Page 1 MX3X Reference Guide IMPORTANT NOTICE. LXE's MX3X is obsolete. This electronic guide has been made available as a courtesy to our customers. Contact your LXE representative for replacement and assistance. E-EQ-MX3XRG-W-ARC 2010 Copyright© by LXE®, Inc, An EMS Technologies Company. All Rights...
Page 2 Java® and Java-based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. or other countries, and are used under license. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LXE, Inc. is under license.
Page 3: Table Of Contents
Field Exit Key Function (IBM 5250/TN5250 Only) Scan Buttons and the SCNR LED Display Display and Display Backlight Timer Keypad Key Functions Caps Key and CapsLock Mode Keypad Shortcuts Custom Key Maps Speaker E-EQ-MX3XRG-W-ARC [ i ] MX3X Reference Guide...
Page 4 Folders Copied at Startup Saving Changes to the Registry Software Load Software Applications Bluetooth (Optional) Java (Optional) LXE RFTerm (Optional) Wavelink Avalanche Enabler Optional MX3X Utilities LAUNCH.EXE LAUNCH.EXE and Persistent Storage REGEDIT.EXE REGLOAD.EXE REGDUMP.EXE WARMBOOT.EXE E-EQ-MX3XRG-W-ARC [ ii ] MX3X Reference Guide...
Page 5 Remote Desktop Connection Transcriber Windows Explorer Taskbar General Tab Advanced Tab Taskbar Icons ActiveSync Introduction Initial Setup Connect via USB Cable for USB ActiveSync Connection: Connect and Communicate Cable for Serial ActiveSync Connection IR Connection E-EQ-MX3XRG-W-ARC [ iii ] MX3X Reference Guide...
Page 6 End User Mode Passwords End-User Switching Technique Using a Stylus Tap Using the Switch Key Sequence Hotkey (Activation hotkey) End User Internet Explorer (EUIE) Application Configuration Application Panel Launch Button Auto At Boot Auto Re-Launch E-EQ-MX3XRG-W-ARC [ iv ] MX3X Reference Guide...
Page 7 Bluetooth Barcode Reader Setup Introduction MX3X with Label MX3X without Label Bluetooth Beep and LED Indications Easy Pairing and Auto-Reconnect Certificates Date / Time Dialing Display Background Appearance Backlight Input Panel Internet Options Keyboard E-EQ-MX3XRG-W-ARC [ v ] MX3X Reference Guide...
Page 8 COM2 Tab COM3 Tab Serial Port Pin 9 Barcode Tab Buttons Enable Code ID Barcode – Custom Identifiers Parameters Buttons Control Code Replacement Examples Barcode Processing Examples Barcode - Ctrl Char Mapping Translate All E-EQ-MX3XRG-W-ARC [ vi ] MX3X Reference Guide...
Page 9 Using Wavelink Avalanche to Upgrade System Baseline Version Information on LXE Mobile Devices User Interface Enabler Configuration File Menu Options Avalanche Update using File | Settings Menu Options Connection Execution Server Contact Startup/Shutdown E-EQ-MX3XRG-W-ARC [ vii ] MX3X Reference Guide...
Page 10 Wireless Zero Config Utility and the Summit Radio Main Tab Admin Login Auto Profile Profile Tab Using the Scan Feature Profile Parameters IMPORTANT Profile SSID Client Name Power Save Tx Power Bit Rate Radio Mode Auth Type EAP Type E-EQ-MX3XRG-W-ARC [ viii ] MX3X Reference Guide...
Page 11 Sign-On vs. Stored Credentials How to: Use Stored Credentials How to: Use Sign On Screen Windows Certificate Store vs. Certs Path User Certificates Root CA Certificates Configuring the Profile No Security LEAP PEAP/MSCHAP PEAP/GTC E-EQ-MX3XRG-W-ARC [ ix ] MX3X Reference Guide...
Page 12 External Connectors / Interface / USB Host / Client Ports / Power Connector Dimensions and Weight Environmental Specifications Network Card Specifications Summit 802.11 b/g CF 2.4GHz Summit 802.11a/b/g CF 2.4/5.0GHz Bluetooth AppLock Error Messages Hat Encoding Revision History Index E-EQ-MX3XRG-W-ARC [ x ] MX3X Reference Guide...
Page 13: Introduction
Introduction The LXE® MX3X is a rugged, portable, hand-held Microsoft® Windows® CE 5.0 equipped mobile computer capable of wireless data communications using wireless LAN radios with internal antennas or an external remote mount antenna. It can store information for later transmission through an RS-232, InfraRed, or USB port. The device can be scaled from a limited function batch computer to an integrated wireless scanning computer.
Page 14: Components
7. Alt LED 8. Ctrl LED 9. Shift LED 10. Caps LED 11. Scanner LED 12. Backup Battery LED 13. Status LED 14. Main Battery LED 15. Charger LED 16. Scan or Enter (programmable) E-EQ-MX3XRG-W-ARC [ 2 ] MX3X Reference Guide...
Page 15 7. Back Cover Endcap 1. DC Power Jack 2. Left Port 3. Right Port (USB-C) 4. Audio Jack or External Antenna Connector Note: The IR port on the back of the device is COM 2. E-EQ-MX3XRG-W-ARC [ 3 ] MX3X Reference Guide...
Page 16: Battery Well Vent Aperture
The vent aperture functions to relieve any heat or pressure that may build up in the MX3X during everyday use. If the vent hole is covered by an object, e.g. a tracking label, other than an approved LXE main battery, the touch screen may be damaged.
Page 17: Hardware
802.11b/g and a/b/g Wireless Client The MX3X has an LXE 802.11x network card that supports diversity with two internal antennas. The CPU board does not allow hot swapping the network card. Adjusting power management on the network card is set to static dynamic control.
Page 18: System Memory
Backlighting is available and can be adjusted with key sequences. The turn-off timing is configured through the Control Panel. The display controller supports Windows CE graphics modes. Touch screen allows mouse functions (pointing and tapping on the display or Signature Capture) using an LXE approved stylus. There are two types of displays available: transflective greyscale monochrome.
Page 19: Pcmcia Slots
0 accepts PCMCIA 802.11 network cards or SRAM/Flash memory cards. Slot 1 – Compact Flash Card The MX3X has one internal Compact Flash card port that supports Type I and II CF+ cards. The slot is accessible when the endcap has been loosened.
Page 20: Endcaps And Com Ports
1.5 MBps. The COM 2 port is always the IR port on the back of the MX3X, regardless of the type of endcap installed. COM 2 can only be accessed when a tethered scanner is connected to the RS-232 port on the cradle, and the MX3X is in the cradle. The cradle does not need to be powered by an alternate AC or DC power source.
Page 21: Endcap Combinations
USB Client Antenna Barcode scanners, tethered to the serial port on a cradle, send ASCII data to the MX3X in the cradle through the COM2 Port. COM Port Switching The COM 2 port is always the IR port on the back of the computer, regardless of the type of endcap installed.
Page 22: Integrated Scanner Port
The integrated laser scanner scans only when the Scan button is pressed. Scan buttons have no effect on tethered barcode scanners connected to a serial port on the endcap or to the serial port on a cradle holding an MX3X. The SCNR LED illuminates during any MX3X integrated scanner activation.
Page 23: Lxe Connection Cable Technical Specification
The MX3X serial port supports four types of handshaking via the LXE serial cable: None, standard Xon/Xoff, standard DTR/DSR, and a form of RTS/CTS. To use RTS/CTS, the remote side computer must clear the DTR line which sets the MX3X CTS line and allows the MX3X to send data to the remote side.
Page 24: Usb Host / Usb Client Port
USB Host / Client connection is made through an optional USB Port if installed. The connector is an industry-standard 9-pin “D” male connector. An LXE USB cable is required to adapt the connection to a standard USB connector. USB Host Cable ActiveSync --- Connect from USB-C port to USB Type A host e.g.
Page 25: Usb Client Cable
To set the MX3X to use a tethered scanner, select Start | Settings | Control Panel | Scanner | COM1 (or 2 or 3). Tap the “Power on Pin 9 (+5V)” checkbox for the COM port selected. The COM port that accepts the scanner data can be configured for data rate, parity, stop bits and data bits.
Page 26: Programmable Scan Buttons
– in this case, the left button is labeled and functions as Field Exit). Note: The programmable Scan key is the Field Exit key when the MX3X is an IBM 5250 / TN5250 compatible device. To edit the button parameters, select Start | Settings | Control Panel | KeyPad. Change the parameter values and tap OK to save the changes.
Page 27: Display
Power button tap When the display wakes up, the timers will begin the countdown again. When any of the above events occurs prior to the timers expiring, the timers start the countdown again. E-EQ-MX3XRG-W-ARC [ 15 ] MX3X Reference Guide...
Page 28: Keypad
The Shft key enables the shifted functions of the keypad. This function is similar to a regular keyboard’s Shift key. Note that the Shift key only stays active for one keystroke. Each time you need to use a Shifted function, you need to press the Shft key E-EQ-MX3XRG-W-ARC [ 16 ] MX3X Reference Guide...
Page 29: Caps Key And Capslock Mode
A key or combination of keys can be remapped to provide a single keypress, a string of keypresses or to execute an application or command. All key remapping is done using the KeyPad option in the Control Panel. E-EQ-MX3XRG-W-ARC [ 17 ] MX3X Reference Guide...
Page 30: Speaker
IR port At the back of the MX3X is an Infrared (IR) Data Port. The IR Port is designed to provide a data link between the mobile device and a similarly equipped piece of equipment such as a printer. The IR port is the MX3X’s COM 2 port and is a bi-directional half- duplex communication port.
Page 31: Led Functions
OR all charge is depleted in both batteries.. CHGR Charger. When on, the mobile device is receiving external power either from the DC power jack or the MX3X is seated in a powered cradle. Red – Main battery is charging.
Page 32: Power
Power Power Power Modes The MX3X has four power modes: On, Suspend, Critical Suspend and Off. Primary Events Any key on the keypad COM1 activity Touch on the touchscreen Power button tap COM3 activity PC card activity USB client connection...
