A790
Operation Manual
Part Number:799001190001
7990 0114 3001
R00
(OCT-2006)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A790 and is the answer not in the manual?

Questions and answers

Related Manuals for Getac A790

Summary of Contents for Getac A790

  • Page 1 A790 Operation Manual Part Number:799001190001 7990 0114 3001 (OCT-2006)
  • Page 2 TRADEMARKS All brand and product names are trademarks or registered trademarks of their respective companies. NOTE Information in this manual is subject to change without notice.

  • Page 3: Table Of Contents

    Table of Contents Preface ..................vii Chapter 1 Getting Started .............1-1 Getting the Computer Running..........1-2 Unpacking ................1-2 Connecting to AC Power ...........1-2 Opening the Cover .............1-4 Turning On and Off the Computer........1-5 Taking a Look at the Computer ..........1-6 Right-Side Components .............1-6 Left-Side Components ............1-7 Rear Components...............1-8 Front Components............1-10...
  • Page 4 Euro Symbol ..............2-6 Windows Keys ..............2-6 Function Keys ..............2-6 Fn Key................2-7 Hot Keys ................2-7 Using the Touchpad ..............2-9 Configuring the Touchpad ..........2-11 Using the Touchscreen (Optional) .........2-12 Using the Hard Disk Drive ............2-14 Replacing the Hard Disk Drive ........2-14 Using the Video Features............2-17 Configuring the Display Modes ........2-17 Using the Audio Features ............2-19 Connecting Audio Devices ..........2-20...
  • Page 5 Chapter 4 Expanding Your Computer........4-1 Connecting an External Monitor ..........4-2 Connecting a Parallel Device...........4-3 Connecting a Serial Device .............4-4 Connecting an IR Device............4-5 Connecting a USB Device ............4-7 Connecting an IEEE 1394b Device .........4-8 Using PC Cards ...............4-9 PC Card Type..............4-9 CardBus Support..............4-9 Inserting and Removing a PC Card........4-9 System Memory Upgrade ............4-11...
  • Page 6 General Guidelines.............7-3 Cleaning Guidelines ............7-4 Battery Pack Guidelines .............7-4 When Traveling ...............7-5 Chapter 8 Troubleshooting........... 8-1 Preliminary Checklist ..............8-2 Solving Common Problems .............8-3 Battery Problems..............8-4 Bluetooth Problems............8-4 Display Problems ...............8-5 Hardware Device Problems..........8-6 Hard Disk Drive Problems ..........8-6 Infrared Problems...............8-7 Keyboard, Mouse and Touchpad Problems .......8-7 LAN Problems ..............8-8 WLAN Problems..............8-8...
  • Page 7 European Union CE Marking and Compliance Notices ... B-9...

  • Page 8: Preface

    Preface This manual contains information that will help you operate the computer. It is divided into 8 chapters and 2 appendices. Chapter 1, Getting Started, takes you through the process of setting up the computer and identifying its external components. Chapter 2, Operating Your Computer, tells you how to use the computer’s components and features.

  • Page 9: Notational Conventions

    Appendix B, Regulatory Information, provides regulatory statements and safety notices on your computer. Notational Conventions Throughout this manual, the following conventions are used to distinguish elements of text. NOTE: identifies additional information that requires special attention. CAUTION: identifies important information which, if not followed, may result in loss of data or damage to the computer.

  • Page 10: Chapter 1 Getting Started

    CHAPTER Getting Started Congratulations on purchasing this computer. This high performance notebook computer is especially designed for the practical applications of warehouses, automobiles, vehicles, public security, repairing, assisting the handicapped, and other demanding situations where conventional notebook computers just cannot measure This chapter first tells you step by step how to get the computer up and running.

  • Page 11: Getting The Computer Running

    Getting the Computer Running This section guides you through the procedures for getting the computer ready for operation. Unpacking After unpacking the shipping carton, you should find these standard items: Notebook computer Accessories: − AC adapter (100~240 VAC, 50/60 Hz) −...
  • Page 12 NOTE: Power Supply Cord: (optional) Detachable, minimum 1.5 m long. Listed, rated minimum 125 V, 7 A, having a 2/18 AWG, type SVT flexible cord. One end terminates with a parallel blade, molded-on, attachments plug with a 7 A, 125 V (NEMA 1-15P) configuration;...

  • Page 13: Opening The Cover

    CAUTION: When you disconnect the AC adapter, disconnect from the electrical outlet first and then from the computer. A reverse procedure may damage the AC adapter or the computer. When unplugging the connector, always hold the plug head. Never pull on the cord. NOTE: When the AC adapter is connected, it also charges the battery pack.

