MS-6592 ATX Mainboard
Run VGABIOS if S3 Resume
Selecting Enabled allows BIOS to call VGA BIOS to initialize the VGA card
when system wakes up (resumes) from S3 sleep state. The system resume
time is shortened when you disable the function, but system will need an AGP
driver to initialize the VGA card. Therefore, if the AGP driver of the card
does not support the initialization feature, the display may work abnormally
or not function after resuming from S3.
Power Management/APM
This item is used to select the degree (or type) of power saving and is
related to the mode: Suspend Time Out. There are three options for power
management:
Min Saving
Max Saving Maximum Power Management. Suspend Time Out =
User Define Allows end users to configure the Suspend Time Out
Suspend Type
This setting allows you to select the type of Suspend mode. Setting options:
Stop Grant (saves the state of the entire system to disk and then powers off the
system), PwrOn Suspend (the CPU and core system remain powered on in a
very low-power state).
MODEM Use IRQ
This setting names the interrupt request (IRQ) line assigned to the modem (if
any) on your system. Activity of the selected IRQ always awakens the system.
Setting options: 3, 4, 5, 7, 9, 10, 11, NA.
Suspend Time Out
If system activity is not detected for the length of time specified in this
field, all devices except CPU will be shut off. Settings: Disabled, 1 Min, 2
3-20
files is saved to main memory that remains powered
while most other hardware components turn off to save
energy. The information stored in memory will be used
to restore the system when a "wake up" event occurs.
Minimum Power Management. Suspend Time Out =
1 Hour.
1 Min.
field.
