Altronix HubWayEX16S Installation Manual page 6

Typical Application Utilizing HubSat4D/Di as a Remote Accessory Module
Fig. 5
Wire
Strap
(from
Enclosure
to Door)
White
Lead
115VAC
input,
60 Hz.
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- 6 -
with HubWayEX16S UTP Transceiver Hub:
+ DATA - + DATA -
Primary
In-line
Fuse
Black
Lead
CAUTION: To reduce the risk of electric shock do not open enclosure. There
are no user serviceable parts inside. Refer servicing to qualified service personnel.
non power-limited
OFF OFF
OFF OFF
OFF OFF
OFF OFF
BK BK
non power-limited
XFMR
Green
Lead
(ground)
XFMR
HubWayEX16S Active Hub Unit
