- Page 1 5220A / 5226A Thermotouch 7.6iG Programmable thermostat for Electric Underfloor Heating Installation & User Guide...
-
Page 2: Table Of Contents
Contents Compatibility Compatability Sensor probes This thermostat is compatible with Thermogroup NTC 10kΩ @ 25°C What’s in the box? floor sensor probes. Before you start Installing Thermotouch Heating systems This thermostat is compatible with all Thermogroup electric Underfloor Wiring diagram Heating systems. -
Page 3: What's In The Box
What’s in the box? Before you start Check you’ve got everything: Thermotouch 7.6iG should be: • Programmable thermostat • Installed at least 1.2m from the floor • Floor sensor probe (3m) • On an internal wall • Floor sensor conduit (2m) •... -
Page 4: Installing Thermotouch
The Underfloor Heating cold tail should be pulled up through the electrical the installation. plate, and the sensor probe installed (in the conduit provided) within the CAUTION wall cavity or pre-chased channel in a solid wall. High Voltage Cables 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631... - Page 5 Locate the thermostat onto the black steel clips of the mounting plate. 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631...
-
Page 6: Wiring Diagram
The floor temperature sensor is not polarity sensitive. 230/240V AC Supply Live 230/240V AC Supply Neutral UFH Neutral (Load N) 16amps UFH Live (Load L) 16amps Earth (Ground) Sensor connections (No polarity) 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631... - Page 7 Observe any maximum temperature guidelines from your floor manufacturer. (Optional landscape mounting plate 5221/5223) Warning - Do not force the thermostat into place as this will break the clips and result in being unable to install the unit. 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631...
-
Page 8: User Interface
4. Heating on icon 8. Down arrow 12. Manual mode icon scheduled temperature change. The thermostat will then revert to the 13. Schedule mode icon preset heating schedule. 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631... - Page 9 (Sat & Sun) on a separate schedule. No Numbers - Program off. To be used as manual only. What is a heating event? A heating event is any opportunity to change the temperature in your heating schedule. 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631...
-
Page 10: Heating Schedule
Event 3 Home Comfort (or “On”) temperature between 20 - 28°C. Please note all times (even if these are ‘off’ times) need to be consecutive and the times cannot run over midnight. 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631... -
Page 11: Energy Saving Features
When the Open Window Detection feature is enabled, your thermostat can detect sudden drops in temperature and will switch off your heating to eliminate wasted energy. Your thermostat will come back on after 30 minutes, provided the temperature has stabilised. 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631... - Page 12 7 days 123456 (6 days the same +1) programmed 12345 (5 days the same + 2) independently No numbers - Program off Status after power LA: On as before, OF: Off failure 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631...
-
Page 13: Factory Reset & Key Lock
Please note that the IP Rating IP30 current date and time that has been set will not be erased. Width 85mm Height 115mm Depth 46mm (31mm in wall) 1300 368 631 www.thermogroup.com.au www.thermogroup.com.au 1300 368 631... -
Page 14: Troubleshooting Guide
Incompatible 12KΩ then it is likely to be a sensor probe from a different sensor manufacturer and will need to be replaced with a Thermogroup If there is a sensor connected then it may be faulty. Disconnect 10KΩ sensor probe. - Page 15 Service and Support Thermogroup PO Box 822 Leeton NSW 2705 AUSTRALIA Phone: 1300 368 631 Technical Line: 1300 989 464 www.thermogroup.com.au sales@thermogroup.com.au Watch the video guide on our website www.thermogroup.com.au...