  • Page 14: Turning On And Off The Computer

    Turning On and Off the Computer Turning On 1. Make sure the computer is connected to AC power. 2. Press the power button. 3. Each time the computer is turned on, it performs a Power-On Self Test (POST), and the operating system such as Windows should start.

  • Page 15: Taking A Look At The Computer

    Taking a Look at the Computer This section identifies the external components of the computer and briefly describes the function of each component. NOTE: Depending on the model you purchased, the appearance of your computer may not exactly be the same as those shown in this manual. Right-Side Components Component Description...

  • Page 16: Left-Side Components

    Left-Side Components Component Description See Also May contain an extra battery pack or wireless Bay2 Slot modem (GPRS/GSM, CDMA) module. Supplies power to your computer when external P. 3-3 Battery Pack power is not connected. Getting Started...

  • Page 17: Rear Components

    Rear Components Component Description See Also Connects the AC adapter. P. 1-3 Power Connector Each of the two ports connects a USB device, P. 4-7 USB Ports such as a USB floppy drive, USB flash disk, printer, digital camera, joystick, and more. For connecting to a Port Replicator / car mount Docking Port (both are available as an option).
  • Page 18 Component Description See Also Connects a serial device, such as an external P. 4-4 Serial Port modem. Locks the computer to a stationary object for P. 7-2 Kensington security. Lock Connects an IrDA-compliant device for wireless P. 4-5 IR Port data transfer.

  • Page 19: Front Components

    Front Components Component Description See Also Locks the top cover. P. 1-4 Top Cover Latch Sends out sound and voice from the computer. P. 2-19 Stereo Speaker Allows you to carry your computer for an easy Handle grip. 1-10 Getting Started...

  • Page 20: Top-Open Components

    Top-open Components Component Description See Also Displays the output of the computer. P. 2-17 LCD Screen Can also have the optional touchscreen P. 2-12 function. Getting Started 1-11...
  • Page 21 Component Description See Also Show the current status of the computer’s Device devices. Indicators Scroll Lock indicator P. 2-4 Caps Lock indicator P. 2-4 Num Lock indicator P. 2-6 Hard disk drive in-use indicator P. 2-14 Battery charge indicator – P.

  • Page 22: Where To Go From Here

    Where to Go from Here As your computer is ready for operation, you may want to do any of the following now: For this purpose… Do this… To know more about the computer… Go on to the next chapter. To install the operating system if your See the operating system manual.

  • Page 23: Chapter 2 Operating Your Computer

    CHAPTER Operating Your Computer This chapter provides information about the use of the computer. If you are new to computers, reading this chapter will help you learn the operating basics. If you are already a computer user but are new to notebook computers, you may choose to read only the parts containing information unique to your computer.

  • Page 24: Starting And Stopping The Computer

    Starting and Stopping the Computer There are a number of ways to start and stop the computer. Starting the Computer You always start the computer using the power button. A computer starts up with an operating system (OS) existing on the storage device such as the hard disk;...
  • Page 25 To stop in Do this… To start up or this mode… resume again Hibernation Depending on your settings in Windows, Press the power you can place the computer in button. Hibernation mode by: • Closing the display cover. • Pressing Fn+F12 •...

  • Page 26: Using The Keyboard

    Using the Keyboard NOTE: Your computer features backlight for your keyboard to help you see the keyboard keys during poor lighting conditions. Press Fn+F8 to turn it on/off (see Hot Keys later in this chapter). Your special shower-proof and dust-proof rubber keyboard has all the standard functions of a full-sized computer keyboard plus an added for specific functions.

  • Page 27: Cursor-Control Keys

    Cursor-Control Keys NOTE: The word “cursor” refers to the indicator on the screen that lets you know exactly where on your screen anything you type will appear. It can take the form of a vertical or horizontal line, a block, or one of many other shapes. Numeric Keypad A 15-key numeric keypad is embedded in the typewriter keys as shown next:...

  • Page 28: Euro Symbol

    Numeric keys facilitate entering of numbers and calculations. When Num Lock is on, the numeric keys are activated; meaning you can use these keys to enter numerals. NOTE: When the numeric keypad is activated and you need to type the English letter in the keypad area, you can turn Num Lock off or you can press Fn and then the letter without turning Num Lock off.

