1.0 INTRODUCTION

1.1 SPECIFICATIONS
TABLE 1
MANIFOLD PRESSURE: Hi
MANIFOLD PRESSURE: Lo
ORIFICE SIZE: @ 0-4500'
CONTROL VALVE TYPE:
ITEM
INPUT: Hi
INPUT: Lo
GAS INLET SUPPLY
PRESSURE:
VENTING
FAN * Optional *
NATURAL GAS (NG)
18,000 Btu/hr (5.27 kW)
12,500 Btu/hr (3.66 kW)
3.5" w.c. (0.87 kPa)
1.7" w.c. (0.42 kPa)
Minimum: 5.0" w.c. (1.2 kPa)
Maximum: 13.5" w.c. (3.4 kPa)
# 48 DMS
Honeywell , SIT 820 Nova,
Robertshaw-Grayson or
Skytech AF-4000
2-ply aluminum vent,
Simpson Dura-Vent, Selkirk or
Security
Variable Speed (120 Volt)
PROPANE (LPG)
15,000 Btu/hr (4.39 kW)
12,500 Btu/hr (3.66 kW)
10" w.c. (2.49 kPa)
6.4" w.c. (1.57 kPa)
Minimum: 12" w.c. (2.99 kPa)
Maximum: 14" w.c. (3.49 kPa)
# 57 DMS
Honeywell , SIT 820 Nova,
Robertshaw-Grayson or
Skytech AF-4000
2-ply aluminum vent,
Simpson Dura-Vent, Selkirk or
Security
Variable Speed (120 Volt)