Page 33: Suspend Mode
Any key on the keypad PC card activity Power button tap Stylus touch on the touchscreen COM1 CTS External power connection E-EQ-MX3XRG-W-ARC [ 21 ] MX3X Reference Guide...
Page 34: Critical Suspend Mode
Insert a fully charged main battery and press the Power button to turn the device On. Off Mode The MX3X enters the Off Mode when the Main Battery and the Backup Battery are depleted. Insert a fully charged main battery and press the Power button to turn the device On.
Page 35: Batteries
Battery Hot-Swapping When the main battery power level is low, the MX3X will signal the user with a warning dialog box on the display and the BATT M LED illuminates red. The Batt-M LED is illuminated until the main battery is replaced, the battery completely depletes, external power is applied to the mobile device using the power jack, or the MX3X is placed in a powered cradle.
Page 36: Low Battery Warning
Backup Battery The MX3X has a backup battery that is designed to provide limited-duration electrical power in the event of main battery failure. The backup battery is a 50 mAh Nickel Cadmium (NiCd) battery that is factory installed in the unit. The need for recharging of the backup battery is automatically detected and controlled by the operating system.
Page 37: Software
MX3X and some of its optional features. Operating System Your MX3X operating system is Windows CE 5.0 or CE .NET 4.2. The MX3X operating system revision is displayed on the Desktop. This is the factory default value for the Desktop Display Background.
Page 38: General Windows Ce Keyboard Shortcuts
General Windows CE Keyboard Shortcuts General Windows CE Keyboard Shortcuts Use the keyboard shortcuts in the chart below to navigate with the MX3X keyboard. These are standard keyboard shortcuts for Windows CE applications. Press these keys … To … CTRL + C...
Page 39: Warmboot
MX3X, erasing any customer applied registry changes and returning the MX3X to its factory settings. Clearing Persistent Storage / Reset to Default Settings The coldboot utility sets all registry settings back to LXE factory defaults. No other clearing is available or necessary. Folders Copied at Startup The following folders are copied on startup: System\Desktop=>...
Page 40: Saving Changes To The Registry
Bluetooth (Optional) Only installed on a Bluetooth equipped MX3X. The System Administrator can Discover and Pair targeted Bluetooth devices for each MX3X. The System Administrator can enable / disable Bluetooth settings and assign a Computer Friendly name for each MX3X.
Page 41: Java (Optional)
Java (Optional) Installed by LXE. Files can be accessed by tapping Start | Programs | JEM-CE. Doubletap the EVM icon to open the EVM Console. A folder of Java examples and Plug-ins is also installed with the Java option. LXE does not support Java applications running on the mobile device.
Page 42: Mx3X Utilities
Then, information is added to the registry, if desired, to make the CAB file auto-launch at startup. The registry information needed is under the key HKEY_LOCAL_MACHINE \ Software \ LXE \ Persist, as follows. The main subkey is any text, and is a description of the file. Then 3 mandatory values are added: FileName is the name of the CAB file, with the path (usually \System).
Page 43: Launch.exe And Persistent Storage
Note: The REG.TXT file is not saved in persistent storage. To use the REG.TXT file as a reference in the even of a coldboot, LXE recommends copying the file to the \SYSTEM directory on the MX3X or storing a copy of the file on a PC.
Page 44: Wavplay.exe
Click the My Device icon on the Desktop then click the System icon. A flash card is used for permanent storage of the MX3X drivers, CAB files and utilities. It is also used for registry content back CAB files, when executed, are not deleted.
Page 45: Desktop Icons
The MX3X Desktop appearance is similar to that of a desktop PC running Windows 2000 or XP. At a minimum, it has the following icons that can be double tapped with the stylus to access My Computer, Internet Explorer, and the Recycle Bin.
Page 46: My Device Folders
Related Manual: “Using Wavelink Avalanche on LXE Windows Computers”. The MX3X has the Avalanche Enabler installation files loaded, but not installed, on the mobile device when it is shipped from LXE. The installation files are located in the System folder on CE devices. The installation application must be run manually the first time Avalanche is used.
Page 47: Internet Explorer
Java (Optional) Installed by LXE. Files can be accessed by tapping Start | Programs | JEM-CE. Doubletap the EVM icon to open the EVM Console. A folder of Java examples and Plug-ins is also installed with the Java option. LXE does not support Java applications running on the mobile device.
Page 48: Start Menu Program Options
Access: Start | Programs Communication Stores Network communication options ActiveSync Transfer files between a MX3X and a desktop computer Connect Run this command after setting up a connection Start FTP Server Begin connection to FTP server Stop FTP Server End connection to FTP server...
Page 49: Communication
Java (Optional) Installed by LXE. Files can be accessed by tapping Start | Programs | JEM-CE. Doubletap the EVM icon to open the EVM Console. A folder of Java examples and Plug-ins is also installed with the Java option. LXE does not support Java applications running on the mobile device.
Page 50: Command Prompt
There are few changes in the Windows CE version of Media Player as it relates to the general desktop Windows PC Microsoft Media Player options. The Media Player on the MX3X can be accessed by clicking Start | Programs | Media Player. Click the “?” button to access Media Player Help.
Page 51: Wordpad
There are few changes in the Windows CE version of Remote Desktop Connection as it relates to the general desktop Windows PC Microsoft Remote Desktop Connection options. If installed, Remote Desktop Connection on the MX3X can be accessed by Start | Programs | Remote Desktop Connection.
Page 52: Taskbar
Tap the checkbox to have the Control Panel folders appear in drop down menu format from the Settings | Control Panel menu option. Clear Contents of Document Folder Tap the Clear button to remove the contents of the Document folder. E-EQ-MX3XRG-W-ARC [ 40 ] MX3X Reference Guide...
Page 53: Taskbar Icons
Refer to Start | Help for an explanation of standard Windows CE taskbar icons. Following are a few of the MX3X and LXE unique taskbar icons that may appear in the Taskbar. These icons are in addition to the Windows CE taskbar icons.
Page 54: Activesync
PC is available from the Microsoft website. Follow their instructions to locate, download and install ActiveSync on your desktop computer. Using Microsoft ActiveSync version 3.8 or higher, you can synchronize information on your desktop computer with the MX3X and vice versa. Synchronization compares the data on your mobile device with your desktop computer and updates both with the most recent data.
Page 55: Connect Via Usb
Connect and Communicate Start | Settings | Control Panel | PC Connection The connection type must be changed to Serial 1 @ 57600 or Serial 3 @ 57600 depending on which serial port on the MX3X is used. To change the connection type tap the Change button. From the popup list, choose Serial 1 @ 57600 or Serial 3 @ 57600 This will set up the mobile device to use the serial port.
Page 56: Cable For Serial Activesync Connection
9000054CABLE, RS-232 9 Pin to 9 Pin, MX3X Serial port to PC/Laptop serial port Connect one end of the cable to the COM port (labeled RS-232 COM1) on the MX3X endcap. Connect the other end to a COM port on a PC or laptop.
Page 57: Wireless Connection
Select Start | Settings | Programs | Communication | ActiveSync. From the popup list, choose Network and then tap the Connect button. MX3X without Touchscreen For a MX3X, the touchscreen can be disabled. it may be easier to configure the MX3X using ActiveSync and LXEConnect rather than using the MX3X keyboard only. E-EQ-MX3XRG-W-ARC [ 45 ] MX3X Reference Guide...
Page 58: Synchronizing From The Mobile Device
A desktop or laptop PC with an available serial port and a mobile device with a serial port. The desktop or laptop PC must be running Windows NT or greater. Null modem cable with all control lines connected. LXE recommends using the null modem cable part number listed in Connect and Communicate.
Page 59: Connect
ActiveSync will insist the unique name of the mobile device be changed. If the mobile device is associated with a second host, changing the name will destroy that partnership as well. This can cause some confusion when re-establishing partnerships with hosts. E-EQ-MX3XRG-W-ARC [ 47 ] MX3X Reference Guide...
Page 60: Troubleshooting Activesync
If the MX3X is connected to a PC by a cable, disconnect the cable from the MX3X and reconnect it again. Check that the correct connection is selected (Serial or USB “Client” if this is the initial ActiveSync installation).
Page 61: Configuring The Mx3X With Lxeconnect
ActiveSync is already installed on the MX3X. The MX3X is preconfigured to establish a USB ActiveSync connection to a PC when the proper cable is attached to the MX3X and the PC. If The MX3X uses a serial port for ActiveSync, it is necessary to configure the MX3X to use the serial port.
Page 62 Install LXEConnect LXEConnect Installation Files 7. Select and copy the LXEConnect.msi and Setup.exe files from the MX3X to the user PC. Note the location chosen for files 8. Close the ActiveSync explorer dialog box. Do not disconnect the MX3X ActiveSync connection.
Page 63: Using Lxeconnect
Using LXEConnect Using LXEConnect 1. If an ActiveSync connection is has not been established, connect the MX3X to the PC. Details on ActiveSync are included in the following section. 2. Double-click the LXEConnect icon that was created on the desktop.
Page 64: Control Panel
Start | Settings | Control Panel or My Device | Control Panel link Note: Change the font displayed on the touchscreen by choosing Start | Settings | Control Panel | Keyboard and then the Key map dropdown list. Tap the ? button for Help when changing MX3X Control Panel options. Option Function Software, hardware, versions and network IP.
Page 65 Remove Programs Select to remove specific user installed programs in their entirety. LXE Scan Wedge utility. Set scanner key wedge, scanner port, and imager LED Scanner illumination options. Assign baud rate, parity, stop bits and data bits for COM1 port.
Page 66: About
The registry settings for the Version tab are under HKEY_LOCAL_MACHINE \ Software \ LXE \ Version in the registry. To add a user application to the Version panel, create a new string value under the HKLM\Software\LXE\Version key. The string name should be the Application name to appear in the Version window.
Page 67: Identifying Software Versions
The Versions tab displays the versions of many of the software programs installed. Not all installed software installed on the mobile device is included in this list and the list varies depending on the applications loaded on the MX3X. The LXE Image line displays the revision of the system software installed.
