- Page 1 HANDLE Spade Handle Drill DRILL 1050W Side Handle INSTRUCTION MANUAL SPECIFICATIONS Motor: 1050W Input: 230-240V ~ 50Hz Chuck Key Chuck Size: 13mm ( ”) Keyed No Load Speed: 0-550/min Drilling Capacities: Timber 50mm Steel 13mm Weight: ozito.com.au Kit Box SHD-3100...
- Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION 1. HANDLES SPADE HANDLE DRILL 1 Chuck 6 Variable Speed Dial WARNING! ENSURE tHE tOOL IS SWItCHED Off AND 2 Side Handle 7 On/Off Trigger DISCONNECtED fROM tHE POWER SUPPLy bEfORE 3 Securing Knob 8 Lock-On Button PERfORMING ANy Of tHE fOLLOWING ASSEMbLy.
- Page 3 OPERATION 2. FITTING & REMOVING ACCESSORIES 3. ON/OFF SWITCH 1 Open the chuck jaws CAUtION! tO REDUCE tHE RISk Of ELECtRICAL slightly larger than SHOCk, tHE USE Of A RESIDUAL CURRENt DEvICE the bit you wish to (RAtED 30mA OR LESS) IS RECOMMENDED. insert.
- Page 4 6 Move the drill bit into the workpiece. Note: Do not force the drill or apply side pressure to elongate the hole. Let the drill do all the work. SHD-3100...
- Page 5 Always replace both carbon brushes at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the drill by an unauthorised person or by mishandling of the drill.
- Page 6 Model No. SHD-3100 How to Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any further questions, please contact Ozito Customer Service on: Australia: 1800 069 486 New Zealand: 0508 069 486...
- Page 7 Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. extension lead for signs of damage, w ear and ageing. Replace the extension lead if damaged or defective.
- Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZItO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0315...
