SECTION 1
• Frequency coverage
• Type of emission
• Number of programable channels
• Antenna impedance
• Operating temperature range
• Power supply requirement
• Current drain
(approx.)
• Dimensions (projections not included)
• Weight (with BP-231, approx.)
• Transmit output power
• Modulation
• Max. permissible deviation
• Frequency error
• Spurious emission
• Adjacent channel power
• Audio harmonic distortion
• Residual modulation (with CCITT filter)
• Limiting charact of modulation
• Microphone impedance
• Receive system
• Intermediate frequencies
• Sensitivity
• Squelch sensitivity (at threshold)
• Adjacent channel selectivity
• Spurious response
• Intermodulation
• FM Hum and Noise
(without CCITT filter)
• Audio output power
• Audio output impedance
All stated specifications are subject to change without notice or obligation.
Measurements made in accordance with ETS 300 296.
SPECIFICATIONS
Wide
Middle
Narrow
Digital
Specified Icom's battery packs only (Operatable voltage; 7.2 V DC negative ground)
Stand-
by
RX
Max.
audio
High
TX
power
446.00625–446.09375 MHz (Analog)
446.103125–446.196875 MHz (Digital)
16K0F3E (25.0 kHz)
14K0F3E (20.0 kHz)
8K50F3E (12.5 kHz)
4K00F1D (6.25 kHz)
64 channels (4 zones)
50 Ω (nominal)
−25˚C to 55˚C
80 mA (Analog), 115 mA (Digital)
350 mA
0.5 A
53.0 (W) × 195.0 (H) × 32.5 (D) mm
280 g
0.5 W ERP
Variable reactance frequency modulation
±2.5 kHz
±0.5 kHz
0.25 µW (≤1 GHz), 1.00 µW (>1 GHz)
60 dB
5% typ. (with 1 kHz at AF 60% deviation)
43 dB typ.
70–100% of max. deviation
2.2 kΩ
Double conversion superheterodyne
1st IF; 46.35 MHz, 2nd IF; 450 kHz
26.5 dBµV/m at 20 dB SINAD
26.5 dBµV/m
81.29 dBµV/m
91.29 dBµV/m
86.29 dBµV/m
43 dB typ.
0.5 W typ. at 5% distortion with an 8 Ω load
0.6 W typ. at 5% distortion with a 6 Ω load
8 Ω
