Service Manual
Washing Machine
Model:
DWD-F1011/F1012/F1013/F1211/F1212/F1213
DWD-F1021/F1022/F1023/F1221/F1222/F1223
DWD-F1031/F1032/F1033/F1231/F1232/F1233
DWD-F1041/F1042/F1043/F1241/F1242/F1243
NFL-1065/NFL-1265
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
S/M No. : WDF1011002(r)
Apr. 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWD-F1012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Daewoo DWD-F1012

Summary of Contents for Daewoo DWD-F1012

  • Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CORP. http : //svc.dwe.co.kr Apr. 2008...

  • Page 2: Table Of Contents

    SHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASH TO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER SHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER...

  • Page 3: Specifications

    1. SPECIFICATIONS DWD-F1X1X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER DWD-F1X2X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER SPECIFICATIONS...
  • Page 4 DWD-F1X3X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN LOWER COVER ADJUSTABLE LEG DWD-F1011/F1012/F1013/F1211/F1212/F1213 DWD-F1021/F1022/F1023/F1221/F1222/F1223 MODEL DWD-F1031/F1032/F1033/F1231/F1232/F1233 NFL-1065/NFL-1265 POWER SOURCE 220-240V, 50Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 64kg WATER CONSUMPTION 47~59 POWER CONSUMPTION 2200W MAXIMUM MASS...
  • Page 5 DWD-FU1X4X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN LOWER COVER ADJUSTABLE LEG MODEL DWD-FU1041/1042/1043/1241/1242/1243 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595mm x 540mm x 850mm WEIGHT 64 kg WATER CONSUMPTION 47~59 POWER CONSUMPTION 2200W MAXIMUM MASS WASH...

  • Page 6: Installation

    2. INSTALLATION Transit bolts Transit bolts The appliance is fitted with transit bolts to prevent internal damage during transport. The appliance is fitted with transit bolts to prevent internal damage during transport. Removing transit bolts Removing transit bolts 1. To prevent internal damage during transport, the 2.

  • Page 7: Installation Place Requirement

    Installation place requirement Level floor : Allowable slope under entire washer is 1° Power outlet : Must be with 1.5 meters of entire side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required.

  • Page 8: Connecting Inlet Hose

    Connecting inlet hose In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. FOR ORDINARY TAP 1 Pull down the collar 2 Loosen the four...

  • Page 9: Installation Of Drain Hose

    Installation of drain hose Installation of drain hose • When installing the drain hose in sink, secure it tightly with a string. • Proper securing of the drain hose will protect the floor from damage due to water leakage. • The drain hose should not be placed higher than 100cm above the floor.

  • Page 10: Level Adjustment

    Level adjustment 1. The level adjustment of the washing machine pre- vents excessive noise and vibration. Install the washing machine on a solid and even floor surface, if possible, in a corner of the room. Note: the wooden floor may cause excessive vibration.

  • Page 11: Maintenance

    3. MAINTENANCE Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent. Immediately wipe off any spills.

  • Page 12: Cleaning The Water Inlet Filter

    Cleaning the water inlet filter Cleaning the water inlet filter • • "IE" error message will blink on the control panel when water does not enter the detergent drawer. "IE" error message will blink on the control panel when water does not enter the detergent drawer. •...

  • Page 13: Cleaning The Detergent Case

    Cleaning the detergent case Cleaning the detergent case After a while detergents and fabric softeners leave a deposit in the detergent case. After a while detergents and fabric softeners leave a deposit in the detergent case. • It should be cleaned from time to time with a jet of running water. •...

  • Page 14: Direction For Disassembly

    4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1) Open the door and remove the gasket clamp. 2) Remove the gasket from the front cabinet. 3) Remove two screws, and remove the door lock switch. HEATER AND THERMISTOR 1) Remove four screws on the back cover, and 2) Remove connectors and the earth terminal.
  • Page 15 3) Remove the nut by using a box wrench, and 4) Loosen the nut by using a box wrench, and pull out remove the earth terminal. the heater. UNIVERSAL MOTOR 1) remove the belt from the pulley. 2) Lay the right side of the washer on the floor, and remove the connector.
  • Page 16 DRAIN PUMP 1) Lay the right side of the washer on the floor, and 2) Remove connectors. remove the lower panel by pressing six sanp fits. 3) Remove the screw, and remove the drain pump from 4) Remove the drain hose. the lower frame.

