CleanMax Zoom Owner's Manual page 9

Models ZM-400 and ZM-600
The vacuum cleaner handle is packed
as a separate component that requires
assembly.
Installing the Handle
1. Release the handle bracket from the
handle tube by removing the two
screws (Fig. 6).
2. Place handle onto the handle tube,
aligning holes with pegs (Fig. 7).
3. Place the handle bracket back into
position
(Fig. 8).
4. Secure with two screws removed in
step 1.
5. Thread cord through cord guides
and proceed with wrapping the cord
(Fig. 9).
6. Wrap the cord clockwise around the
top and bottom cord hooks (Fig.
10). Fasten the plug to the wrapped
cord using the channel on the plug.
When not in use store the appliance
indoors in a clean dry area where it
can't be damaged or cause injury.
Assembling the Vacuum
Fig. 6
Fig. 8
Fig. 10
9
Fig. 7
Fig. 9