  • Page 29: Fn Key

    Fn Key key, at the lower left corner of the keyboard, is used with another key to perform the alternative function of a key. The letter “Fn” and the alternative functions are identified by the color of blue on the keytop. To perform a desired function, first press and hold , then press the other key.
  • Page 30 Description Switches the display output to one of the following when an external device is connected. Upon booting the system with CRT: LCD & CRT Upon booting the system with DVI: LCD & DVI NOTE: When in full screen DOS mode, or when playing DVD or MPEG file, display switching is not allowed.

  • Page 31: Using The Touchpad

    Using the Touchpad CAUTION: Do not use a sharp object such as a pen on the touchpad. Doing so may damage the touchpad surface. NOTE: For optimal performance of the touchpad, keep your fingers and the pads clean and dry. When tapping on the pad, tap lightly. Do not use excessive force. The touchpad is a pointing device that allows you to communicate with the computer by controlling the location of the pointer on the screen and making selection with the buttons.
  • Page 32 Term Action Point Move your finger on the pad until the cursor points to the selection on the screen. Click Press and release the left button. –or– Tap gently anywhere on the pad. Double- Press and release the left button twice in quick succession. click –or–...

  • Page 33: Configuring The Touchpad

    Configuring the Touchpad You may want to configure the touchpad to suit your needs. For example, if you are a left-handed user, you can swap the two buttons so that you can use the right button as the left button and vise versa. You can also change the size of the on-screen pointer, the speed of the pointer, and so To configure the touchpad, you can use the standard Microsoft or IBM PS/2 driver if you are using Windows to take advantage of more powerful...

  • Page 34: Using The Touchscreen (Optional)

    Using the Touchscreen (Optional) CAUTION: Do not use a sharp object such as a ballpoint pen or pencil on the touchscreen. Doing so may damage the touchscreen surface. The touchscreen is a touch-sensitive device that allows you to communicate with the computer by controlling the location of the pointer on the screen and making selection with the buttons.
  • Page 35 Term Action Drag and Press lightly on the touchscreen and move your finger drop until you reach your destination (drag). Finally, release your finger (drop) when you finish dragging your selection to the destination. The object will drop into the new location.

  • Page 36: Using The Hard Disk Drive

    Using the Hard Disk Drive Your computer comes with a hard disk drive as drive C. A hard disk drive is a storage device with non-removable, rotating, magnetic storage platters inside it. It is where your operating system and application software programs are stored.
  • Page 37 4. Remove the two screws securing the hard disk drive compartment. 5. Lift up the handle and pull on it to remove the hard disk drive compartment. 6. Remove the two screws securing the hard disk drive to the compartment and remove the steel plate cover. Operating Your Computer 2-15...
  • Page 38 7. Lift up the hard disk drive from the compartment and replace it with a new one. 8. Replace the steel plate cover and replace the two screws to secure the hard disk drive to the compartment. 9. Replace the hard disk drive compartment to the computer and secure with two screws.

  • Page 39: Using The Video Features

    Using the Video Features The video subsystem of your computer features: 12.1/14.1-inch TFT (Thin-Film Transistor) color LCD display with 1024 768 XGA (eXtended Graphics Array) resolution, or × optional 14.1-inch TFT (Thin-Film Transistor) color LCD display with 1400 1050 SXGA+ / SXGA (Super eXtended Graphics Array) ×...
  • Page 40 For displaying in higher resolutions, you can connect an external CRT monitor that supports higher resolutions. (See “Connecting an External Monitor” in Chapter 4 for more information.) The following table lists the display modes supported by your computer. Display Mode LCD Only CRT Only Simultaneous Display Resolution Colors...

  • Page 41: Using The Audio Features

    Using the Audio Features NOTE: To take advantage of the enhanced audio capabilities, the device driver supplied with your computer must be installed (see chapter 6 for details). If you experience interference while recording, try lowering the microphone recording volume. The audio subsystem of your computer features: External audio connectors ( ) and A set of speakers ( )

  • Page 42: Connecting Audio Devices

    Connecting Audio Devices For higher audio quality, you can send or receive sound through external audio devices. Audio Output Connector ( ) can be connected to the line-in connector of powered speakers with built-in amplifiers, headphones, or earphone set. Microphone Connector ( ) can be connected to an external microphone for recording voice or sound.

  • Page 43: Using The Communication Features

    Using the Communication Features Using the LAN NOTE: To take advantage of the LAN feature, the device driver supplied with your computer must be installed (see chapter 6 for details). The internal 10/100/1000Base-T Ethernet LAN (Local Area Network) module allows you to connect your computer to a network. It supports data transfer rate up to 1000 Mbps.

