- Page 1 5259IG PLEASE ENSURE YOU HAVE FULLY READ AND UNDERSTOOD THIS GUIDE BEFORE INSTALLATION! Watch the video online WWW.THERMOGROUPUK.COM 5259 Touch Screen Thermostat Installation YOUR STEP-BY-STEP GUIDE TO THE PERFECT INSTALLATION STOCK NO 5259 STOCK NO 5275 STOCK NO 5267...
- Page 2 This document will provide a step-by-step guide to a perfect installation, details on your warranty and how to get Technical Support should you Thermogroup UK shall not be liable for any other expense, loss or need it. damage; whether direct, indirect, incidental, consequential or exemplary...
- Page 3 REGULATIONS IP32 5259 is IP32 rated so is suitable for safe installation in bathrooms. All electrical circuits in bathrooms must be protected by a 30mA RCD. The instructions we supply include as much information as possible to ensure that all installations comply with current electrical regulations. Please call our freephone customer care line if in any doubt on 0800 019 5899.
- Page 4 5259IG Stage 1: How to install your thermostat Step 2: Getting an even temperature Step 3: Removing the face plate Step 1: Conduit Installation Cavity wall: Position your conduit into your The conduit and sensor should be positioned back box and feed it down through the wall centrally between two runs of heating cable to PRO TIP cavity.
- Page 5 5259IG Stage 1: How to install your thermostat E a r t h E a r t h Step 7: Wiring the Thermostat Step 8: Detailed wiring schematic Step 9: Slide the thermostat into the back box Pull the wires through from your heating Position the cables as shown above and Slide the thermostat into position.
-
Page 6: Before You Start
Sensor mode Down button The 5259 has three sensor settings. Air Sensor (IN), Floor Sensor (OUT) and Air Sensor with Floor Limit (All). We recommend Floor Sensor (OUT) for the most accurate control. The thermostat sensor is defaulted to “IN” so Function 1: Set the time &... - Page 7 5259IG Stage 2: Programming your thermostat Menu button Periods 1 - 6 Manual control mode °C °C Heating on Function 2: Manual Mode Function 3: Heating schedule continued You can switch between Manual mode and your custom Schedule to advance to (period 5) and select the desired time by tapping using...
- Page 8 Feel free to contact us at Bridge House. all on the Thermogroup UK website. Open 07:30 – 16:30 Mon - Fri Thermogroup UK, Bridge House, Hop Pocket Lane, Paddock Wood, 0800 019 5899 WWW.THERMOGROUP UK.COM...