Page 68: Accessibility
Accessibility Start | Settings | Control Panel | Accessibility Customize the way the MX3X keyboard, sound, display, mouse, automatic reset and notification sounds function. There are a few changes from general Windows desktop Accessibility options. Note: LXE disables the keyboard StickyKeys and StickyKeys Settings on the Keyboard panel as this setting, when enabled, interferes with LXE's assigned sticky key implementation.
Page 69: Administration - For Applock
Administration - for AppLock Introduction LXE’s AppLock is designed to be run on LXE certified Windows CE based devices only. LXE loads the AppLock program as part of the LXE customer installation process. MX3X AppLock is setup by the Administrator by tapping Start | Settings | Control Panel | Administration.
Page 70: Setup A New Device
LXE devices with the AppLock feature are shipped to boot in Administration mode with no default password, thus when the MX3X is first booted, the user has full access to the device and no password prompt is displayed. After the administrator specifies the applications to lock, a password is assigned and the device is rebooted or the hotkey is pressed, the device switches to end-user mode.
Page 71: Administration Mode
In addition to these configuration options, the administrator can view and manage the status logs of AppLock sessions. Administrator default values for this device: Administrator Hotkey Shift+Ctrl+A Password none Application path and name none Application command line none E-EQ-MX3XRG-W-ARC [ 59 ] MX3X Reference Guide...
Page 72: End User Mode
To summarize, if an error occurs that prevents AppLock from switching to user mode, the password will not timeout and AppLock will wait until the correct password is entered. Forgotten password? See: Troubleshooting E-EQ-MX3XRG-W-ARC [ 60 ] MX3X Reference Guide...
Page 73: End-User Switching Technique
A checkmark indicates applications currently active or available for Launching by the user. When Keyboard is selected, the MX3X default input method (Input Panel, Transcriber, or custom input method) is activated. The check to the left of the application name indicates that the application is active.
Page 74: Hotkey (Activation Hotkey)
Hotkey (Activation hotkey) If the mobile device uses LXE’s Multi AppLock to allow the user to switch between applications, the default Activation key is Ctrl+Spc. The key sequence switches the focus between one application and another. Data entry affects the application running in the foreground only.
Page 75: Application Configuration
If a password has not been configured, the Administrator Control panel is displayed. Important: Before setting up multiple instances of the same application, make sure the targeted software application will allow two instances to run at the same time. E-EQ-MX3XRG-W-ARC [ 63 ] MX3X Reference Guide...
Page 76: Application Panel
Default is Ctrl+Spc. Select the Global Key key sequence the end-user is to press when switching between Global Key applications. The Global Key default key sequence must be defined by the AppLock Administrator. The Global key is presented to the end-user as the Activation key. E-EQ-MX3XRG-W-ARC [ 64 ] MX3X Reference Guide...
Page 77: Launch Button
When clicked, displays the Launch options panel for the Filename selected on the Administration panel. Application Launch Options Note: Launch order is determined by the Order specified in the Application tab. The Order value does not have to be sequential. E-EQ-MX3XRG-W-ARC [ 65 ] MX3X Reference Guide...
Page 78: Auto At Boot
Order number) and no delay (0 seconds) for all other applications. Note: Launch order is determined by the Order specified in the Application tab. The Order value does not have to be sequential. E-EQ-MX3XRG-W-ARC [ 66 ] MX3X Reference Guide...
Page 79: Auto Re-Launch
The delay is specified in seconds. Valid values are between 0 (no delay) and 99 seconds. AppLock must also be configured to automatically re-launch an application. To AppLock, application termination by the end- user is indistinguishable from application termination for any other reason. E-EQ-MX3XRG-W-ARC [ 67 ] MX3X Reference Guide...
Page 80: Manual (Launch)
Error conditions may generate a topmost popup requiring an end-user response, memory resource issues requiring an end-user response, etc. Also at the administrator’s discretion, these types of applications can be started manually (see Manual [Launch]) by the end-user. E-EQ-MX3XRG-W-ARC [ 68 ] MX3X Reference Guide...
Page 81: Match
Match field must be used. Use the Match field to specify up to 32 characters of the class name for the application. For example, DOS applications using a standard DOS display box should specify condev_appcls in the Match textbox. E-EQ-MX3XRG-W-ARC [ 69 ] MX3X Reference Guide...
Page 82: Security Panel
After the user closes the dialog box, the Security Panel is displayed and the password can then be entered and confirmed again. If the passwords match, the password is encrypted and saved. See Also: Passwords Troubleshooting E-EQ-MX3XRG-W-ARC [ 70 ] MX3X Reference Guide...
Page 83: Options Panel
This specifies the period of time for AppLock to wait for an application to restart. If the application fails to restart automatically, AppLock then proceeds according to the options selected when the application was configured on the Application Launch panels. E-EQ-MX3XRG-W-ARC [ 71 ] MX3X Reference Guide...
Page 84: Status Panel
Error status messages are logged when an error occurs and is intended to be used by the administrator to deter- Error mine why the specified application cannot be locked. Processing status shows the flow control of AppLock components and is mainly intended for LXE Customer Serv- Process ice when helping users troubleshoot problems with their AppLock program.
Page 85: Log
If two copies of the same application are configured, but the application only allows one copy to run at a time, for exam- ple Microsoft Pocket Word and LXE RFTerm, the switch to end-user fails. AppLock stays in Administration mode and is stopped until the Administrator password is entered.
Page 86: Battery
Battery Start | Settings | Control Panel | Battery This panel is used to view the status and percentage of power remaining in the MX3X main battery. The data cannot be edited by the user. The battery gas gauge icon resides in the system tray and shows four levels of charge – 100%, 75%, 50%, 25%. At a point below 50% the system status LED will turn yellow and the gas gauge icon will turn yellow.
Page 87: Bluetooth
It is not necessary to disconnect a paired scanner and printer before a different scanner or printer is paired with the MX3X. The target Bluetooth device should be as close as possible (line of sight) to the MX3X during the pairing process. Assumption:The System Administrator has Discovered and Paired targeted Bluetooth devices for the MX3X. The MX3X operating system has been upgraded to the revision level required for Bluetooth client operation.
Page 88: Bluetooth Devices
Note: When an active paired device enters Suspend Mode, is turned Off or leaves the MX3X Bluetooth scanning range, the Bluetooth connection between the paired device and the MX3X is lost. There may be audible or visual signals as paired devices disconnect from the MX3X.
Page 89: Bluetooth Device Menu
The Bluetooth panel assigns an icon to the device name. An icon with a red background indicates the device's Bluetooth connection is inactive. An icon with a white background indicates the device is connected to the MX3X and the device's Bluetooth connection is active.
Page 90: Bluetooth Device Properties
Bluetooth Device Properties Bluetooth Device Right Click Menu Tap Pair as Scanner to set up the MX3X to receive data from the scanner. Tap Pair as Printer to set up the MX3X to send data to the printer. Tap Disconnect to stop the connection between the MX3X and a paired Bluetooth device.
Page 91: Settings
Disable this option to inhibit MX3X connection with all Bluetooth devices. This Computer is connectable Enabled option is enabled by default.
Page 92: Turn Off Bluetooth Button
Turn Off Bluetooth Button Option Default Information Enable this option to ensure other devices can discover the MX3X. This option is Computer is discoverable Disabled disabled by default. A dialog box appears on the MX3X screen notifying the user a Bluetooth device requests to pair with the MX3X.
Page 93 This panel lists the assigned Computer Friendly Name (that other devices may discover during their Discovery and Query process), the Bluetooth MAC address, and software version levels. The data cannot be edited by the user. E-EQ-MX3XRG-W-ARC [ 81 ] MX3X Reference Guide...
Page 94: Using Bluetooth
Discover and pair with nearby Bluetooth devices. Only LXE printers or scanners are recognized and displayed in the Bluetooth panel. All other Bluetooth devices are ignored. Prerequisite: The Bluetooth devices have been setup to allow them to be “Discovered” and “Connected/Paired”. The System Administrator is familiar with the pairing function of the Bluetooth devices.
Page 95: Initial Use
LED on the device, or a dialog box is placed on the MX3X display. 10. Whenever the MX3X is turned On, all previously paired, live, Bluetooth devices in the vicinity are paired, one at a time, with the MX3X.
Page 96: Bluetooth Indicators
MX3X is out of range of all paired Bluetooth device(s). Connection is inactive. Note: When an active paired device enters Suspend Mode, is turned Off or leaves the MX3X Bluetooth scan range, the Bluetooth connection between the paired device and the MX3X is lost. There may be audible or visual signals as paired devices disconnect from the MX3X.
Page 97 Introduction Sample Bluetooth Address Barcode Label Locate the barcode label, similar to the one shown above, attached to the MX3X. The label is the Bluetooth address identifier for the MX3X. The mobile Bluetooth scanner / imager requires this information before discovering, pairing, connecting or disconnecting can occur.
Page 98: Mx3X With Label
1. Scan the Bluetooth address barcode label, attached to the MX3X, with the LXE Bluetooth mobile scanner. 2. If this is the first time the Bluetooth scanner has scanned the MX3X Bluetooth label, the devices are paired. See section titled “Bluetooth Beep and LED...
Page 99: Mx3X Without Label
The devices are paired. The Bluetooth barcode reader responds with a series of beeps and LED flashes. Refer to the following section titled “Bluetooth Beep and LED Indications”. Note: After scanning the MX3X Bluetooth label, if there is no beep and no LED flash from the Bluetooth device, the devices are currently paired.
Page 100: Bluetooth Beep And Led Indications
Pairing supports SPP devices only. Up to two Bluetooth devices can be connected to the MX3X at a time; LXE supports one Bluetooth scanner and one Bluetooth printer.
Page 101: Certificates
Start | Settings | Control Panel | Certificates Manage digital certificates used for secure communication. Note: Digital certificates are date sensitive. If the date on the MX3X is incorrect, wireless authentication will fail. The Certificates stores lists the certificates trusted by the MX3X mobile device user.
