CORDLESS
SCREWDRIVER
TORCH KIT
3.6V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Input:
3.6V
Chuck Size:
6.35mm Keyless
No Load Speed:
180 /min
Max. Torque:
3.5Nm
Battery:
1.5Ah Li-ion
Charge time:
3 - 5 hours
Weight with Battery:
1.55kg
ozito.com.au
WHAT'S IN THE BOX
Cordless Screwdriver
Screwdriver Bits x 54
Charger
SDL-3100
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ozito SDL-3100
Summary of Contents for Ozito SDL-3100
- Page 1 Screwdriver Bits x 54 3.6V Lithium Ion INSTRUCTION MANUAL SPECIFICATIONS Input: 3.6V Chuck Size: 6.35mm Keyless No Load Speed: 180 /min Charger Max. Torque: 3.5Nm Battery: 1.5Ah Li-ion Charge time: 3 - 5 hours Weight with Battery: 1.55kg ozito.com.au SDL-3100...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS SCREWDRIVER 1. CHARGING 1 Magnetic Bit Holder 6 Sure Grip Handle This tool is recommended for the use with a residual current 2 LED Worklight 7 LED Torch device with a rated residual current of 30mA or less. 3 Handle Lock Switch 8 Torch On/off Switch 4 Forward/ Reverse Lever... - Page 3 2. MAGNETIC BIT HOLDER 3. SWIVEL HANDLE Installing CRV Bits Inline Position 1. Insert the CRV bit directly into the magnetic bit holder. 1. Slide and hold the handle locking switch forward. 2. Rotate the handle clockwise until it clicks into position. 2.
-
Page 4: Operation
“ON” position. the “OFF” position. Note: Do not force the screwdriver or apply side pressure to elongate the hole. Let the screwdriver do the work. SDL-3100... -
Page 5: Maintenance
Some dust created by power sanding, sawing, grinding, drilling and other construction activities contain chemicals known to Note: Ozito Industries will not be responsible for any damage or cause cancer, birth defects or other reproductive harm. Some examples of injuries caused by repair of the screwdriver by an unauthorised these chemicals are: person or by mishandling. - Page 6 Tool: 3.6V Li-Ion Screwdriver Torch Kit SPARE PARTS Model No. SDL-3100 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. Switch...
-
Page 7: Electrical Safety
Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock. -
Page 8: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0513...
