M U L T I M E D I A A U D I O A N D V I S U A L
Instruction Manual
MO DEL : SB-5548
8 x8 V IDEO -AUDIO M ATRIX S WITC HER
V ID E O -A U D O M at ri x S witc he r S er ie s
Tha nk y o u fo r p urc ha sing the SB- 5548 A V M a trix Sw itc he r. Y o u w ill find this unit e a sy to insta ll
a nd hig hly re lia b le b ut it is e sse ntia l tha t y o u re a d this m a nua l thro ug hly b e fo re a tte m p ting to
use 8x 8 C o m p o site V id e o - Ste re o A ud io M a trix Sw itc he r.
P a rt N o. : E N C L 0 0 5 5 4 8 A 0 0 A 0
Advertisement
Table of Contents
Related Manuals for Shinybow USA SB-5548
Summary of Contents for Shinybow USA SB-5548
- Page 1 M U L T I M E D I A A U D I O A N D V I S U A L Instruction Manual MO DEL : SB-5548 8 x8 V IDEO -AUDIO M ATRIX S WITC HER V ID E O -A U D O M at ri x S witc he r S er ie s Tha nk y o u fo r p urc ha sing the SB- 5548 A V M a trix Sw itc he r.
-
Page 2: Safety Information
SAFETY INFORMATION Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit, use only the original factory packing. Read all documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. -
Page 3: Package Contents
It completely eliminates the need to constantly move around audio and video input and output cables. The SB-5548 is useful for Matrix signals from AV source devices (such as: VCRs, Camcorders, Video Game Consoles, Video CDs, DVDs, Satellite Receivers, CATV Set Top Boxes, etc.) to AV destination devices (such as: HDTV, LCD TVs, Plasma TV Sets, Video Projectors, etc.). -
Page 4: Front Panel
When not using the unit for a long period of time. Insure that the AC power cord is disconnected from the wall outlet. The AC wall outlet should be installed near to the unit and be easily accessible. Do not plug in or attempt to operate an obviously damaged unit. PAGE 4 SB-5548 INSTRUCTION & OPERATION MANUAL... -
Page 5: Rear Panel
OUTPUT OUTPUT OUTPUT DC POWER INLET The SB-5548 is fitted with a DC power plug-park Power Jack: input connector. Please ensure that the plug-park DC Jack - inner OD O 2.1mm (+ ) used is of an approved type and is of sufficient Outside OD O 5.5mm (GND) -
Page 6: Remote Control
REMOTE CONTROL Before making any connections to the SB-5548. Observe the following: > Ensure the mains voltage supply matches the label on the supplied plug- > Connect all audio video sources and destination equipment Pack (+/- 10%) > power up all source and destination audio-visual sources >... -
Page 7: Features And Specifications
DC12V / 2A (consumption 1250mA Max) Use Universal Switch Type 50/60Hz,100~230 VAC Shipping Weight : 3.25 Kgs / 5.41 lb As product improvements are continuous, specifications are subject to change and without notice. PAGE 7 SB-5548 INSTRUCTION & OPERATION MANUAL... -
Page 8: Rs-232 Serial Interface
- Where X is Output Number (1-8) and Y is Number (1-8) Unit will respond with SBUD0XOY - Where X is Output Number (1-8) and Y is Input Number (1-8) Example : Send Input 8 to Output 3 SBI08O03 -Send SBUD08O3 -Rcvd PAGE 8 SB-5548 INSTRUCTION & OPERATION MANUAL... -
Page 9: Rs-232 Protocol Commands
- Reset every output to Input 1 Unit will respond with SBRSTACK - Unit has reset each Output to Input 1 Example : Reset all outputs to Input 1 SBALLRST -Send SBRSTACK -Rcvd PAGE 9 SB-5548 INSTRUCTION & OPERATION MANUAL... -
Page 10: Typical Application
AUDIO - Stereo Audio (AR/AL), connector with RCA OUTPUT 1 ~ 8 PORT HDTV DISPLAY SIGNALS : COMPOSITE VIDEO - Composite Video, connector with RCA AUDIO - Stereo Audio (AR/AL), connector with RCA PAGE 10 SB-5548 INSTALLATION & OPERATION MANUAL... -
Page 11: Limited Warranty
Replace any cable exhibiting these problem. You also must use the highest quality cables if you want to achieve the best results. Poor quality cables will provide poor quality signals. PAGE 11 SB-5548 INSTRUCTION & OPERATION MANUAL... - Page 12 M U L T I M E D I A A U D I O A N D V I S U A L 1399 Wildfire Lane | Frisco, TX 75034 1-877-SHINY-USA 1-877-744-6987 1-972-377-2508 www.shinybowusa.com sales@shinybowusa.com...