  • Page 17: Explode View And Parts List

    5. EXPLODE VIEW AND PARTS LIST BOX INLET AS PART NAME PART CODE SPECIFICATION Q'TY REMARK 3612608700 DWD-F1X11(2) 3612608710 ABS + SPRAY DWD-F1X13 3612608900 DWD-F1X21(2) 3612608910 ABS + SPRAY DWD-F1X23 HANDLE CASE 3612609700 DWD-F1X31(2) 3612609710 ABS + SPRAY DWD-F1X33 3611148000 DWD-F1X41(2) 3611148010 ABS + SPRAY...
  • Page 18 PANEL FRONT AS (DWD-F1X1X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614282700 PANEL F 3614282710 SILVER SPRAY DWD-F1X13 3616603600 DWD-F1X11/DWD-F1X14 BUTTON POWER 3616603620 ABS+AL COATING WINDOW DIAL 3615503100 3616603500 DWD-F1X11/DWD-F1X14 BUTTON SELECT 3616605320 ABS+AL COATING WINDOW LED 3615503000 Refer to PCB AS PRPSSWB1- DWD-F1XXX SERIES...
  • Page 19 PANEL FRONT AS (DWD-F1X2X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614284500 PANEL F 3614284510 SILVER SPRAY DWD-F1X23 3616604200 DWD-F1X21 BUTTON POWER 3616604210 ABS+AL COATING WINDOW DIAL 3615503400 3616604100 DWD-F1X21 BUTTON SELECT 3616604110 ABS+AL COATING WINDOW LED 3615503300 Refer to PCB AS PRPSSWB1- DWD-F1XXX SERIES...
  • Page 20 PANEL FRONT AS (DWD-F1X3X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614285800 DWD-F1X31(2) PANEL F 3614285810 ABS+SPRAY DWD-F1X33 3616635300 DWD-F1X31 BUTTON POWER 3616635310 ABS+SPRAY DWD-F1X32(3) WINDOW DIAL 3615504200 ABS-TR 3616635400 DWD-F1X31 BUTTON SELECT 3616635410 ABS+SPRAY DWD-F1X32(3) WINDOW DISPLAY 3615504300 ABS-TR Refer to PCB AS...
  • Page 21 PANEL FRONT AS (DWD-FU1X4X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK 36142T1500 DWD-F1X41(2) PANEL F 36142T1510 ABS + SPRAY DWD-F1X43 3616639100 DWD-F1X41 BUTTON POWER 3616639110 ABS + SPRAY DWD-F1X42(3) WINDOW COURSE 3615507000 ABS-TR 3616639000 DWD-F1X41 BUTTON SELECTION 3616639010 ABS + SPRAY DWD-F1X42(3) WINDOW DISPLAY 3615506800...
  • Page 22 Detailed Part Code of PCB AS No. PART NAME PART CODE SPECIFICATION Q'TY REMARK PRPSSWB100 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, BB PRPSSWB101 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB PRPSSWB102 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, BB PRPSSWB103 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB PRPSSWB104 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, BB PRPSSWB105 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB...
  • Page 23 Detailed Part Code of PCB AS No. PART NAME PART CODE SPECIFICATION Q'TY REMARK PRPSSWB200 DWD-FU104, PANA MICOM, EC, 1000RPM, HOT V/V, BB PRPSSWB201 DWD-FU104, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB PRPSSWB202 DWD-FU104, PANA MICOM, EC, 1000RPM, COLD V/V, BB PRPSSWB203 DWD-FU104, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB PRPSSWB204 DWD-FU124, PANA MICOM, EC, 1200RPM, HOT V/V, BB PRPSSWB205 DWD-FU124, PANA MICOM, EC, 1200RPM, HOT V/V, NON-BB...
  • Page 24 CABINET FRONT AS PART NAME PART CODE SPECIFICATION Q'TY REMARK 3610811210 PCM, SGCC 0.8T, SILVER DWD-F1XX3 CABINET FRONT 3610811220 SECD 0.7T SWITCH DOOR LOCK 3619046800 250V16A, ROLD, BI-METAL SCREW TAPPING 7122401208 T2S TRS 4X12 SUS PLATE HINGE SUPPORT 3614531900 SGCC T1.6 HINGE DOOR 3612902800 ZNDC...
  • Page 25 TUB ASS’Y EXPLODE VIEW AND PARTS LIST...
  • Page 26 PART NAME PART CODE SPECIFICATION Q'TY REMARK BALANCER WEIGHT F L/R 3616106300 FRONT, 6.0kg SPECIAL SCREW(BALANCER) 3616029400 SWCH 8.5X30 GASKET 3612321400 EPDM CLAMP GASKET AS 3611204500 HSWR D=1.8 TUB FRONT 3618821001 FRPP FH7300GM SPECIAL SCREW(TUB) 3616029800 SWCH 6.5X30 FIXTURE HEATER 3612007300 SUS 0.7T 440x45 DRUM SUB AS...
  • Page 27 CABINET AS EXPLODE VIEW AND PARTS LIST...
  • Page 28 PART NAME PART CODE SPECIFICATION Q'TY REMARK CABINET 3610811100 SGCC, T0.8, PAINTING SPECIAL SCREW 3616029100 M4x12.5, MACHINE FRAME UPPER 3612205800 SGCC T1.2 55X580 SCREW TAPPING 3616029950 TTS"S" HEX F/L 4X8 FRAME TOP-L 3612205600 SGCC T1.6 52x500 FRAME TOP-R 3612205700 SGCC T1.6 52x500 STOPPER SPRING 3615202200 COVER BACK AS...
  • Page 29 PLATE T AS + PANEL LOWER AS PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614532900 HIPS, MFC, WH DWD-F1X11(2) 3614532910 ABS+UV SPRAY, MFC, SILVER DWD-F1X13 3614532920 HIPS, MFC, WH DWD-F1X21(2) 3614532930 ABS+UV SPRAY, MFC, SILVER DWD-F1X23 PLATE T AS DWD-F1X31(2) 3614533300 HIPS, MFC, WH DWD-F1X41(2)