  • Page 44: Using The Wireless Lan (Optional)

    Using the Wireless LAN (Optional) Depending on your model, an internal Mini PCI wireless LAN (WLAN) card may have been pre-installed by your computer manufacturer at the factory. This card allows you to access corporate networks or the Internet in a wireless environment. The WLAN features include: Peer-to-Peer (Ad-Hoc) and Access Point (Infrastructure) modes support...

  • Page 45: Configuring The Wlan

    Configuring the WLAN After driver installation, you can use the WLAN utility to configure and monitor your WLAN connection. If you are using Windows XP, you can also use its built-in WLAN utility. Follow this procedure to launch the WLAN utility in Windows XP: 1.
  • Page 46 4. If any wireless network is detected, the following window appears on screen. 5. Click to select a wireless network to connect to, and then click Connect. 6. Depending on the settings, you may be asked to enter a wireless security password (encryption key).

  • Page 47: Using The Modem

    Using the Modem NOTE: To take advantage of the modem feature, the device driver supplied with your computer must be installed (see chapter 6 for details). The internal 56 K fax/data modem allows you to use the telephone line to communicate with others by fax, email, or connect to an online service or bulletin board.

  • Page 48: Using The Wireless Modem (Optional)

    Using the Wireless Modem (Optional) NOTE: To take advantage of the wireless modem feature, the USB-to-COM driver supplied with your computer must be installed (see chapter 6 for details). Depending on your model, your computer includes an integrated GSM (Global System for Mobile Communications) / GPRS (General Packet Radio Service) feature.

  • Page 49: Using The Gps (Optional)

    Connecting Using GPRS Your computer can receive General Packet Radio Services (GPRS), a high-speed data-only service that transmits data over a mobile telephone network. In addition, GPRS provides permanent on-line connection. To use GPRS, you must have a subscription to the function with a service provider that supports GPRS.

  • Page 50: Using The Bluetooth Feature (Optional)

    Using the Bluetooth Feature (Optional) NOTE: To take advantage of the Bluetooth feature, the Bluetooth driver supplied with your computer must be installed (see chapter 6 for details). Depending on your model, your computer may incorporate the Bluetooth capability for short-range (about 10 meters) wireless communications between devices without requiring a cable connection.
  • Page 51 2. Double-click the icon, then click on New Connection or click on Bluetooth, then Add New Connection . . . Or right-click the icon, and then click on Add New Connection. 3. The Add New Connection Wizard window appears. Select Express Mode (Recommended), then click on Next.
  • Page 52 4. Select the device to connect to and click on Next. 5. Depending on the type of Bluetooth device that you want to connect to, you will need to enter the pertinent information. 2-30 Operating Your Computer...
  • Page 53 Sending a File 1. Right-click the icon, and then click Wireless File Transfer. The following screen appears. 2. In the Wireless File Transfer window, click Add to browse for the file to send. The file(s) will show on the File/Folder window. 3.
  • Page 54 For detailed information on using the Bluetooth Utility, see the Bluetooth Utility Help on your computer by clicking on Help, then Help . . . 2-32 Operating Your Computer...

  • Page 55: Chapter 3 Managing Power

    CHAPTER Managing Power Your computer operates either on external AC power or internal battery power. This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way. The topics in this chapter include: What is an AC adapter How to charge the battery pack...

  • Page 56: Ac Adapter

    AC Adapter CAUTION: The AC adapter is designed for use with your computer only. Connecting the AC adapter to another device can damage the adapter. The AC power cord supplied with your computer is for use in the country where you purchased your computer.

  • Page 57: Battery Pack

    Battery Pack The Li-ion battery pack is the internal power source for the computer when the AC power is “Off” or not connected. It is rechargeable using the AC adapter. The removable battery pack, with on-line charge capacity, comes standard with your computer. It has 107 watt operating capacity. The computer supports up to three Li-ion battery packs: Primary, Bay1, and Bay2 (Bay1 and Bay2 are optional).

  • Page 58: Initializing The Battery Pack

    The charging times are as follows: Charging Time Battery Type (2400 mah or more Computer is Off Computer is On and per cell) in Idle State Primary (107 watt) 3.5 hours 4.7 hours Bay1 (71 watt) 2.5 hours 3.5 hours Bay2 (71 watt) 2.5 hours 3.5 hours...