Page 102: Date / Time
Date / Time Date / Time Start | Settings | Control Panel | Date/Time - or - Time in Desktop Taskbar Use this MX3X panel to set Date, Time, Time Zone, and assign a Daylight Savings location. Factory Default Settings Current Time...
Page 103: Dialing
Dialing Dialing Start | Settings | Control Panel | Dialing Set dialup properties for internal modems (not supplied or supported on the MX3X by LXE). Factory Default Settings Location Work Area Code Tone Dialing Enabled Country/Region Disable Call Waiting Disabled (blank)
Page 104: Display
The display might also called the touchscreen. Select the desktop background image and appearance scheme for the MX3X. Using the options on the Backlight tab, set the display backlight and keypad backlight timers when running on battery or external power.
Page 105: Backlight
Backlight Backlight The backlight settings use the LXE set of default timeouts and is synchronized to the User Idle setting in the Schemes tab in the Power control panel. When the backlight timer expires, the touchscreen backlight is dimmed, not turned off. When both checkboxes are unchecked, the backlight never turns off (or dims).
Page 106: Input Panel
Input Panel Input Panel Start | Settings | Control Panel | Input Panel Set the current MX3X keys and data input method. Factory Default Settings Input Method Keyboard Allow applications to change Enabled input panel state Options button Keys Small keys...
Page 107: Internet Options
Third party cookies Prompt Session cookies Always allow Advanced Stylesheets Enabled Theming Support Enable Multimedia All options enabled Security All options enabled Popups Block popups Disabled Display notification Enabled Use same window Disabled E-EQ-MX3XRG-W-ARC [ 95 ] MX3X Reference Guide...
Page 108 Internet Options E-EQ-MX3XRG-W-ARC [ 96 ] MX3X Reference Guide...
Page 109 Internet Options E-EQ-MX3XRG-W-ARC [ 97 ] MX3X Reference Guide...
Page 110: Keyboard
Chinese, Korean, Japanese. Tahoma font is on every unit and includes English (default), European (French, Spanish, German, Portuguese), Scandinavian languages, Arabic, Cyrillic, Greek, Hebrew, and Thai. See Also: Regional Settings for instruction for setting User Interface Language and Default Input Language. E-EQ-MX3XRG-W-ARC [ 98 ] MX3X Reference Guide...
Page 111: Keypad
KeyPad Start | Settings | Control Panel | KeyPad Icon Use this control panel option to assign key functions to mappable keys available on your MX3X, determine application launch sequences and program command Run sequences. Note: KeyPad Control Panel options LaunchApp and RunCmd do not inter-relate with similarly-named options contained in other Control Panel applets.
Page 112: Keymap Tab
7. If any parameters are needed for the application, click on the OPT radio button. This clears the text box (though the appli- cation name is saved). Enter the desired parameters in the appropriate text box. 8. Click OK to save the result and close the Keypad Control. E-EQ-MX3XRG-W-ARC [ 100 ] MX3X Reference Guide...
Page 113 8. Click OK to save the result and close the Keypad Control. 9. If the KeyMap tab is accessed again, the command plus any specified parameters is displayed in the Key Sequence text box when the remapped key is again selected. E-EQ-MX3XRG-W-ARC [ 101 ] MX3X Reference Guide...
Page 114: Launchapp Tab
The default for all text boxes is Null or “ ”. The text boxes accept string values only. Note that executables and parameters are not checked for accuracy by the keyboard driver. If the launch fails, the MX3X emits a single beep, if the launch is successful, it is silent.
Page 115: Runcmd Tab
The default for all text boxes is Empty, Null or " ". The text boxes accept string values only. Note that executables and parameters are not checked for accuracy by the keyboard driver. If the launch fails, the MX3X emits a single beep, if the launch is successful, the mobile device is silent.
Page 116: Mixer
Start | Settings | Control Panel | Mixer The MX3X has a speaker. It is active when a headset is not connected to the device. Use the settings on these panels to adjust the volume, record gain and sidetone for microphone input, speaker and speaker output.
Page 117: Mouse
Mouse Mouse Start | Settings | Control Panel | Mouse Use this option to set the double-tap sensitivity for stylus taps on the MX3X touchscreen. E-EQ-MX3XRG-W-ARC [ 105 ] MX3X Reference Guide...
Page 118: Mx3X-Vxc Options
Set options such as IP V6, time sync, touchscreen enable and CapsLock. Also set Status Popup taskbar icon display options for the Admin and User. It may be necessary to warmboot the MX3X after making desired changes. A pop up window indicates if a warmboot is required.
Page 119: Misc
The System/GrabTime.ini file takes precedence over the Windows/GrabTime.ini file. System/Grabtime.ini also persists after a coldboot; Windows/Grabtime.ini does not persist. Misc Options on this tab configure device specific options. Note that options not available on the MX3X are grayed out. MX3X Options / Misc. Tab CapsLock By default, CapsLock is disabled after a warmboot.
Page 120: Status Popup
The default for the User and Admin status popup windows is to show all status information. The 5 second timeout to remove the status popup from the display is disabled by default for the User and Admin status popup windows. Click here to go to the KeyPad control panel. E-EQ-MX3XRG-W-ARC [ 108 ] MX3X Reference Guide...
Page 121: Network And Dialup Options
Network and Dialup Options Start | Settings | Control Panel | Network and Dialup Connections Set MX3X network driver properties and network access properties. Select a connection to use, or create a new connection. Create a New Connection 1. On the mobile device, select Start | Settings | Control Panel | Network and Dialup Connections. A window is dis- played showing the existing connections.
Page 122: Owner
Owner Owner Start | Settings | Control Panel | Owner Set the MX3X owner details. The Network ID is used when logging into a remote network. Factory Default Settings Identification Name Blank Company Blank Address Blank Telephones Blank Display owner ID at power-on...
Page 123 Owner Enter user name, password and domain to be used when logging into network resources. E-EQ-MX3XRG-W-ARC [ 111 ] MX3X Reference Guide...
Page 124: Password
Password Start | Settings | Control Panel | Password Use this panel to set MX3X user access to control panels and power up password properties. Important: This password must be entered before performing a cold boot or cold reset. If entering a power-on or screen saver password does not allow you to disable this password protection or perform a cold boot, contact Customer Support.
Page 125: Pc Connection
PC Connection PC Connection Start | Settings | Control Panel | PC Connection Use these options to control a cabled connection (USB, serial) between the MX3X and a nearby desktop/laptop computer. Factory Default Settings Enable direct connection Enabled Connect using...
Page 126: Pcmcia
PCMCIA PCMCIA Start | Settings | Control Panel | PCMCIA Use the options on the tabs to manage cards installed in the MX3X. Factory Default Settings PCMCIA Disable slot now Power slot during sleep (3.3v) Dimmed Power slot during sleep (5v)
Page 127: Cf Tab Options
When there is no card in a slot, the options are dimmed. IntATA Tab Options The IntATA Tab provides information on the internal Compact Flash ATA drive. There are no user configurable options. E-EQ-MX3XRG-W-ARC [ 115 ] MX3X Reference Guide...
Page 128: Power
Power Start | Settings | Control Panel | Power The MX3X power mode timers are cumulative. The System Idle timer begins the countdown after the User Idle timer has expired and the Suspend timer begins the countdown after the System Idle timer has expired.
Page 129 And the device enters Suspend after 5 minutes and 18 seconds of no activity. If the User Idle timer is set to Never, the power scheme timers never place the device in User Idle, System Idle or Sus- pend modes. E-EQ-MX3XRG-W-ARC [ 117 ] MX3X Reference Guide...
Page 130: Regional And Language Settings
Regional and Language Settings Start | Settings | Control Panel | Regional Settings Set the appearance of numbers, currency, time and date based on regional and language settings. Set the MX3X user interface language and the default input language. Factory Default Settings...
Page 131 Regional and Language Settings E-EQ-MX3XRG-W-ARC [ 119 ] MX3X Reference Guide...
Page 132: Remove Programs
Start | Settings | Control Panel | Remove Programs Note: Lists programs installed in RAM that have been marked for removal. Select a program and tap Remove. Follow the prompts on the screen to uninstall MX3X user-installed only programs. The change takes effect immediately.
Page 133: Scanner Wedge
Integrated scanner configuration can be changed using the Scanner Control Panel or via the LXE API functions. While the changed configuration is being stored, the Scanner LED is solid amber. The scanner is not operational during the configuration update.
Page 134: Barcode Processing Overview
If Translate All is set, key is translated to CTRL + char, and output. If Translate All is not set, and key has a valid VK code, key is output. Otherwise, key is ignored (not output). The barcode data is ready to be read by applications. E-EQ-MX3XRG-W-ARC [ 122 ] MX3X Reference Guide...
Page 135: Factory Default Settings
Enable Dimmed / Min - 1 to Max - all AIM ID Enable dimmed Symbol ID Enable dimmed Custom Null Control Character Disabled Translate All Disabled Character/Replacement Null / Ignore (drop) Custom Identifiers Name Blank ID Code Blank E-EQ-MX3XRG-W-ARC [ 123 ] MX3X Reference Guide...
Page 136: Main Tab
If “Send Key Messages (WEDGE)” is not checked, the Scanner Driver is in “Block” mode which Send Key Messages buffers the data that can be read by an application from the WDG: device through the OS or LXE (WEDGE) APIs. Note that this latter method is significantly faster than using “Wedge”.
Page 137: Keys Tab
Integrated Scan buttons have no effect on scanners tethered to a COM port or scanners connected wirelessly (for example, wireless Bluetooth scanners) to the MX3X. The Scan button on the tethered or wireless barcode scanner must be pressed. Incoming data from the tethered or wireless barcode scanner is manipulated using the parameters set on the Barcode Tab.
Page 138: Com2 Tab
This panel does not configure the connected device. Please refer to the documentation for the external connected or wireless device for information on configuring the device. Power on Pin 9 (+5V) on the MX3X is disabled on the COM2 port. Important: Do not connect a tethered scanner to a port labeled USB-H or USB-C.
