V I I . C O M F O R T A D J U S T M E N T S
After becoming familiar with your scooter's operation, you may find the need to make some adjustments to
increase your comfort
WARNING! Remove the key from the key switch before adjusting the tiller or the seat.
Never attempt to adjust the tiller or the seat while the scooter is in motion.
NOTE: Any nylon insert lock nut removed during the disassembly or adjustment of the scooter must be
replaced with a new nut. Nylon insert lock nuts should not be reused as it may cause damage to the
nylon insert, resulting in a less secure fit. Replacement nylon insert lock nuts are available at local
hardware stores or through your authorised Pride Dealer.
TILLER ANGLE ADJUSTMENT
Your scooter is equipped with an adjustable pivoting tiller that
you can position to maximise your ergonomic comfort.
1. Turn the tiller adjustment knob anticlockwise to loosen the
tiller. See figure 9.
2. Move the tiller to a comfortable position.
3. Turn the tiller adjustment knob clockwise to secure the tiller
in position.
NOTE: In order to lower the tiller to the scooter deck,
you must first remove the seat.
SEAT ROTATION
The seat lock lever is located at the bottom of the right side of
the seat. The lever allows you to lock the seat into one of four
positions: forward, rearward, left, and right.
1. Pull up on the seat lock lever to unlock the seat.
2. Rotate the seat to the desired position.
3. Release the seat lock lever to lock the seat securely in place.
SEAT HEIGHT ADJUSTMENT
The seat can be repositioned to different heights. See figure 10.
1. Remove the seat from your scooter.
2. Use the attached ring to pull and remove the detent pin
from the lower seat post.
3. Raise or lower the upper seat post to the desired seat height.
4. While holding the upper seat post at that height, align the
adjustment holes of the upper and lower seat posts.
5. Fully insert the detent pin.
6. Reinstall the seat.
Go-Go Ultra www.pridemobility.com
Figure 9. Tiller Adjustment
UPPER SEAT POST
LOWER SEAT POST
Figure 10. Seat Height Adjustment
TILLER
ADJUSTMENT
KNOB
DETENT PIN
27
