Built-In Installation
Anti-Tip Bracket Installation
To prevent the unit from tipping forward and provide
a stable installation, the unit must be secured in place
with the anti-tip brackets shipped with the unit.
IMPORTANT NOTE: Placement of the anti-tip brackets is
critical to a stable installation. Failure to properly position
the anti-tip brackets will prevent them from engaging the
unit.
IMPORTANT NOTE: The two anti-tip brackets must be
installed exactly 24" (610) from the front of the rough
opening to the back of the brackets and a minimum of 4"
(102) from the sides of the rough opening. This depth will
3
increase to 26 / " (665) for a flush inset installation based
16
3
on / " (19) deep decorative panels. Proper placement will
4
ensure that the anti-tip brackets engage the anti-tip bar at
the back of the unit.
Anti-Tip Hardware Included
2 Anti-tip brackets
1
12 #12 x 2 / " PH pan HD zinc screws
2
3 3
4 / "–16 x 3 / " wedge anchors
8 4
12 #12 flat washers
1
4 #8–18 x 1 / " PH truss HD screws
4
4 Nylon zip-it wall anchors
IMPORTANT NOTE: For either wood or concrete floor
applications, if the #12 x 2
stud or the wall plate in any of the back holes of the
brackets, use the provided #8–18 x 1
screws and #12 flat washers with the nylon zip-it wall
anchors.
IMPORTANT NOTE: In some installations the subflooring
or finished floor may necessitate angling the screws used
to fasten the anti-tip brackets to the back wall.
WOOD FLOOR APPLICATIONS
After properly locating the anti-tip brackets in the rough
opening, drill pilot holes
wall studs and/or wall plate. Use the #12 x 2
HD zinc screws and #12 flat washers to secure the
brackets in place. Be sure that the screws penetrate
through the flooring material and into wall studs or wall
3
plate a minimum of / " (19). Refer to the illustration on the
4
following page.
1
/ " screws do not hit a wall
2
1
/ " PH truss HD
4
3
/ " (5) diameter maximum in the
16
1
/ " PH pan
2