Page 139: Serial Port Pin 9
Power on Pin 9 on the COM2 panel is dimmed. To configure COM1 to have Ring Indicator (RI) on Pin 9, uncheck the checkbox for Power on Pin 9 (+5V) (disabled). The default is On (enabled). E-EQ-MX3XRG-W-ARC [ 127 ] MX3X Reference Guide...
Page 140: Barcode Tab
Enabling or disabling a specific barcode symbology is done manually using the configuration barcode in the Integrated Scanner Programming Guide (available on the LXE Manuals CD and the LXE ServicePass website). Choose an option in the Enable Code ID drop-down box: None, AIM ID, Symbol ID, or Custom ID.
Page 141: Enable Code Id
When Enable Code ID is set to AIM or Symbol,Custom Code IDs appear at the end of the list of standard Code IDs. When Enable Code ID is set to Custom, Custom Code IDs replace the list of standard Code IDs. E-EQ-MX3XRG-W-ARC [ 129 ] MX3X Reference Guide...
Page 142 Scanner Control Panel processing causes a bad scan beep by the mobile device on the same data. E-EQ-MX3XRG-W-ARC [ 130 ] MX3X Reference Guide...
Page 143: Barcode - Custom Identifiers
ID Code defines the data at the beginning of a barcode that acts as an identifier (the actual Code ID). Both Name and ID Code must be specified in order to add a custom Code ID to the Custom IDs list. E-EQ-MX3XRG-W-ARC [ 131 ] MX3X Reference Guide...
Page 144: Buttons
The Clear All button text changes to a Remove button when an item in the Custom IDs list is selected. Click the desired line item and then click the Remove button to delete it. Line items are Removed one at a time. Contents of the text box fields are cleared at the same time. E-EQ-MX3XRG-W-ARC [ 132 ] MX3X Reference Guide...
Page 145: Control Code Replacement Examples
0x0A. Escaped hex- The hex-encoding to pass through to the Value 0x0C is a barcode is Vertical Tab \0x0A or 0\x0A encoded text application. converted to text 0x0A See also Hat Encoding E-EQ-MX3XRG-W-ARC [ 133 ] MX3X Reference Guide...
Page 146: Barcode Processing Examples
Note: Rejected barcodes generate a bad scan beep. In some cases, the receipt of data from the scanner triggers a good scan beep (from the external scanner), and then the rejection of scanned barcode data by the processing causes a bad scan beep on the same data. E-EQ-MX3XRG-W-ARC [ 134 ] MX3X Reference Guide...
Page 147: Barcode - Ctrl Char Mapping
Barcode - Ctrl Char Mapping The Ctrl Char Mapping button (Control Character Mapping) activates a dialog to define the operations the LXE Wedge performs on control characters (values less than 0x20) embedded in barcodes. Control characters can be replaced with user-defined text which can include hat encoded or hex encoded values.
Page 148 This button is grayed unless an entry in the list box is highlighted. When an entry (or entries) is highlighted, and the Delete button is clicked, the highlighted material is deleted from the list box. E-EQ-MX3XRG-W-ARC [ 136 ] MX3X Reference Guide...
Page 149: Barcode - Symbology Settings
Barcode Data) add a prefix or suffix to a barcode. The Symbology drop-down box contains all symbologies supported on the MX3X. An asterisk appears in front of symbologies that have already been configured or have been modified from the default value.
Page 150: Parameters
Max field is rejected. The default for this field is All (9999). If the value entered is greater than the maximum value allowed for that symbology, the maximum valid length is used instead. E-EQ-MX3XRG-W-ARC [ 138 ] MX3X Reference Guide...
Page 151: Strip Leading/Trailing Control
Strips the Code ID based on the type code id specified in the Enable Code ID field in the Barcode tab. By default, Code ID stripping is enabled for all symbologies (meaning code IDs will be stripped, unless specifically configured otherwise). E-EQ-MX3XRG-W-ARC [ 139 ] MX3X Reference Guide...
Page 152: Barcode Data Match List
Prefix and Suffix data is always added on after stripping is complete, and is not affected by any stripping settings. If the stripping configuration results in a 0 length barcode, a good beep will still be sounded, since barcode data was read from the scanner. E-EQ-MX3XRG-W-ARC [ 140 ] MX3X Reference Guide...
Page 153: Match List Rules
Code ID is disabled, then the barcode data to match must include the Code ID. If Strip Code ID is enabled, the data should not include the Code ID since it has already been stripped. E-EQ-MX3XRG-W-ARC [ 141 ] MX3X Reference Guide...
Page 154: Add Prefix/Suffix Control
If ‘All’ is selected, the suffix is added for any symbology that has not been specifically configured. Note: Non-ASCII equivalent keys in Key Message mode are unavailable in this option. Non-ASCII equivalent keys include the function keys (e.g. F1), arrow keys, Page up, Page down, Home, and End. E-EQ-MX3XRG-W-ARC [ 142 ] MX3X Reference Guide...
Page 155: Length Based Barcode Stripping
= 20, max length = 20, strip leading 0, strip trailing 4, Code ID enabled, Barcode Data = “00” Add the AIM custom symbologies. Refer to the previous section Barcode – Symbology Settings for instruction. E-EQ-MX3XRG-W-ARC [ 143 ] MX3X Reference Guide...
Page 156 Click the Barcode Data button. Click the Add button. Add the data for the match codes. Refer to the previous section Barcode Data Match List for instruction. Scan a barcode and examine the result. E-EQ-MX3XRG-W-ARC [ 144 ] MX3X Reference Guide...
Page 157: Stylus
Stylus Start | Settings | Control Panel | Stylus Use this control panel option to set stylus double-tap sensitivity properties and calibrate the MX3X touch panel when needed. Double Tap Follow the instructions on the screen and tap the OK button to save any double tap changes.
Page 158: System
Memory sizes given do not include memory used up by the operating system. For example, a system with 128 MB may only report 99 MB memory, since 29 MB is used by the operating system. This is actual DRAM memory, and does not include internal flash used for storage. E-EQ-MX3XRG-W-ARC [ 146 ] MX3X Reference Guide...
Page 159: Memory Tab
The device name and description can be changed by the user. Enter the name and description using either the keypad or the Input Panel and tap OK to save the changes. This information is used to identify the MX3X to other computers and devices.
Page 160: Terminal Server Client Licenses
Terminal Server Client Licenses Start | Settings | Control Panel \ Terminal Server Client Licenses Any licenses stored on the MX3X appear in the drop-down list. Select a license and tap the Close button. The license is available for use immediately.
Page 161: Volume And Sounds
You can also select / deselect sounds for key clicks and screen taps and whether each is loud or soft. As the volume scrollbar is moved between Loud and Soft, the MX3X emits a tone each time the volume increases or decreases.
Page 162: Good Scan And Bad Scan Sounds
WAV files and can be replaced by a WAV file of the user’s choice. By default a good scan sound on the MX3X is a single beep, and a bad scan sound is a double beep. WiFi Control Panel Start | Settings | Control Panel | WiFi or click the Summit Client Utility icon Use this option to set parameters and manage profiles for the wireless client pre-loaded on your MX3X.
Page 163: Enabler Installation And Configuration
Installing the Enabler on LXE Devices LXE CE devices have the Avalanche Enabler installation files loaded, but not installed, on the mobile device when it is shipped from LXE. The installation files are located in the \System folder on CE devices.
Page 164: Briefly
The Avalanche folder cannot be deleted while the Enabler is running. See Stop the Enabler Service. If sharing errors occur while attempting to delete the Avalanche folder, warm boot the MX3X, immediately delete the Avalanche folder, and then perform another warm boot. Stop the Enabler Service To stop the Enabler from monitoring for updates from the Mobility Center Console: 1.
Page 165: Update Monitoring Overview
The Enabler running on the MX3X will attempt to access COM1, COM2, and COM3. “Agent not found” will be reported if the Mobile Device Server is not located or a serial port is not present or available (COM port settings can be verified using the LXE scanner applet in the Control Panel on the MX3X).
Page 166: Mobile Device Wireless And Network Settings
Mobile Device Wireless and Network Settings Mobile Device Wireless and Network Settings Once the connection to the Mobile Device Server is established, the MX3X Enabler attempts to apply all network and wireless settings contained in the active profile. The success of the application of settings is dependent upon the local configuration of control parameters for the Enabler.
Page 167: Preparing An Lxe Device For Remote Management
April 2007. The LXE Remote Management Utility (RMU) must be installed on all LXE mobile devices first – then you can control mobile device reboot, storage RAM adjustment, real-time updates and Avalanche Enabler properties. If the RMU is not...
Page 168: Using Wavelink Avalanche To Upgrade System Baseline
Version Information on LXE Mobile Devices The VersionInfo.EXE file is included in the Remote Management Utility package downloaded to the MX3X. It is stored in the \Program Files\RMU folder. When VersionInfo.EXE is opened, a dialog box is presented to the MX3X user displaying:...
Page 169: User Interface
User Interface User Interface The Enabler can be configured and controlled manually through the user interface on the MX3X. This section details the functionality that can be controlled by the user or system administrator. Parameters and Screen Displays Screen displays shown in this section are designed to present the end-user with information graphically.
Page 170: Enabler Configuration
The Enabler user interface application is launched by clicking either the Enabler Settings icon on the desktop or Taskbar or by selecting Avalanche Enabler from the Programs menu. The opening screen presents the MX3X user with the connection status and a navigation menu. Avalanche Enabler Opening Screen Note: Some parameters and features described in this section may not be available if you are not running the latest version of the Enabler.
Page 171: File Menu Options
The password is not case-sensitive. Avalanche Update using File | Settings Use these menu options to setup the Avalanche Enabler on the MX3X. LXE recommends changing settings and then saving the changes (reboot) before connecting to the network. Alternatively, the Mobile Device Server can be disabled until needed (refer to the Wavelink Avalanche Mobility Center User’s Guide for details).
Page 172: Menu Options
Menu Options Menu Options Note: Your MX3X screen display may not be exactly as shown in the following menu options. Contact your representative for version information and upgrade availability. Enter the IP Address or host name of the Mobile Device Server. Set the order in which serial ports or Connection RF connections are used to check for the presence of the Mobile Device Server.
