INSTRUCTIONS
Welcome to the carefree radio control experience that is Electra. With the flip of a switch you're flying! No fuel
or messy exhaust oil to clean. No adjustments to make on an engine. Electra performs like a thoroughbred
but has a stable pony temperament. She is based on the proven and popular Gentle Lady sport sailplane, but
has been modified for the higher performance demands of electric flight. Building is easy, but carefully FOL-
LOW THESE STEP-BY-STEP INSTRUCTIONS to prevent simple mistakes. Many a modeler has built two
right wings because he failed to follow the instructions. You'll also find many installation and flying tips includ-
ed. We think you will find electric flying to be a quiet, yet exciting change of pace−maybe even "Electra-fying!"
WARNING!
THIS IS NOT A TOY! A radio-controlled model is not a toy and is not intended for persons under 16 years old.
Keep this kit out of the reach of younger children, as it contains parts that could be dangerous. A radio-con-
trolled model is capable of causing serious bodily injury and property damage. It is the buyer's responsibility to
build this kit correctly and to properly install the motor, radio, and all other equipment. Test and fly the finished
model only in the presence and with the assistance of another experienced R/C flyer. The model must always
be operated and flown using great care and common sense, as well as in accordance with the safety standards
of the Academy of Model Aeronautics (5151 Memorial Drive, Muncie, IN 47302, 1-800-435-9262). We suggest
you join the AMA and become properly insured prior to flying this model. Also, consult with the AMA or your
local hobby dealer to find an experienced instructor in your area.
Per the Federal Communications
Commission, you are required to use only those radio frequencies specified "for Model Aircraft."
© copyright 1986
Pt. # 2083 4/00