  • Page 59: Checking The Battery Level

    Checking the Battery Level NOTE: Any battery level indication is an estimated result. The actual operating time can be different from the estimated time, depending on how you are using the computer. You can check the approximate battery level using the battery meter function of the operating system.
  • Page 60 4. Lift up the handle and pull on it to slide the battery pack off the computer. 5. Slide the front panel off the battery pack and replace it on a new battery pack. 6. Slide the new battery pack into the computer. 7.

  • Page 61: Battery Low Signals And Actions

    Battery Low Signals and Actions Battery Low occurs when the battery has approximately 10 % (Windows default setting) of its charge remaining. The computer gives warning beeps or messages and the Battery Power Indicator ( ) blinks amber (orange) to alert you to take actions. NOTE: You can set up your threshold and signals of Battery Low under Windows.

  • Page 62: Power Management

    Power Management Your computer supports ACPI (Advanced Configuration and Power Interface) for power management. The power management feature allows you to reduce the power consumption for energy saving. With an ACPI-compliant operating system such as Windows 2000 and Windows XP, power supply to different computer components is controlled on an as-needed basis.

  • Page 63: Hibernation

    Hibernation Hibernation is a very useful feature. People frequently open many applications when they use computers. It takes some time to get all these applications open and running, and normally they all have to be closed before the system can be turned off. When you use the hibernation feature, you do not have to close the applications.

  • Page 64: Power-Saving Tips

    Power-Saving Tips In addition to your computer’s automatic power management, you can do your part to maximize the battery’s operating time by following these suggestions. Do not disable Power Management. Decrease the LCD brightness to the lowest comfortable level. If you work with an application that uses a PC card, exit the application when you finish using it.

  • Page 65: Chapter 4 Expanding Your Computer

    CHAPTER Expanding Your Computer You can expand the capabilities of your computer by connecting other peripheral devices. When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter. This chapter gives guidelines on installing and using these devices: External monitor Parallel device Serial device...

  • Page 66: Connecting An External Monitor

    Connecting an External Monitor If you want the benefits of a larger display screen with higher resolution, you can connect an external CRT monitor to your computer. Follow this procedure to connect an external monitor: 1. Make sure that the computer is not turned on. 2.

  • Page 67: Connecting A Parallel Device

    Connecting a Parallel Device Your computer has a parallel port for connecting a parallel device such as printer. The port supports ECP (Extended Capabilities Port) and EPP (Enhanced Parallel Port) modes that turn the standard parallel port into a high-speed bi-directional peripheral port. Follow this procedure to connect a parallel device: 1.

  • Page 68: Connecting A Serial Device

    Connecting a Serial Device Your computer has a serial port for connecting a serial device such as a serial mouse or modem. Follow this procedure to connect a serial device: 1. Make sure the computer is not turned on. 2. Plug the device cable to the serial port on the rear of the computer. 3.

  • Page 69: Connecting An Ir Device

    Connecting an IR Device Your computer has an IR (infrared) port for connecting an infrared- equipped device wirelessly such as another computer, printer, or PDA (Personal Digital Assistant). When using the IR port of your computer to receive data: Place the transmitting device where its IR port faces the IR port of your computer within the effective range −...
  • Page 70 NOTE: During infrared communication, note the following: Do not move the computer and IR device. Do not enter Standby mode. Do not use a cell phone or another IR device near the computer. Avoid strong light such as sunlight or fluorescent light. Disable the screen saver.

  • Page 71: Connecting A Usb Device

    Connecting a USB Device Your computer has two USB ports that supports transfer rates up to 12 MB/s for USB 1.1 devices and 480 MB/s for USB 2.0 devices, such as digital camera, scanner, printer, modem, and mouse. USB is specified to be an industry standard extension to the PC architecture.

  • Page 72: Connecting An Ieee 1394B Device

    Connecting an IEEE 1394B Device NOTE: Your IEEE 1394B port will only function under Windows XP SP2. It is also Windows Vista ready. Make sure that the 1394B driver is installed correctly (see chapter 6 for details). To connect an IEEE 1394A (also known as FireWire 400) device to the computer’s IEEE 1394B (also known as FireWire 800) port, you need an optional FireWire 800/FireWire 400 bilingual cable.

  • Page 73: Using Pc Cards

    Using PC Cards Your computer has a PC card slot. PC cards are credit card-sized peripheral products based on the standards developed by PCMCIA (Personal Computer Memory Card International Association). PCMCIA is a non-profit association for promoting the interchangeability among mobile computers where ruggedness, low power, and small size are critical.
  • Page 74 To insert a PC card: 1. Locate the PC card slot on the right side of the computer. 2. Slide the PC card, with its label facing up, into the slot until the eject button pops out. Eject Button 3. When a new card is seated, the computer will detect it and try to install the appropriate driver.