Page 173: Connection
Connection Connection Options Avalanche Enter the IP Address or host name of the Mobile Device Server assigned to the MX3X. Server Address Check Serial Indicates whether the Enabler should first check for serial port connection to the Mobile Device Server Connection before checking for a wireless connection to the Mobile Device Server.
Page 174: Execution
Execution Execution Note the dimmed options on this MX3X panel. This menu option is designed to manage downloaded applications for automatic execution upon startup. Execution Options (Dimmed) Auto-Execute An application that has been installed with the Avalanche Management system can be run Selection automatically following each boot.
Page 175: Server Contact
Sync Clock Reset the time on the MX3X based on the time on the Mobile Device Server host PC. On Startup – Connect to the Mobile Device Server when the Enabler is accessed. On Resume – Connect to the Mobile Device Server when resuming from Suspend mode.
Page 176: Startup/Shutdown
Startup/Shutdown Startup/Shutdown LXE recommends using LXE AppLock to manage the taskbar. AppLock is resident on each mobile device with a Windows CE OS (with the exception of the HX3). AppLock configuration instructions are located in the MX3X reference guide. Startup / Shutdown Options...
Page 177: Scan Config
LXE recommends using LXE eXpress Config and eXpress Scan for this function. eXpress Scan is included with the updated MX3X enablers. Scan Config Option Scan Config functionality is a standard option of the Wavelink Avalanche MC system but is not currently supported by LXE on the MX3X. E-EQ-MX3XRG-W-ARC [ 165 ] MX3X Reference Guide...
Page 178: Display
Display Window Display Options Update Window Display The user interface for the Enabler can be configured to dynamically change based on the status of the MX3X connection with the Mobile Device Server. At startup Default is Half Screen. Options are Half screen, Hidden or Full screen.
Page 179: Shortcuts
Shortcuts Shortcuts LXE recommends using LXE AppLock for this function. AppLock is resident on each mobile device with a Windows CE OS, with the exception of the HX3. AppLock configuration instructions are located in each equipment-specific reference guide. Application Shortcuts Configure shortcuts to other applications on the MX3X.
Page 180: Adapters
Adapters Adapters Note: LXE recommends the user review the network settings configuration utilities and the default values in the MX3X Reference Guide before setting All Adapters to Enable in the Adapters applet. Adapters Options - Network Manage When enabled, the Enabler will control the network settings. This parameter cannot be configured from the Network Avalanche Mobility Center Console and is enabled by default.
Page 181 Avalanche Network Profile Displayed When enabled, the Enabler will ignore any network or wireless settings coming from the Avalanche MC Console Manual and use only the network settings on the MX3X. Settings Properties Selecting the Properties icon displays the Manual Settings Properties dialog applet. From here, the user can...
Page 182 For MX3X descriptions of these Enabler parameters, refer to the MX3X Reference Guide. LXE does not recommend enabling “Manage Wireless Settings” for Cisco Client or Summit Client devices. Troubleshooting: When you download a profile that is configured to manage network and wireless settings, the Enabler will not apply the manage network and wireless settings to the adapter unless the global Manage wireless settings and Manage network settings options are enabled on the Adapters panel (see Figure titled Adapters Options –...
Page 183: Status
It also searches for new adapters and may cause a slight delay to refresh the contents of the drop-down menu. Status Display Link speed indicates the speed at which the signal is being sent from the adapter to the MX3X. Speed is dependent on signal strength. E-EQ-MX3XRG-W-ARC [ 171 ] MX3X Reference Guide...
Page 184: Exit
If changes were made on the MX3XStartup/Shutdown tab screen, then after entering the password, tap OK and the following screen is displayed: Continue or Stop Monitoring Change the option if desired. Tap the X button to cancel Exit. Tap the OK button to exit the Avalanche applet. E-EQ-MX3XRG-W-ARC [ 172 ] MX3X Reference Guide...
Page 185: Using Remote Management
MX3X eXpress Scan Desktop Icon If the MX3X has an eXpress Scan icon on the desktop, eXpress Scan may be used for the initial configuration of the device. If the eXpress Scan icon is not present on the desktop, install the Enabler following the instructions earlier in this section. If the icon is still not present, the Enabler must be updated as detailed in the installation instructions earlier in this section.
Page 186: Step 2: Scan Barcodes
Step 2: Scan Barcodes Step 2: Scan Barcodes For each LXE device to be configured, please follow these instructions. Start eXpress Scan on the MX3X by double clicking the eXpress Scan icon. Enter the barcode password, if any. eXpress Scan Password Input Click Start.
Page 187: Step 3: Process Completion
After the last barcode is scanned, the settings are automatically applied. Configuring Settings Once configured, the MX3X is warmbooted. Once connected to the wireless network and the Mobile Device Server, any software updates and additional configuration data are downloaded. E-EQ-MX3XRG-W-ARC [ 175 ] MX3X Reference Guide...
Page 188: Reflash The Mx3X
Depending on the size of the operating system, the total time required for successful reflashing may require several minutes. The OS upgrade files are unique to your MX3X's physical configuration and date of manufacture. OS upgrade files designed for one device configuration should not be used on a different device configuration.
Page 189: Troubleshooting
The operating system will not be able to execute the OS update when the battery level is too low (25% or less), as there is a high risk that the power remaining in the battery expires when executing the update and the MX3X will be left in an inoperable state.
Page 190: Wireless Network Configuration For Lxe Devices
Wireless Network Configuration for LXE Devices The LXE MX3X uses either a Summit 802.11b/g radio or a Summit 802.11a/b/g radio. The radio can be configured for no encryption, WEP encryption or WPA security. Please refer to the table below for the security options supported.
Page 191: Summit Client Utility
The SCU help may also be accessed by selecting Start | Help and tapping the Summit Client Utility link. The SCU does not have to be accessed to view the help information using this option. E-EQ-MX3XRG-W-ARC [ 179 ] MX3X Reference Guide...
Page 192: Summit Tray Icon
The signal strength for the currently associated/authenticated Access Point is -71 dBm to -90 dBm The signal strength for the currently associated/authenticated Access Point is -51 dBm to -70 dBm The signal strength for the currently associated/authenticated Access Point is greater than -50 dBm E-EQ-MX3XRG-W-ARC [ 180 ] MX3X Reference Guide...
Page 193: Wireless Zero Config Utility And The Summit Radio
The WZC icon may not be visible until control is passed to the WZC utility as described below. You can use either the Wireless Zero Configuration Utility or the Summit Client Utility to connect to your network. LXE recommends using the Summit Client Utility to connect to your network. The Wireless Zero Configuration Utility cannot control the complete set of security features of the radio.
Page 194: Main Tab
Profile and Global parameters may only be edited after entering the Admin Login password. The Active Profile may be changed without logging in. Once logged in, the button label changes to Admin Logout. The admin is also automatically logged out when the SCU is exited. E-EQ-MX3XRG-W-ARC [ 182 ] MX3X Reference Guide...
Page 195: Admin Login
Main Tab Access additional troubleshooting features on the Diags Tab After Admin login, the use can also: Create, edit, rename and delete profiles on the Profile Tab Edit global parameters on the Global Tab E-EQ-MX3XRG-W-ARC [ 183 ] MX3X Reference Guide...
Page 196: Auto Profile
Auto Profile. The search continues until: the SCU connects to and, if necessary, authenticates with one of the specified profiles or until the Off button is clicked to turn off Auto Profile. E-EQ-MX3XRG-W-ARC [ 184 ] MX3X Reference Guide...
Page 197: Profile Tab
Using the Scan Feature Commit – Ensures that the profile settings made on this screen are saved in the profile. When not logged in, the parameters can be viewed, but cannot be changed. E-EQ-MX3XRG-W-ARC [ 185 ] MX3X Reference Guide...
Page 198: Using The Scan Feature
The SSID parameter is assigned the value of the SSID of the AP. Other profile entries must be completed manually. Click the Refresh button to update the display. E-EQ-MX3XRG-W-ARC [ 186 ] MX3X Reference Guide...
Page 199: Profile Parameters
Access Points. Default: Blank Power Save Power save mode. Options: CAM (Constantly Awake Mode, power save off) Maximum (Maximum power saving mode) Fast (Fast power saving mode) Default: Fast E-EQ-MX3XRG-W-ARC [ 187 ] MX3X Reference Guide...
Page 200: Tx Power
It is important this parameter correspond to the AP to which the device is to connect. For example, if this parameter is set to G rates only the LXE device may only connect to APs set for G rates and not those set for B and G rates.
Page 201: Auth Type
EAP only. In this case, set the Auth Type radio parameter to “LEAP”. EAP Type Extensible Authentication Protocol (EAP) type used for 802.1x authentication to AP. Options: None LEAP EAP-FAST PEAP-MSCHAP PEAP-GTC EAP-TLS Default: E-EQ-MX3XRG-W-ARC [ 189 ] MX3X Reference Guide...
Page 202: Encryption
CCKM TKIP CKIP Manual CKIP Auto Default: None Note: The Encryption type chosen determines if the WEP/PSK Keys button is active. Available entries on the pop up window vary by encryption type chosen. E-EQ-MX3XRG-W-ARC [ 190 ] MX3X Reference Guide...
Page 203: Status Tab
There are no user entries on this screen. Note: After completing radio configuration, it is a good idea to review this screen to verify the radio has associated (no encryption, WEP) or authenticated (LEAP, any WPA), as indicated above. E-EQ-MX3XRG-W-ARC [ 191 ] MX3X Reference Guide...
Page 204: Diags Tab
Save To… – Use this save the results of the diagnostics to a text file. Use the explorer window to specify the name and location for the diagnostic file. The text file can viewed using an application such as WordPad. E-EQ-MX3XRG-W-ARC [ 192 ] MX3X Reference Guide...
Page 205: Global Tab
“Custom” when the operating system registry has been used to set the parameter to a value not available from the Global settings parameter options. Selecting Custom for a parameter has no effect as the parameter value returns to the previously selected value when you press Commit. E-EQ-MX3XRG-W-ARC [ 193 ] MX3X Reference Guide...
