Owner's Manual
ATTENTION:
Read everything
in this manual
before operating
your scooter.
The Ultimate In Style & Performance
®
Unit 106, Heyford Park Camp Road
Upper Heyford, Oxfordshire OX25 5HA
www.pridemobility.com

Advertisement

Table of Contents

   Summary of Contents for Pride Victory

  • Page 1 Owner’s Manual ATTENTION: Read everything in this manual before operating your scooter. The Ultimate In Style & Performance ® Unit 106, Heyford Park Camp Road Upper Heyford, Oxfordshire OX25 5HA www.pridemobility.com...
  • Page 2 Using your Pride product safely depends upon your diligence in following the warnings, cautions, and instructions in this owner’s manual. Using your Pride product safely also depends upon your own good judgement and/or common sense, as well as that of your provider, caregiver, and/or healthcare profes- sional.
  • Page 3: Table Of Contents

    C O N T E N T S contents INTRODUCTION ......................... 4 SAFETY ............................6 III. SPECIFICATIONS ........................15 IV. YOUR VICTORY ........................17 BATTERIES AND CHARGING .................... 22 VI. OPERATION ..........................26 VII. COMFORT ADJUSTMENTS....................27 VIII. DISASSEMBLY AND ASSEMBLY ..................29 IX.
  • Page 4: Introduction

    Your understanding of these instructions is essential for the safe operation of your new Pride Scooter. Pride is not liable for damage to property or personal injury arising out of the unsafe use of a Pride Scooter. Pride is also not liable for any property damage or personal injury arising out of the failure of any person and or/user to following the instructions and recommendations set forth in this manual or any other instructions or recommenda- tions contained in other scooter related literature issued by Pride or contained on the Pride Scooter itself.
  • Page 5 I N T R O D U C T I O N MY AUTHORISED PRIDE PROVIDER IS: Name:_______________________________________________________________________________ Address:_____________________________________________________________________________ QUICK REFERENCE INFORMATION: Scooter Model:________________________________________________________________________ Serial Number:__________________________________________________________________________ Purchase Date:________________________________________________________________________ NOTE: If you ever lose or misplace your product registration card or owner’s manual, write to us and we will be glad to send you a new one immediately.
  • Page 6: Safety

    Victory safely. MODIFICATIONS Pride has designed and engineered your Victory to provide maximum mobility and utility. A wide range of accesso- ries is available from your authorised Pride Provider to further customize your scooter to better suit your needs and/or preferences.
  • Page 7 PRE-RIDE SAFETY CHECK Get to know the feel of your Victory and its capabilities. Pride recommends that you perform a safety check before each use to make sure your scooter operates smoothly and safely. For details on how to perform these necessary inspections, see XI.
  • Page 8 WARNING! Never carry an oxygen tank weighing more than 6 kg (13 lbs.) Never fill the rear basket with contents exceeding 7 kg (15 lbs.). Victory...
  • Page 9 1. Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the center/ stop position. 2. Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or when power is removed from the system for any reason. Victory...
  • Page 10 Your Victory is designed to provide optimum stability under normal driving conditions—dry, level surfaces com- posed of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when you will encoun- ter other surface types. For this reason, your scooter is designed to perform admirably on packed soil, grass, and gravel.
  • Page 11 Your scooter is equipped with a manual freewheel lever that, when pushed down, allows the scooter to be pushed. For more information about how to place your scooter into and out of freewheel mode, see IV. “Your Victory.” WARNING! Do not use your scooter in freewheel mode without an attendant present. Personal injury may result.
  • Page 12 Use care that pocketbooks, packages, or scooter accessories do not become caught in lift doors. LIFT/ELEVATION PRODUCTS If you will be traveling with your Victory, you may find it necessary to use a lift/elevation product to aid in transpor- tation. Pride recommends that you closely review the instructions, specifications, and safety information set forth by the manufacturer of the lift/elevation product before using that product.
  • Page 13 WARNING! If you require a positioning belt to safely operate your Victory, make sure it is fastened securely. Serious personal injury may result if you fall from the Victory.
  • Page 14 Avoid reaching or bending while driving your Victory. When reaching, bending, or leaning while seated on your Victory, it is important to maintain a stable center of gravity and keep the scooter from tipping. Pride recommends that the scooter user determine his/her personal limitations and practice bending and reaching in the presence of a qualified healthcare professional.
  • Page 15: Specifications

    (4 Wheel) 40.5 cm (49") (16") 53 - 73 cm (21"- 29") 147 cm 104 cm (58") (41") (3 Wheel Turning Radius) (4 Wheel Turning Radius) 61 cm (24") 9 cm 3.5" 25 cm 10" Figure 5. Victory Tyre Timensions Victory...
  • Page 16 I I I . S P E C I F I C A T I O N S Victory 3-4 specifications Model Number(s) 3-wheel: SCUK1660 4-wheel: SCUK1770 Available Colours Painted: Candy Apple Red, Viper Blue Overall Length (3-wheel) 119 cm (47 in.) Overall Length (4-wheel) 124.5 cm (49 in.)
  • Page 17: Your Victory