  • Page 75: System Memory Upgrade

    System Memory Upgrade You can upgrade your computer by changing system memory to a maximum of 2 GB on the two 200-pin DDR2 SO-DIMM slots. However, to avoid damage during the installation procedure, please ask your dealer for help. Expanding Your Computer 4-11...

  • Page 76: Chapter 5 Setup Configuration Utility (Scu)

    CHAPTER Setup Configuration Utility (SCU) SCU is a program for configuring the BIOS (Basic Input/Output System) settings of the computer. BIOS is a layer of software, called firmware, that translates instructions from other layers of software into instructions that the computer hardware can understand.

  • Page 77: When And How To Use The Scu Program

    When and How to Use the SCU Program When to Use You need to run the SCU program when: You see an error message on the screen requesting you to run Setup. You want to restore the factory default settings. You want to modify some specific settings according to the hardware.
  • Page 78 The SCU menu can be divided into four areas: On the top is the menu bar containing the titles of the available menus. Each menu title brings a specific menu. The center column of the menu displays the current configuration information of the system, devices, and memory items.

  • Page 79: Moving Around And Making Selections

    Moving Around and Making Selections In most cases, you must go through two levels to complete the setting for an item: menu title and submenu. Use the keyboard to move around and make selections. A brief description of keyboard usage is listed next: Function Selects a menu title.

  • Page 80: Main Menu

    Main Menu The Main menu contains the system date and time as well as the IDE/SATA interface setting of the system. System Time sets the system time. System Date sets the system date. IDE Channel 0 Master/Slave / SATA Port 0/1 sets the type of storage device installed.

  • Page 81: Advanced Menu

    Advanced Menu The Advanced menu contains the hard disk drive heater as well as the screen display setting during system boot-up. HDD Heater sets if the system automatically turns on the built-in hard disk drive heater for low temperature operation. The options are Enabled and Disabled.

  • Page 82: Intel Menu

    Intel Menu The Intel menu contains the LPC I/O devices and CPU thermal setting of the system. LPC Control Sub-Menu sets the items that control the configuration of various LPC input/output devices that exists on the CRB as well as the National 393 serial input/output devices.

  • Page 83: Security Menu

    Security Menu The Security menu contains the security setting, which safeguard your system against unauthorized use. TPM Support enables or disables TPM (Trusted Platform Module) support. The options are Enabled and Disabled. NOTE: To use the TPM feature, the TPM driver supplied with your computer must be installed (see chapter 6 for details).

  • Page 84: Boot Menu

    Boot Menu The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system.

  • Page 85: Exit Menu

    Exit Menu The Exit menu displays ways of exiting the SCU program. After finishing with your settings, you must save and exit so that the changes can take effect. Exit Saving Changes saves the changes you have made and exits BIOS Setup Utility.

  • Page 86: Chapter 6 Installing Software Drivers

    CHAPTER Installing Software Drivers To take full advantage of the unique features of your computer, some operating systems require custom software, known as drivers, to be installed. If you purchased the computer with Windows pre-installed, your dealer may have already installed the drivers. If not, you need to install the drivers using the driver disc supplied with your computer.

  • Page 87: How To Use The Driver Cd

    How to Use the Driver CD NOTE: • The drivers may have been updated after this manual was published. For driver upgrade, please contact your dealer. • You can always find README or document files on the driver CD. These files contain the latest information from the software supplier.
  • Page 88 To install the necessary driver, just click on the particular option and follow the onscreen instructions to continue and complete installation. Device Driver Ensures the full function of the following drivers. Install this main driver before installing the other drivers. Upon clicking this button, the chipset, VGA, audio, modem, and LAN drivers would be installed one after the other.
  • Page 89 SmartCard Reader Allows your computer to install smartcard reader driver. (Oprion) Bluetooth Allows your computer to connect to Bluetooth (option) -compliant devices. Refer to chapter 2 for detailed instructions on using the Bluetooth feature of your computer. Vehicle Dock Upon clicking this button on the first page, the following screen appears.
  • Page 90 Others Upon clicking on this on the first page, the following screen appears. IMPONTANT IrDA Installs the IrDA hotfix for Windows XP only Dual Core Installs the dual core hotfix for Windows XP only. 1394B Please install the 1394 hot fix and note that 1394B will l be fully supported by Window Vista.