Page 206: Roam Trigger
“Custom” when the operating system registry has been used to set the parameter to a value not available from the Global settings parameter options. Selecting Custom for a parameter has no effect as the parameter value returns to the previously selected value when you press Commit. E-EQ-MX3XRG-W-ARC [ 194 ] MX3X Reference Guide...
Page 207: Roam Period
“Custom” when the operating system registry has been used to set the parameter to a value not available from the Global settings parameter options. Selecting Custom for a parameter has no effect as the parameter value returns to the previously selected value when you press Commit. E-EQ-MX3XRG-W-ARC [ 195 ] MX3X Reference Guide...
Page 208: Dfs Channels
Optimized (Use Cisco Information Element and CCX version number, support all CCX features except AP assisted roaming, AP specified maximum transmit power and radio management) Off (Do not use Cisco Information Element and CCX version) Default: Off (for 802.11b/g radio) Optimized (for 802.11a/b/g radio) E-EQ-MX3XRG-W-ARC [ 196 ] MX3X Reference Guide...
Page 209: Wmm
The value for this parameter should be set as follows: Antenna Configuration TX Diversity A Main and BG Main Main Only A Main and A Aux BG Main and BG Aux A Main only Main Only BG Main only Main Only E-EQ-MX3XRG-W-ARC [ 197 ] MX3X Reference Guide...
Page 210: Rx Diversity
(sent as several pieces instead of as one block). Use a low setting in areas where communication is poor or where there is a great deal of radio interference. Options: 256 to 2346 Default: 2346 E-EQ-MX3XRG-W-ARC [ 198 ] MX3X Reference Guide...
Page 211: Rts Thresh
Access Point. Options: 0 to 2347 Default: 2347 The LED on the radio card is not visible to the user when the radio card is installed in a sealed MX3X. Options: On, Off Default: Tray Icon Determines if the Summit icon is displayed in the system tray.
Page 212: Hide Password
If the authentication credentials are not stored in the active profile and the authentication times out, the user is again prompted to enter the credentials. Options: An integer from 3 to 60 Default: E-EQ-MX3XRG-W-ARC [ 200 ] MX3X Reference Guide...
Page 213: Certs Path
Windows certificate store. LXE suggests ensuring the directory path currently exists before assigning the path in this parameter. For example, if the certificate is stored in My Computer/System/mycertificate.cer, enter System in the Certs Path text box as the directory path.
Page 214: Sign-On Vs. Stored Credentials
2. For PEAP-MSCHAP, PEAP-GTC and EAP-TLS import the CA certificate into the Windows certificate store. 3. For EAP-TLS, also import the User Certificate into the Windows certificate store. 4. Access the Credentials screen again. Make sure the Validate server and Use MS store checkboxes are checked. E-EQ-MX3XRG-W-ARC [ 202 ] MX3X Reference Guide...
Page 215 If the user clicks the Cancel button, the device does not associate. The user is not prompted again for credentials until the device is rebooted, the radio is disabled then enabled, the Reconnect button on the Diags Tab is clicked or the profile is modified and the Commit button is clicked. E-EQ-MX3XRG-W-ARC [ 203 ] MX3X Reference Guide...
Page 216: Windows Certificate Store Vs. Certs Path
4. The default is to use all certificates in the store. If this is OK, skip to the last step. 5. Otherwise, to select a specific certificate click on the Browse (…) button. E-EQ-MX3XRG-W-ARC [ 204 ] MX3X Reference Guide...
Page 217 7. Select the desired certificate and click the Select button to return the selected certificate to the CA Cert textbox. 8. Click OK to exit the Credentials screen and then Commit to save the profile changes. E-EQ-MX3XRG-W-ARC [ 205 ] MX3X Reference Guide...
Page 218: Configuring The Profile
Admin Login button and enter the password. LXE recommends editing the default profile with the parameters for your network. Select the Default profile from the pull down menu. Make any desired parameter changes as described in the applicable following section determined by network security type and click the Commit button to save the changes.
Page 219: No Security
Once configured, click the Commit button. Ensure the correct Active Profile is selected on the Main tab and warmboot. The SCU Main tab shows the device is associated after the radio connects to the network. E-EQ-MX3XRG-W-ARC [ 207 ] MX3X Reference Guide...
Page 220: Wep
Once configured, click the Commit button. Ensure the correct Active Profile is selected on the Main tab and warmboot. The SCU Main tab shows the device is associated after the radio connects to the network. E-EQ-MX3XRG-W-ARC [ 208 ] MX3X Reference Guide...
Page 221: Leap
Click OK then click Commit. Ensure the correct Active Profile is selected on the Main Tab and warmboot. The SCU Main tab shows the device is associated after the radio connects to the network. E-EQ-MX3XRG-W-ARC [ 209 ] MX3X Reference Guide...
Page 222: Peap/Mschap
For Stored Credentials, User, Password and the CA Certificate Filename must be entered. Enter these items as directed below. PEAP/MSCHAP Credentials Enter the Domain\Username (if the Domain is required), otherwise enter the Username. Enter the password. E-EQ-MX3XRG-W-ARC [ 210 ] MX3X Reference Guide...
Page 223 Click OK then click Commit. The device should be authenticating the server certificate and using PEAP/MSCHAP for the user authentication. Note: The date must be properly set on the device to authenticate a certificate. E-EQ-MX3XRG-W-ARC [ 211 ] MX3X Reference Guide...
Page 224: Peap/Gtc
Enter the Domain\Username (if the Domain is required), otherwise enter the Username. Enter the password. Leave the CA Certificate File Name blank for now. Click OK then click Commit. Ensure the correct Active Profile is selected on the Main Tab. E-EQ-MX3XRG-W-ARC [ 212 ] MX3X Reference Guide...
Page 225 Click OK then click Commit. The device should be authenticating the server certificate and using PEAP/MSCHAP for the user authentication. Note: The date must be properly set on the device to authenticate a certificate. E-EQ-MX3XRG-W-ARC [ 213 ] MX3X Reference Guide...
Page 226: Wpa/Leap
To use Stored Credentials, click on the Credentials button. No entries are necessary for Sign-On Credentials as the user will be prompted for the Username and Password when connecting to the network. WPA/LEAP Credentials Enter the Domain\Username (if the Domain is required), otherwise enter the Username. Enter the password. E-EQ-MX3XRG-W-ARC [ 214 ] MX3X Reference Guide...
Page 227: Eap-Fast
RADIUS server must have auto provisioning enabled to send the PAC provisioning credentials to the MX3X. EAP-FAST Profile Configuration For automatic PAC provisioning, once a username/password is authenticated, the PAC information is stored on the MX3X. The same username/password must be used to authenticate each time. See the note below for more details.
Page 228 Note: When using Automatic PAC Provisioning, once authenticated, there is a file stored in the \System directory with the PAC credentials. If the username is changed, that file must be deleted. The filename is autoP.00.pac. E-EQ-MX3XRG-W-ARC [ 216 ] MX3X Reference Guide...
Page 229: Eap-Tls
For Stored Credentials, User, Password and the CA Certificate Filename must be entered. Enter these items as directed below. EAP-TLS Credentials Enter the Domain\Username (if the Domain is required), otherwise enter the Username. Leave the certificate file name entries blank for now. E-EQ-MX3XRG-W-ARC [ 217 ] MX3X Reference Guide...
Page 230 Enter the certificate filename in the CA Cert textbox. Click OK then click Commit. The MX3X should be authenticating the server certificate and using EAP-TLS for the user authentication. Certificates for information on generating a Root CA certificate or a User certificate.
Page 231: Wpa Psk
Once configured, click the Commit button. Ensure the correct Active Profile is selected on the Main Tab and warmboot. The SCU Main tab shows the device is associated after the radio connects to the network. E-EQ-MX3XRG-W-ARC [ 219 ] MX3X Reference Guide...
Page 232: Certificates
The easiest way to get the root CA certificate is to use a browser on a PC to navigate to the Certificate Authority. To request the root CA certificate, open a browser to http://<CA IP address>/certsrv. Sign into the CA with any valid username and password. Logon to Certificate Authority E-EQ-MX3XRG-W-ARC [ 220 ] MX3X Reference Guide...
Page 233 Make sure the correct root CA certificate is selected in the list box. Download CA Certificate Screen Click the DER button. To download the CA certificate, click on the Download CA certificate link. E-EQ-MX3XRG-W-ARC [ 221 ] MX3X Reference Guide...
Page 234 Generating a Root CA Certificate Download CA Certificate Screen Click the Save button and save the certificate. Make sure to keep track of the name and location of the certificate. E-EQ-MX3XRG-W-ARC [ 222 ] MX3X Reference Guide...
Page 235: Installing A Root Ca Certificate
Note: This section is only if the Windows certificate store is used. If the certificate store is not used, copy the certificate to the \System folder or other path specified in the Summit Certs global parameter. Copy the certificate file to the MX3X. Import the certificate by navigating to Start | Control Panel | Certificates. Certificates Tap the Import button.
Page 236 Using the explorer buttons, browse to the location where you copied the certificate, select the certificate desired and tap OK. Certificate Import Confirmation Tap Yes to import the certificate. Once the certificate is installed, return to the proper authentication section, earlier in this manual. E-EQ-MX3XRG-W-ARC [ 224 ] MX3X Reference Guide...
Page 237: Generating A User Certificate
This process saves a user certificate and a separate private key file. Windows CE equipped devices such as the device require the private key to be saved as a separate file rather than including the private key in the user certificate. Certificate Services Welcome Screen Click the Request a certificate link. E-EQ-MX3XRG-W-ARC [ 225 ] MX3X Reference Guide...
Page 238 Generating a User Certificate Request a Certificate Screen Click on the advanced certificate request link. Advanced Certificate Request Screen Click on the Create and submit a request to this CA link. E-EQ-MX3XRG-W-ARC [ 226 ] MX3X Reference Guide...
