Now Configure the IP Phone as a user
• Open a web browser window from a computer connected to the same local area network as
the OfficeSuite Polycom SoundStation IP 6000 Conference Phone.
• Type in the IP Address from the OfficeSuite Polycom SoundStation IP 6000 Conference
Phone (if static it is the one you assigned earlier and if DHCP it is the one you retrieved from
the step above)
• Hit enter
• When prompted, enter user name "Polycom"
• Enter Password "456"
• Once the Polycom UI opens select "Line"
o Identification
Display Name – Same as named on OfficeSuite URL
Address – type in OfficeSuite ext.
Auth User ID – type in OfficeSuite ext.
Auth password – type in OfficeSuite password for that ext.
o Server 1
Address (type in address to MBG – Sil dependent)
Port – type in 5060
Transport – UDP only
Scroll to bottom hit submit
Wait for phone to reboot
• Select SIP
o Server 1
Address (type in address to MBG – Sil dependent)
Port – type in 5060
Transport – UDP only
o Local Settings
Digitmap – type in x.T|x.#
Digit Timeout – type in 3
Scroll to bottom hit submit
Wait for phone to reboot
• Select General
o Select Audio Processing
Codec Preferences
• Select G.711Mu as 1
• Select G.729AB as 2
• Select the remaining Codecs as Not Used
Scroll to bottom hit submit
Wait for phone to reboot
• Select General – again
o Select Time
SNTP (129.6.15.28 or 29)