  • Page 91: Touchscreen Driver

    User Guide Upon clicking on this on the first page, allows you to hview the Operation Manual on screen. NOTE: You need Adobe Acrobat Reader to open the manual file supplied on this driver disc. Install the Adobe Acrobat Reader program if you do not have it on your computer by clicking on Get Adobe Reader.
  • Page 92 5. Click on Standard Calibration. 6. Click on the four sides (points) and the plus-sign “+” on the screen to calibrate your touchscreen for use on the computer. Installing Software Drivers...
  • Page 93 Using the OSD NOTE: The OSD utility is an option for you. You can decide whether you would like to have this utility installed. With the OSD utility installed, the utility will be activated and an icon will appear on the system tray every time Windows starts up. A graphic display will appear on the screen to indicate the current status of certain operations (as listed next).
  • Page 94 Icon appears on the screen to indicate that AC power cord has been connected or unplugged. The OSD disappears after a few seconds. AC In AC out Exiting and Reactivating the OSD Utility To exit the OSD utility, right-click on the OSD utility icon on Windows system tray and click on “Exit.”...

  • Page 95: Chapter 7 Caring For The Computer

    CHAPTER Caring for the Computer Taking good care of your computer will ensure a trouble-free operation and reduce the risk of damage to your computer. This chapter gives you guidelines covering these areas of maintenance: How to protect the computer What to note when using and storing the computer How to clean the computer What to note when using the battery pack...

  • Page 96: Protecting The Computer

    Protecting the Computer To safeguard the integrity of your computer data as well as the computer itself, you can protect the computer in several ways as described in this section. Using the Cable Lock You can use a Kensington-type cable lock to protect your computer against theft.

  • Page 97: Taking Care Of The Computer

    Taking Care of the Computer Location Guidelines Use the computer where the temperature is between 0 °C (32 °F) and 55 °C (131 °F). Avoid placing the computer in a location subject to high humidity, extreme temperatures, mechanical vibration, direct sunlight, or heavy dust.

  • Page 98: Cleaning Guidelines

    Cleaning Guidelines Never clean the computer with its power on. Use a soft cloth moistened with water or a non-alkaline detergent to wipe the exterior of the computer. Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the display.

  • Page 99: When Traveling

    When Traveling Before traveling with your computer, make a backup of your hard disk data into optical discs or other storage devices. As an added precaution, bring along an extra copy of your important data. Make sure the battery pack is fully charged. Make sure the computer is turned off.

  • Page 100: Chapter 8 Troubleshooting

    CHAPTER Troubleshooting Hardware, software, or a combination of both can cause computer problems. When you encounter any problem, it might be a typical problem that can easily be solved. This chapter tells you what actions to take when solving common computer problems.

  • Page 101: Preliminary Checklist

    Preliminary Checklist Here are helpful hints to follow before you take further actions when you encounter any problem: Try to isolate which part of the computer is causing the problem. Make sure that you turn on all peripheral devices before turning on the computer.

  • Page 102: Solving Common Problems

    Solving Common Problems For easy reference, the problems are divided into these categories. Problem Type Go to Battery Problems P. 8-4 Bluetooth Problems P. 8-4 Display Problems P. 8-5 Hardware Device Problems P. 8-6 Hard Disk Drive Problems P. 8-6 Infrared Problems P.

  • Page 103: Battery Problems

    Battery Problems The battery does not charge (Battery Charge indicator does not light amber). Make sure that the AC adapter is properly connected. Make sure that the battery is not too hot or cold. Allow time for the battery pack to return to room temperature. Make sure that the battery pack is installed correctly.

  • Page 104: Display Problems

    I cannot end a Bluetooth connection. If another device is connected to your computer, you can either end the connection using the other device or by deactivating Bluetooth. Display Problems Nothing appears on the screen. If the power-on indicator is not on, check the electrical outlet, the plugs and power cords.

  • Page 105: Hardware Device Problems

    The external monitor displays nothing. Make sure that the monitor is turned on. Make sure that the monitor’s signal cable is properly connected. Switch the display to the monitor by pressing or change the display through the settings in Display Properties. Simultaneous display/multi-display does not work.

  • Page 106: Infrared Problems

    The hard disk drive operations seem slow. The data files stored on the hard disk drive may be fragmented. Use a tool such as Window’s Disk Defragmenter to defragment the files. The hard disk drive in-use indicator glows without blinking. The data files stored on the hard disk drive may be fragmented.