Page 239 Be sure to note the name used for the private key file, for example LXEUSER.PVK. The certificate file created later in this process must be given the same name, for example, LXEUSER.CER. DO NOT check to use strong private key protection. Make any other desired changes and click the Submit button. E-EQ-MX3XRG-W-ARC [ 227 ] MX3X Reference Guide...
Page 240 When prompted for the private key password: Click None if you do not wish to use a password, or Enter and confirm your desired password then click OK. Certificate Issued Click the Download certificate link. E-EQ-MX3XRG-W-ARC [ 228 ] MX3X Reference Guide...
Page 241 Be sure use the same name for the certificate file as was used for the private key file. For example, it the private key was saved as LXEUSER.PVK then the certificate file created must be given the same name, for example, LXEUSER.CER. E-EQ-MX3XRG-W-ARC [ 229 ] MX3X Reference Guide...
Page 242: Installing A User Certificate
Installing a User Certificate Installing a User Certificate Copy the certificate and private key files to the MX3X. Import the certificate by navigating to Start | Control Panel | Certificates. Select My Certificates from the pull down list. Certificates Tap the Import button.
Page 243 From the Field pull down menu, select Private Key. Private Key Not Present If the private key is present, the process is complete. If the private key is not present, import the private key. E-EQ-MX3XRG-W-ARC [ 231 ] MX3X Reference Guide...
Page 244 Make sure the certificate and private key file have the same name, for example LXEuser.cer for the certificate and LXEuser.pvk for the private key file. If the file names are not the same, rename the private key file and import it again. E-EQ-MX3XRG-W-ARC [ 232 ] MX3X Reference Guide...
Page 245: Keymaps
Keymaps KeyMap 101-Key Equivalencies The following keymap is used on an MX3X that is NOT running an LXE Terminal Emulator. LXE terminal emulators use a separate keymap (later in this section). When using a sequence of keys that includes the 2nd key, press the 2nd key first then the rest of the key sequence.
Page 246 Bksp Delete Home Left Arrow Right Arrow Page Up Up Arrow Page Down Down Arrow ScrollLock Shift Shift Shift CapsLock Off CapsLock Off CapsLock Off CapsLock Off CapsLock Off CapsLock Off CapsLock Off E-EQ-MX3XRG-W-ARC [ 234 ] MX3X Reference Guide...
Page 247 CapsLock Off CapsLock Off CapsLock Off CapsLock Off CapsLock Off CapsLock Off CapsLock Off CapsLock Off CapsLock Off Shft Shft Shft Shft Shft Shft Shft Shft Shft Shft Shft Shft Shft Shft Shft E-EQ-MX3XRG-W-ARC [ 235 ] MX3X Reference Guide...
Page 248 KeyMap 101-Key Equivalencies To get this Key / Function Press these Keys in this Order Shft Shft Shft Shft Shft Shft Shft Shft Shft Shft Shft < > : (colon) E-EQ-MX3XRG-W-ARC [ 236 ] MX3X Reference Guide...
Page 249 KeyMap 101-Key Equivalencies To get this Key / Function Press these Keys in this Order ; (semicolon) _ (underscore) , (comma) ' (apostrophe) ~ (tilde) " & E-EQ-MX3XRG-W-ARC [ 237 ] MX3X Reference Guide...
Page 250: Ibm 3270 Terminal Emulation
IBM 3270 Terminal Emulation The MX3X's IBM 3270 Terminal Emulator keypads are designed to allow the user to enter terminal emulator commands when running LXE’s RFTerm program. When running RFTerm on the MX3X, please refer to RFTerm Webhelp for equivalent keys and keypress sequences.
Page 251: Ibm 5250 Terminal Emulation
IBM 5250 Terminal Emulation The MX3X's IBM 5250 Terminal Emulator keypads are designed to allow the user to enter terminal emulator commands when running LXE’s RFTerm program. When running RFTerm on the MX3X, please refer to RFTerm Webhelp for equivalent keys and keypress sequences.
Page 252: Technical Specifications
1900 mAh 10.8V, 3 cell, Li-Ion battery pack.In-Unit and External Re-Chargeable Internal Nickel Cadmium (NiCd) 5.7V max. Automatically charges from main battery dur- Backup Battery (CMOS) ing normal operation. Memory operational for 5 minutes when main battery is depleted E-EQ-MX3XRG-W-ARC [ 240 ] MX3X Reference Guide...
Page 253: External Connectors / Interface / Usb Host / Client Ports / Power Connector
Display readable (with backlight on) for <= two hours Ambient Light – ranging from total darkness to Keypad readable (after previous exposure to a 60W bulb for 30 minutes) direct sunlight for <= 15 minutes. E-EQ-MX3XRG-W-ARC [ 241 ] MX3X Reference Guide...
Page 254: Network Card Specifications
Same as MX3X Storage Temperature Connectivity TCP/IP, Ethernet, ODI Diversity Bluetooth Enhanced Data Rate Up to 3.0 Mbit/s over the air Connection No less than 32.80 feet (10 meters) line of sight Bluetooth Version 2.0 + EDR E-EQ-MX3XRG-W-ARC [ 242 ] MX3X Reference Guide...
Page 255: Applock Error Messages
The backdoor keys have been pressed. The backdoor hotkeys provide a method for Backdoor message LOG_ customer service to get a user back into their system without editing the registry or received PROCESSING reloading the device. E-EQ-MX3XRG-W-ARC [ 243 ] MX3X Reference Guide...
Page 256 Encrypt exported key OK Encrypt password process successful. LOG_EX Encrypt failure The password encryption failed. LOG_ERROR Encrypt gen key failure Unable to encrypt password. LOG_ERROR Encrypt generate key Unable to encrypt password. LOG_ERROR failure E-EQ-MX3XRG-W-ARC [ 244 ] MX3X Reference Guide...
Page 257 Exit There are two exit paths from the enumeration function. This message denotes the LOG_ AppLockEnumWindows- enumeration function did not find the application. PROCESSING Not found LOG_ Exit DecryptPwd Exiting password decryption processing. E-EQ-MX3XRG-W-ARC [ 245 ] MX3X Reference Guide...
Page 258 AppLock. Hook wndproc of open The application is open, but AppLock cannot lock it. LOG_ERROR app failure Hot key event creation The Admin applet is unable to create the hotkey notification. LOG_ERROR failure E-EQ-MX3XRG-W-ARC [ 246 ] MX3X Reference Guide...
Page 259 Both AppLock.exe and Kbdhook.dll register the message at initialization. PROCESSING The AppLock system communicates with the keyboard hook via a user defined message. LOG_ Registering Hotkey MSG Both Applock.exe and Kbdhook.dll register the message at initialization. PROCESSING E-EQ-MX3XRG-W-ARC [ 247 ] MX3X Reference Guide...
Page 260 ToUser after admin, not The user mode switch is attempted when the device boots and after the administrator LOG_EX at boot presses the hotkey. The mode switch is being attempted after a hotkey press. E-EQ-MX3XRG-W-ARC [ 248 ] MX3X Reference Guide...
Page 261 The window handle that is passed to the enumeration function. This message can be Window handle to used by engineering with other development tools to trouble shoot application lock LOG_EX enumwindows=%x failures. WM_WINDOWPOSCHG Output the window size after it has been adjusted by AppLock LOG_EX adjusted=%x E-EQ-MX3XRG-W-ARC [ 249 ] MX3X Reference Guide...
Page 262: Hat Encoding
Hat Encoding Hat Encoding E-EQ-MX3XRG-W-ARC [ 250 ] MX3X Reference Guide...
Page 263: Revision History
3. Enabler Installation and Con- 3. Changed LXE_MX3X_ENABLER.CAB to LXE_ENA- figuration BLER.CAB. V / Dec 2009 Control Panel - Administration Troubleshooting: Removed LXE AppLock backdoor key sequence. W / Jan 2010 Entire Guide MX3X Archived / Obsolete E-EQ-MX3XRG-W-ARC [ 251 ] MX3X Reference Guide...
Page 264: Index
Setup Bootstrapping the RMU Asian fonts Assign Auth Server CAB Files on the Flash Card Auth Timeout Calibration Auto-reconnect, Bluetooth CCX Features Auto hide Certificates 89, 220 Auto Profile Root CA Automatic reset E-EQ-MX3XRG-W-ARC [ 252 ] MX3X Reference Guide...
Page 265 Enabler searches for an Mobile Device Server Ctrl Char Mapping Enabler Settings icon custom Code IDs Endcap Combinations Custom identifier Endcaps and COM Ports Custom Identifiers Environmental Specifications Error message Mobile unit out of resources Data stripping E-EQ-MX3XRG-W-ARC [ 253 ] MX3X Reference Guide...
Page 266 LAUNCH.EXE High Contrast LaunchApp Tab Hotkey Leading and Trailing AppLock LED Functions Length Based Barcode Stripping Icon on taskbar Link speed Icons Logging Explorer, Internet AppLock My Computer LXEConnect My Documents Recycle Bin E-EQ-MX3XRG-W-ARC [ 254 ] MX3X Reference Guide...
Page 267 Preparing an LXE Device for Remote Management Prerequisites Network and Dialup Options Enabler Install and Configure Network Card Specifications Wavelink Avalanche System No Security Profile Notification Profile Parameters Profile Tab Program Shutdown Programmable Scan Owner Prompt Command E-EQ-MX3XRG-W-ARC [ 255 ] MX3X Reference Guide...
Page 268 160, 171 Installing on VX3X Status Display RTS Thresh Status Panel RunCmd Tab AppLock RX Diversity Status Popup Status tab Status Tab Scan Config 160, 165 StickyKeys Scan Config option Stop Enabler Monitoring E-EQ-MX3XRG-W-ARC [ 256 ] MX3X Reference Guide...
Page 269 Summit Radio Tx Power WPA/LEAP Summit Radio 214-215 Update tab” Update Window Display Upgrade System Baseline User Certificates Generating Installing on VX3X User Idle timer User Interface User Interface Language Using eXpress Scan E-EQ-MX3XRG-W-ARC [ 257 ] MX3X Reference Guide...
