Summary of Contents for Thermogroup Thermotouch Manual Glass 5215

  • Page 1 5215 / 5216 Thermotouch Manual Glass Manual thermostat for electric underfloor heating Installation & User Guide...
  • Page 2: Table Of Contents

    Contents Compatability What’s in the box? Before you start Installing Thermotouch Wiring diagram Switching on your system Settings User interface Technical data Key lock 1300 368 631 www.thermogroup.com.au...
  • Page 3: Compatability

    Compatibility Thermotouch Manual Glass is compatible with Thermogroup NTC 10K floor sensor probes. NTC 10k @ 25°C If your existing floor probe is from another thermostat manufacturer and is not compatible, set your thermostat to ambient temperature sensing mode. (Not advisable for timber or other temperature sensitive floors).
  • Page 4: What's In The Box

    • Manual thermostat (5215 or 5216) • Floor sensor probe (3m) • Floor sensor conduit (2m) • Fixing screws • Installation guide • Deep electrical back box You will also need: • Electrical screwdriver • Electrical test meter 1300 368 631 www.thermogroup.com.au...
  • Page 5: Before You Start

    • Away from drafts or heat influences • Installed so that the floor sensor probe can be laid in a heated area of the floor • Installed by a qualified electrician, in line with current electrical regulations and relevant local standards www.thermogroup.com.au 1300 368 631...
  • Page 6: Installing Your Thermostat

    You will be installing Thermotouch as part of a high voltage mains electrical circuit. To ensure your safety and to protect the thermostat, switch off the mains power before you start the installation. CAUTION High Voltage Cables 1300 368 631 www.thermogroup.com.au...
  • Page 7 The underfloor heating cold tail should be pulled up through the back box, and the sensor probe installed (in the conduit provided) within the wall cavity or pre chased channel in a solid wall. www.thermogroup.com.au 1300 368 631...
  • Page 8 Underfloor heating cold tails and floor sensor probes can be extended up to 50m. Connect multiple heaters to the thermostat in parallel. 50m max. 1300 368 631 www.thermogroup.com.au...
  • Page 9 (2) to release the clips holding the back plate and the thermostat fascia together. Disconnect the white ribbon cable. Do not try to force the back plate off without first pushing the fascia down to relase the clips! www.thermogroup.com.au 1300 368 631...
  • Page 10: Wiring Diagram

    Connect the Thermostat to the underfloor heating (UFH) cold tail, power supply and floor temperature sensor. The floor temperature sensor is not polarity sensitive. 220-240V AC Supply Live 220-240V AC Supply Neutral UFH Neutral (Load N) UFH Live (Load L) Earth (Ground) Sensor connections (No polarity) 1300 368 631 www.thermogroup.com.au...
  • Page 11 Installing your thermostat 6. Fix mounting plate in position Use a cross-head screwdriver to fix the mounting plate to the back box in the wall. Now you can connect the white ribbon cable to the fascia. www.thermogroup.com.au 1300 368 631...
  • Page 12 Installing your thermostat 7. Fix thermostat fascia in place Locate the thermostat onto the mounting plate and push down to clip in place. 1300 368 631 www.thermogroup.com.au...
  • Page 13: Switching On Your System

    The temperature of your underfloor heating should be increased gradually to avoid thermal shock in the floor. Start at 15°C and work up to your desired temperature 2-3°C per day. Observe any maximum temperature guidelines from your floor manufacturer. www.thermogroup.com.au 1300 368 631...
  • Page 14: Settings

    When you are finished, leave the thermostat idle for 30 seconds. It will automatically save your settings and switch off. Switch the unit on by pressing to continue using the thermostat with your new settings. 1300 368 631 www.thermogroup.com.au...
  • Page 15 Status after power failure after power failure 5215: 5101 V1.1 Software version 5216: 5101 V1.1 Factory reset rE (yes) Backlight timer 10 secs - 300 secs (5 mins) Backlight brightness level 1 (min), 2, 3, 4 (max) www.thermogroup.com.au 1300 368 631...
  • Page 16: User Interface

    User interface 1. Measured temperature 5. Power button 2. Heating on icon 6. Down arrow 3. Lock icon 7. Set temperature 4. Up arrow 1300 368 631 www.thermogroup.com.au...
  • Page 17: Technical Data

    Maximum load Backup storage EEPROM Temperature range 5 ~ 80°C (0.5°C increments) Accuracy ±0.5°C Sensor rating NTC 10kΩ @ 25°C Consumption Warranty 3 years IP Rating IP20 Width 85mm Height 85mm Depth 46mm (31mm in wall) www.thermogroup.com.au 1300 368 631...
  • Page 18: Heating Schedule

    7 seconds. Factory reset Find menu item 10 in the advanced settings. Press and then press The thermostat will switch off and reset to factory settings. This will totally erase the heating program and any adjusted settings. 1300 368 631 www.thermogroup.com.au...
  • Page 19 Notes www.thermogroup.com.au 1300 368 631...
  • Page 20: Service And Support

    Service and Support Thermogroup PO Box 822 Leeton NSW 2705 AUSTRALIA Phone: 1300 368 631 Technical Line: 1300 989 464 www.thermogroup.com.au sales@thermogroup.com.au Watch the video guide on our website www.thermogroup.com.au...

This manual is also suitable for:

Thermotouch manual glass 5216
