINDOW DISPLAY AS 3615503020 ABS-TR + STICKER PCB AS...
  • Page 17 CABINET FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET FRONT 3610811220 SECD 0.7T SWITCH DOOR LOCK 3619047100 DL-LC BITRON_3P 250V 16A BI-METAL SCREW TAPPING 7122401208 T2S TRS 4X12 SUS PLATE HINGE SUPPORT 3614531900 SGCC T1.6 HINGE DOOR 3612902800 ZNDC CAP HINGE DOOR 3610916500...
  • Page 18 TUB ASS’Y EXPLODE VIEW AND PARTS LIST...
  • Page 19 PART NAME PART CODE SPECIFICATION Q'TY REMARK D01 BALANCER WEIGHT F L/R 3616106320 FRONT, 5.5kg D02 SPECIAL SCREW(BALANCER) 3616029400 SWCH 8.5X30 D03 GASKET 3612321400 EPDM D04 CLAMP GASKET AS 3611204500 HSWR D=1.8 D05 TUB FRONT 3618821010 FRPP FH7304GM D06 SPECIAL SCREW(TUB) 3616029800 SWCH 6.5X30 D07 FIXTURE HEATER...
  • Page 20 CABINET AS EXPLODE VIEW AND PARTS LIST...
  • Page 21 PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET 3610811100 SGCC, T0.8, PAINTING SPECIAL SCREW 3616029100 M4x12.5, MACHINE FRAME UPPER 3612205800 SGCC T1.2 55X580 SCREW TAPPING 3616029950 TTS"S" HEX F/L 4X8 FRAME TOP-L 3612205600 SGCC T1.6 52x500 FRAME TOP-R 3612205700 SGCC T1.6 52x500 STOPPER SPRING 3615202200 COVER B...
  • Page 22 PLATE T AS + PANEL LOWER AS PART NAME PART CODE SPECIFICATION Q'TY REMARK PLATE T AS 3614532900 HIPS, MFC, WH SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN PANEL LOWER 3614282801 HIPS COVER PUMP FILTER 3611425801 HIPS EXPLODE VIEW AND PARTS LIST...

  • Page 23: Functions Of The Control Panel

    6. FUNCTIONS OF THE CONTROL PANEL DWD-FD1411/1412/1413/1414/1415 Power Switch Press this buton to turn the power ON or OFF. Start/Hold This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 24 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...

  • Page 25: Functions Of The Controller

    7. FUNCTIONS OF THE CONTROLLER SEQUENCE CHART Cotton Synthetic Division Progress Time Sensing 20sec. Water Supply 2min. 10min. Pre Wash 8min. Drain 1min. B-Spin 1min. Middle Spin 3min. Sensing 20sec. Water Supply 2min. 70min. 60min. Wash 1 35min. (Heating) 30min. 20min.
  • Page 26 Wool Delicate Hand Wash Quick 30 Rinse+Spin Division Progress Time Soak 30min. 2min. Water Supply 1min. 15min. Wash 1 10min. (Heating) 5min. 20min. Wash 2 10min. 5min. Drain 1min. B-Spin 1min. Middle Spin 4min. 2min. Water Supply 1min. Rinse 1 3min.

  • Page 27: Function Of The Convenient Service

    8. FUNCTION OF THE CONVENIENT SERVICE The test mode of the load movement You can check the PCB ASS'Y and the condition of each load movement simply. • The method to enter 1 Press the Power switch button. 2 Press the Option button 3 times while press the Temp button. At this time, the version is displayed on the Custom LED 3 Each load makes a movement as follows, whenever the Time Delay button is pressed a time.

  • Page 28: Troubleshooting Guide

    9. TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. SYMPTOM CAUSE SOLUTION...
  • Page 29 SYMPTOM CAUSE SOLUTION Washer does not start. Electronical power cord may not be Make sure plug fits tightly in wall outlet. plugged in or connection may be loose. House fuse blown, circuit breker Reset circuit breaker or replace fuse. tripped, or a power outage has Do not increase fuse capacity.
  • Page 30 MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. WATER INLET The water level sensor (sensor pressure) is an inferior product Change the water level sensor...
  • Page 31 MESSAGE ERROR CAUSE SOLUTION The heater worked without the water in the tub. Check the water level. THERMISTOR WASH OVERHEATING The thermistor wash is an inferior product or broke down. Change the thermistor wash. ERROR The water temp. is over 45°C in delicate & wool course. WATER TEMP.

  • Page 32: Wiring Diagram

    10. WIRING DIAGRAM WIRING DIAGRAM...
  • Page 33 DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M No. :...