    CONTROL CONSOLE ASSEMBLY The control console assembly houses all the controls you need to drive your Victory, including the key switch, the speed adjustment dial, the throttle control lever, the battery condition meter, the horn button, and the light switch.
  • Page 18 Use your right thumb to push the right side of the lever to disengage your Victory’s brake and move forward. n Release the lever and allow your Victory to come to a complete stop before pushing the left side of the lever to move in reverse.
  • Page 19 The charger is located behind the batteries and at the forward right corner of the rear section. n The charger power lead plugs into your Victory’s battery charger by means of a receptacle located on the rear section of your Victory, near the main circuit breaker reset button and ammeter.
  • Page 20 Manual Freewheel Lever Whenever you want to push your Victory for short distances, you can put it in freewheel mode. It is important to remember that when your Victory is in freewheel mode, the braking system is disengaged. Even though the motor of your Victory is disengaged from the drive system when your scooter is put in freewheel mode, the motor can still run if the throttle lever is pushed.
  • Page 21 See figure 8. Anti-Tip Wheels The anti-tip wheels are an integral and important safety feature of your Victory. Do not, under any circumstances, remove the anti-tip wheels from your scooter.
  • Page 22: Batteries And Charging

    6. When the batteries are fully charged, unplug the charger power lead from the wall outlet and then from the charger power lead receptacle. NOTE: There is a charger inhibit function on your scooter. The scooter will not run and the battery condition meter will not operate while the batteries are charging. Victory...
  • Page 23 If you encounter a damaged or cracked battery, immediately enclose it in a plastic bag and call your authorised Pride Provider for instructions on disposal. Your authorised Pride Provider will also have the necessary informa- tion on battery recycling, which is our recommended course of action.
  • Page 24 10. Reconnect the battery tie-down strap. 11. Reinstall the rear shroud and seat. What about public transportation? If you intend to use public transportation with your scooter, you must contact the transportation provider in ad- vance to determine their specific requirements. Victory...
  • Page 25 We work closely with our battery manufacturer to provide batteries that best suit your scooter’s specific electrical demands. Fresh batteries arrive daily at Pride and are shipped fully charged to our customers. During shipping, the batteries may encounter temperature extremes that can influence their initial performance. Heat diminishes the charge on the battery;...
  • Page 26: Operation

    5. Carefully and safely get out of the seat and stand to the side of your scooter. 6. You can leave the seat facing to the side to facilitate boarding your scooter the next time you wish to operate it. Victory...
  • Page 27: Comfort Adjustments

    The seat can be repositioned to one of three different LOCATING HOLES UPPER SEAT POST heights. See figure 12. 1. Remove the seat from your Victory. See VIII. “Dis- LOWER SEAT assembly and Assembly.” POST 2. Use the attached ring to pull and remove the ball detent pin from the lower seat post.
  • Page 28 SEAT LOCK seat and the tiller. See figure 13. LEVER 1. Remove the seat from your Victory. See VIII. “Dis- assembly and Assembly.” SEAT BOLTS 2. Remove the four bolts that fasten the seat platform to the seat base.
  • Page 29: V I I I . D I S A S S E M B L Y A N D A S S E M B L Y

    1. Remove the key from the key switch. See IV. “Your Victory.” 2. Push down on the manual freewheel lever. See IV. “Your Victory.” Putting your scooter in drive mode may make it easier for you to stabilise the rear section.
  • Page 30 Push back on the toggle latch so it locks into place. 6. Connect the front-to-rear cable and both battery har- nesses. 7. Replace the rear shroud. 8. Replace the seat and rotate it until it locks into place. Figure 20. Frame Sections Victory...
  • Page 31: Optional Accessories

    I X . O P T I O N A L A C C E S S O R I E S For information concerning these optional accessories, contact your authorised Pride Provider. Oxygen Holder Double Crutch Holder Single Crutch Holder...
  • Page 32: Basic Troubleshooting

    What if the motor runs but my Victory does not move? n Your Victory was probably left in freewheel mode. When the manual freewheel lever is pulled up, the brakes are disengaged and all power to the transaxle is cut.
  • Page 33: Care And Maintenance

    M A I N T E N A N C E Your Victory requires a minimal amount of care and maintenance. If you do not feel confident in your ability to perform the maintenance listed below, you may schedule inspection and maintenance at your authorised Pride Provider.
  • Page 34: Warranty

    This guarantee does not extend to those items which may need replacement due to normal wear and tear (tyres, belts, bulbs, upholstery, plastic shrouds, motor brushes, fuses, and batteries), or damage to the product caused by misuse or accident for which Pride or its agent cannot be held responsible. This warranty does not include labor or service calls.