  • Page 30: Functions Of The Control Panel

    6. FUNCTIONS OF THE CONTROL PANEL DWD-F1X1X SERIES Power Button Press this button to turn the power ON or OFF. Start/Hold Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 31 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...
  • Page 32 DWD-F1X2X SERIES Power Button Press this button to turn the power ON or OFF. Start/Hold Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 33 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...
  • Page 34 DWD-F1X3X SERIES Power Button Press this button to turn the power ON or OFF. Start/Hold Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 35 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...
  • Page 36 DWD-F1X4X SERIES 1000/1200 Power Button Press this button to turn the power ON or OFF. Start/Hold Button This button is use to start wash cycle or stop temporarily. When you want to change program in operating, press this button. Temperature Button This button can be used to adjust temperature of water according to types of the load to be washed.
  • Page 37 Time Save Button By pressing this button, you can decrease pre-set washing time to 10 minutes. Time save is available in Cotton, Eco and Synthetic. Time Delay Button If you want to reserve the finishing time of washing, use this button. If the Time Delay button is pressed, "2:00"...

  • Page 38: Functions Of The Controller

    7. FUNCTIONS OF THE CONTROLLER SEQUENCE CHART Cotton Synthetic Division Progress Time Sensing 20sec. Water Supply 2min. 10min. Pre Wash 8min. Drain 1min. B-Spin 1min. Middle Spin 3min. Sensing 20sec. Water Supply 2min. 70min. 60min. Wash 1 35min. (Heating) 30min. 20min.
  • Page 39 Wool Delicate Hand Wash Quick 30 Rinse+Spin Division Progress Time Soak 30min. 2min. Water Supply 1min. 15min. Wash 1 10min. (Heating) 5min. 20min. Wash 2 10min. 5min. Drain 1min. B-Spin 1min. Middle Spin 4min. 2min. Water Supply 1min. Rinse 1 3min.

  • Page 40: Function Of The Convenient Service

    8. FUNCTION OF THE CONVENIENT SERVICE The test mode of the operation You can check the PCB AS and the operation of the washing machine simply. • The method to test and operate 1 Press the Power button. 2 Press the Option button 3 times while press the Temp button. At this time, the version is displayed on the Custom LED 3 Whenever the Time Delay button is pressed, the washing machine is operated as following.
  • Page 41 The spinning test mode You can continually spin the washing machine with constant speed. • The method to test and operate 1 Press the Power button. 2 Press the Time Save button 3 times while press Temp button. 3 “300” displays on “18:88 LED”. 300 means the spinning rpm. You can adjust the spinning rpm by pressing Spin button.

  • Page 42: Troubleshooting Guide

    9. TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. SYMPTOM CAUSE SOLUTION...
  • Page 43 SYMPTOM CAUSE SOLUTION Washer does not start. Electronical power cord may not be Make sure plug fits tightly in wall outlet. plugged in or connection may be loose. House fuse blown, circuit breaker Reset circuit breaker or replace fuse. tripped, or a power outage has Do not increase fuse capacity.
  • Page 44 MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. WATER INLET The water level sensor (sensor pressure) is an inferior product Change the water level sensor...
  • Page 45 MESSAGE ERROR CAUSE SOLUTION The water temp. is over 45°C in delicate & wool course. WATER TEMP. Change the thermistor wash. ERROR (The thermistor wash is an inferior product or broke down.) The heater wash dose not work. HEATER WASH Change the heater wash.

  • Page 46: Wiring Diagram

    10. WIRING DIAGRAM WIRING DIAGRAM...
  • Page 47 DAEWOO ELECTRONICS CORP. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M No. : PRINTED DATE: Apr. 2008...
