Installing RIMM and C-RIMM Modules

1.
The RIMM slot has 2 Notch Keys, so the RIMM memory module can only
fit in one orientation.
2.
Insert the RIMM memory module vertically into the RIMM slot. Then
push it in.
3.
The plastic clips at sides of the RIMM slot will automatically close.
4.
You may insert another RIMM module or a C-RIMM module (as shown
below) in the unused slot to ensure the system's proper operation.
2-8
NOTCH
RIMM Module
C-RIMM Module