  • Page 107: Lan Problems

    The numeric keypad is disabled. Make sure that the is switched on. (Check if the Num Lock Num Lock Indicator glows or not.) The external keyboard does not work. Make sure that the keyboard cable is properly connected. The USB mouse does not work. Make sure that the mouse cable is properly connected.
  • Page 108 Transmission quality is poor. Your computer may be in an out-of-range situation. Move your computer closer to the Access Point or another WLAN device it is associated with. Check if there is high interference around the environment and solve the problem as described next. Radio interference exists.

  • Page 109: Modem Problems

    Use the Web Manager/Telnet of the Access Point to check whether it is connected to the network. Reconfigure and reset the Access Point. I cannot access the network. Make sure that the necessary driver(s) is correctly installed. Make sure that the network configuration is appropriate. Make sure that the user name or password is correct.

  • Page 110: Power Management Problems

    Power Management Problems The computer does not enter Standby or Hibernation mode automatically. If you have a connection to another computer, the computer does not enter Standby or Hibernation mode if the connection is actively in use. Make sure that the Standby or Hibernation time-out is enabled. The computer does not enter Standby or Hibernation mode immediately.

  • Page 111: Software Problems

    The printer prints garbled information. Make sure that the printer driver is correctly installed. Make sure that the printer cable is properly connected. Software Problems An application program does not work correctly. Make sure that the software is correctly installed. If an error message appears on the screen, consult the software program’s documentation for further information.

  • Page 112: Startup Problems

    Make sure that your computer is equipped with the driver needed. Click the speaker symbol on the taskbar and check the Windows volume control. Check the volume control of your computer. Startup Problems When you turn on the computer, it does not respond and the Power Indicator does not light green.

  • Page 113: Resetting The Computer

    Resetting the Computer You may have to reset (reboot) your computer on some occasions when an error occurs and the program you are using hangs up. If the system operation seems to hang up, first wait. It is possible that the system is processing data.
  • Page 114 APPENDIX NOTE: 1. Bay 1 and Bay2 door’s protects outer covering from fire, when operating the computer if should be maintained the closed, to guarantee fire protection ability. Turn off the computer before opening the Bay 1/Bay 2 doors to change component.

  • Page 115: Appendix B Regulatory Information

    APPENDIX Regulatory Information This appendix provides regulatory statements and safety notices on your computer. NOTE: Marking labels located on the exterior of your computer indicate the regulations that your model complies with. Please check the marking labels and refer to the corresponding statements in this appendix.

  • Page 116: On The Use Of The System

    On the Use of the System Class B Regulations Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 117: Safety Notices

    Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
  • Page 118 ENGLISH CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufacturer's instructions. DEUTSCH VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ.

  • Page 119: About The Modem

    About the Modem Caution Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Never touch non-insulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines.

  • Page 120: On The Use Of Rf Device

    On the Use of RF Device NOTE: The information in this section applies to models with the wireless LAN module. USA and Canada Safety Requirements and Notices IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 121 The use of wireless devices in hospitals is restricted to the limits set forth by each hospital. Antenna use: In order to comply with FCC RF exposure limits, low gain integrated antennas should be located at a minimum distance of 20 cm (8 inches) or more from the body of all persons.
  • Page 122 EMC Requirements This device uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC). This device complies with the limits for a Class B digital device pursuant to Part 15 subpart C of the FCC Rules and Regulations.

  • Page 123: European Union Ce Marking And Compliance Notices

    Canada Radio Frequency Interference Requirements To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit être utilisé...
  • Page 124 Greek To προϊόν αυτό πληροί τις προβλέψεις της Ευρωπαϊκής Οδηγίας 1999/5/EC. Icelandic Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 1999/5/EC. Italian Questo prodotto è conforme alla Direttiva Europea 1999/5/EC. Norwegian Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 1999/5/EC.
  • Page 125 General European standards dictate maximum radiated transmit power of 100 mW Effective Isotropic Radiated Power (EIRP) and the frequency range 2400 – 2483.5 MHz. Belgium and the Netherlands In Belgium and the Netherlands, the product may not be used outdoors. See the instructions next under the heading “How to Turn Off the Wireless LAN.”...
  • Page 126 Departments in Which the Wireless LAN Module’s Maximum EIRP Not Shown in the Previous Table Frequency Ranges (MHz) Indoors Outdoors 2400 – 2446.5 10 mW Not permitted 2446.5 – 2483.5 100 mW 100 mW on private property with Ministry of Defense approval Turning Off the Wireless LAN Radio NOTE: Turning the wireless LAN radio off is not the same as disabling the wireless LAN card.
