Installation Preparation

Installation Preparation
Make sure that the actual equipment that was shipped to
you matches the design you are expecting to install. The
Sub-Zero built-in line offers the following design alterna-
tives: framed, overlay, flush inset and stainless steel
models. The overlay model has two design applications,
overlay and flush inset.
Each of these design options has specific installation
requirements, which means it is vital that the unit match
your planning and space needs. Before you begin the
installation process, check the exact model number you
need against the model number on the shipping carton.
If the unit you receive does not match your requirements,
contact your Sub-Zero dealer.
TOOLS AND MATERIALS REQUIRED:
• Phillips screwdriver set
• Slotted screwdriver set
• Torx drive screwdriver set
1
• 4' (1.2 m) of / " copper tubing and saddle valve for the
4
water line (4200880)—do not use self-piercing valves
• Copper tubing cutter
• Level—2' (.6 m) and 4' (1.2 m) recommended
• Appliance dolly able to support 700 lbs (317 kg) and
adequate manpower to handle the weight of the unit
• Various sized pliers
• Wrench set
• Allen wrench set
3
• / " hex bolt nut driver
8
• Crescent wrenches
• Cordless drill and assorted drill bits
1
• Masonite, plywood,
or other suitable material to protect finished flooring
• Appropriate materials to cover and protect the home
and its furnishings during installation
/ " pressed fiberboard, cardboard
8
